Fortran ↔ C Interoperability with ISO_C_BINDING: Design & Checks

Requirements

To call a C routine from Fortran you need:

1. Both compilers support the ISO_C_BINDING module (Fortran 2003+).
2. Matching C types for the arguments and return value; use the C‑compatible types defined in ISO_C_BINDING (e.g., C_INT, C_FLOAT).
3. Consistent name mangling – the Fortran call must reference the exact C symbol name.

Smallest Viable Design

The minimal design declares the external C function once in Fortran, marks it with BIND(C), and calls it directly. No wrapper libraries or additional Fortran modules are required.

!< Fortran module that calls a C add function >
module c_add_mod
  use, intrinsic :: iso_c_binding, only: c_int
  implicit none
  interface
    function c_add(a, b) bind(C, name="c_add") result(res) bind(C)
      import :: c_int
      integer(c_int), value :: a, b
      integer(c_int) :: res
    end function
  end interface
end module

program test_c_add
  use c_add_mod
  implicit none
  integer(c_int) :: x, y, z
  x = 5_c_int
  y = 7_c_int
  z = c_add(x, y)
  print *, "5 + 7 =", z
end program

On the C side you need a matching definition:

/* c_add.c */
#include <stdint.h>
int32_t c_add(int32_t a, int32_t b) { return a + b; }

Trust & Data Boundaries

The Fortran code assumes the C library follows the C ABI: correct calling convention, stack alignment, and type sizes. The boundary is a single function call; the Fortran side must validate any data returned from C if it is used in a context that could cause undefined behavior (e.g., assuming a non‑null string).

Operational Checks

• Compile‑time type checking: The compiler will reject mismatched types if you use ISO_C_BINDING types. Use -Wall -Wextra to catch hidden mismatches.
• Runtime bounds checking: With -fcheck=all (gfortran) or equivalent flags you can detect out‑of‑bounds array accesses that might be caused by a C routine.
• Alignment & aliasing flags: Use -fno-strict-aliasing or the compiler’s aliasing option to avoid subtle bugs when the C routine accesses Fortran arrays.
• Name mangling verification: Compile the C file and run nm to confirm the symbol name is c_add.

Failure Modes

• Name mangling mismatch: If the Fortran BIND(C, name="c_add") does not match the C symbol, the call will fail at link time or result in a segmentation fault.
• Type size mismatch: Using INTEGER(C_INT) assumes int32_t on the C side; on a platform where int is 64 bits this will corrupt data.
• Derived type layout: A Fortran derived type marked BIND(C) must have only interoperable components. Mixing non‑interoperable components leads to undefined layout.
• String handling: Fortran CHARACTER is not null‑terminated; passing a Fortran string to a C function expecting char* without length can overflow.
• Stack alignment differences: On 64‑bit targets the stack must be 16‑byte aligned for C; a Fortran compiler that misaligns the stack will cause crashes.

When to Redesign

• Target compiler lacks ISO_C_BINDING support (e.g., old legacy Fortran compilers).
• The C library uses C++ name mangling or templates – the interface must be wrapped in extern "C".
• Performance critical code needs inline assembly or non‑C ABI interactions; a direct C call may be too slow.
• You need to expose Fortran code to other languages; a pure C interface is a lower‑level abstraction that may not suffice.

Practical Checklist

1. Define all C‑compatible types using ISO_C_BINDING.
2. Use BIND(C, name="...") to fix the symbol name.
3. Compile the C source with gcc -c c_add.c -o c_add.o and the Fortran source with gfortran -c test_c_add.f90 -o test_c_add.o.
4. Link both objects: gfortran test_c_add.o c_add.o -o test_c_add.
5. Run the program and verify the output matches the expected result.
6. Optionally, run nm test_c_add | grep c_add to confirm the symbol is present.

Example Verification Steps

# Compile C
gcc -c c_add.c -o c_add.o

# Compile Fortran
gfortran -c test_c_add.f90 -o test_c_add.o

# Link
gfortran test_c_add.o c_add.o -o test_c_add

# Run
./test_c_add
# Expected output: 5 + 7 = 12

After running, inspect the stack alignment with a debugger or gdb ./test_c_add if you suspect alignment issues. If the program crashes, check the symbol name with nm c_add.o and verify that the Fortran BIND(C, name="c_add") matches.

Conclusion

ISO_C_BINDING offers a minimal, standards‑compliant path to interoperate with C. By strictly using the provided types, binding attributes, and performing the outlined checks you can achieve reliable, maintainable cross‑language code. When the design assumptions break—such as missing ISO_C_BINDING support or the need for C++ mangling—consider a wrapper layer or a redesign that isolates the Fortran code from the changing ABI.
