Integrating C Libraries into Fortran with ISO_C_BINDING: A Step‑by‑Step Guide

Problem & Takeaway

When you need to reuse a mature C library in a Fortran project, you must avoid name mangling, type mismatches, and ABI incompatibilities. The ISO_C_BINDING module gives you a portable, compile‑time way to declare C‑compatible kinds, pointer types, and function interfaces. By following a clear procedure—compile the C code, write a Fortran interface with BIND(C), and link with matching compiler flags—you can call C functions directly from Fortran and verify the integration with simple tooling.

Prerequisites

• Fortran compiler supporting ISO_C_BINDING (e.g., gfortran 9+).
• Standard C compiler (e.g., gcc).
• Basic knowledge of C and Fortran data types.
• Access to the C library source or pre‑compiled object files.

Desired Outcome

Produce a working executable that calls a C function from Fortran, prints the result, and passes basic diagnostics (symbol visibility, correct output, no runtime crashes).

Concrete Example

We’ll wrap a simple C function that adds two integers:

/* lib.c */
#include <stdio.h>

int add_ints(int a, int b) {
    return a + b;
}

And call it from Fortran:

! main.f90
program use_c
    use iso_c_binding, only: c_int, c_funptr, c_loc
    implicit none

    interface
        function add_ints(a, b) bind(C, name="add_ints") result(res) bind(C)
            import :: c_int
            integer(c_int), value :: a, b
            integer(c_int) :: res
        end function add_ints
    end interface

    integer(c_int) :: x, y, z
    x = 7_c_int
    y = 5_c_int
    z = add_ints(x, y)
    print *, "Result: ", z
end program use_c

Step‑by‑Step Procedure

1. Compile the C source into an object file.

   # Compile with PIC for shared libs or static linking
   gcc -c -fPIC lib.c -o lib.o


2. Compile the Fortran source into an object file.

   gfortran -c main.f90 -o main.o


3. Link both objects into a single executable.

   gfortran main.o lib.o -o demo


4. Run the program to verify output.

   ./demo
   # Expected output: Result: 12


5. Check symbol visibility.

   nm demo | grep add_ints
   # Should list a symbol like 0000000000000000 T add_ints


6. Optional: Verify ABI with objdump.

   objdump -d demo | less
   # Search for the call to add_ints to confirm correct calling convention.


Expected Checks

• Symbol name. Use nm or objdump to confirm the C function appears as add_ints (no underscore or mangling). If it shows _add_ints or similar, adjust the Fortran BIND(C, NAME='add_ints') or compile with -fno-underscoring.
• Return value correctness. Compare the Fortran output against a known C program that prints the same result.
• Runtime stability. No segmentation faults or stack corruption should occur. If the program crashes, verify that the Fortran arguments are passed with the value attribute and that the C function signature matches.

Recovery Options

1. Mismatch in integer kind. If the Fortran output is wrong, check that c_int matches the C int size on your platform. On 64‑bit systems, c_int is still 32‑bit; use c_long if the C function uses long.
2. Underscore prefix. If the symbol appears as _add_ints, either:
   • Add -fno-underscoring to the Fortran compile line.
   • Change the C function name to add_ints_ and update the Fortran BIND(C, NAME='add_ints_').
3. Structure alignment. For complex data, declare C structs with __attribute__((packed)) and use BIND(C) in Fortran to match layout. Verify with sizeof in C and c_sizeof in Fortran.
4. Linker errors. Ensure both object files are compiled with the same ABI flags (e.g., -std=c11 for C and -std=f2008 for Fortran). Mismatched flags can cause symbol resolution failures.

Limitations & Practical Checks

• ISO_C_BINDING only guarantees interoperability for scalar types and pointers. For arrays, use explicit shape or c_ptr and manual copying.
• Non‑interoperable types (e.g., Fortran complex vs C double complex) require a C wrapper that translates between representations.
• When calling C functions that modify memory, ensure the Fortran arguments are passed by reference (intent(inout)) and use the value attribute only for scalars.

To confirm correct operation, run the compiled program and compare its output with a reference C program. If the output matches and no linker or runtime errors occur, the integration is considered successful.

Diagram

Component	Role
C Source (lib.c)	Defines native functions.
Fortran Interface (main.f90)	Declares C functions with ISO_C_BINDING.
Compiler Flags	Ensures matching ABI and symbol naming.
Linker	Combines object files into executable.
