Calling C Functions from Fortran with ISO_C_BINDING: A Practical Guide

Desired Outcome

A Fortran program successfully calls a C function—such as a math routine from a C library—with correct argument passing, return value handling, and no segmentation faults or data corruption.

Prerequisites

• A Fortran compiler supporting Fortran 2003 or later: gfortran ≥ 4.3, ifort ≥ 11, nvfortran, or flang.
• A C compiler compatible with the same ABI (typically gcc, clang, or icc on the same platform).
• The target C library headers and binaries installed (or a simple C source file you control).
• Basic familiarity with Fortran modules and C function prototypes.

Procedure

1. Write the C Function and Header

Create a minimal C library. For this guide we use a simple square-root wrapper:

/* clib.h */
#ifndef CLIB_H
#define CLIB_H

double c_sqrt(double x);

#endif

/* clib.c */
#include
#include "clib.h"

double c_sqrt(double x) {
    return sqrt(x);
}

Compile the C code to an object file:

gcc -c -O2 -std=c11 clib.c -o clib.o

Where to run: Any POSIX shell (Linux, macOS, WSL). Permissions: Write access to the working directory. Risk: Low—compilation only.

2. Declare the Fortran Interface Using ISO_C_BINDING

In your Fortran source, use the intrinsic iso_c_binding module and an interface block with bind(C):

! main.f90
program call_c_sqrt
    use, intrinsic :: iso_c_binding
    implicit none

    interface
        function c_sqrt(x) bind(C, name="c_sqrt")
            import :: c_double
            real(c_double), value :: x
            real(c_double) :: c_sqrt
        end function c_sqrt
    end interface

    real(c_double) :: x, y
    x = 2.0_c_double
    y = c_sqrt(x)
    print *, "c_sqrt(", x, ") = ", y
end program call_c_sqrt

Key points:

• import :: c_double brings the C-compatible kind parameter into the interface scope.
• value attribute on the dummy argument passes the scalar by value, matching C's double x parameter.
• bind(C, name="c_sqrt") tells the Fortran compiler to look for the exact symbol c_sqrt (no underscore mangling).

3. Compile the Fortran Source

gfortran -c -O2 main.f90 -o main.o

Check: Verify main.o exists and contains the expected symbol reference:

nm main.o | grep c_sqrt
# Expected: U c_sqrt  (undefined, to be resolved at link time)

4. Link Fortran and C Objects Together

Use the Fortran compiler as the linker driver so it pulls in the Fortran runtime (libgfortran, etc.):

gfortran main.o clib.o -o app

Where to run: Same shell. Risk: Linker errors if ABIs mismatch (32 vs 64 bit, different calling conventions).

Expected Checks

1. Run the executable: ./app should output something like c_sqrt( 2.0000000000000000 ) = 1.4142135623730951.
2. Compare against a pure-Fortran reference: Add print *, "sqrt(", x, ") = ", sqrt(x) and verify the two results match to machine precision.
3. Inspect argument values: Add print statements before and after the call, or run under gdb: gdb ./app then break main, run, print x, step, print y.
4. Confirm no abnormal termination: Exit code 0, no Segmentation fault or Bus error.

Common Pitfalls and Recovery Options

Linker Fails with "Undefined Reference"

• Cause: Symbol name mismatch (e.g., C compiler emits c_sqrt but Fortran expects c_sqrt_ or vice versa).
• Fix: Use bind(C, name="exact_symbol") to override. Inspect actual symbols with nm clib.o | grep c_sqrt.
• Cause: Architecture mismatch (32-bit object linked into 64-bit executable).
• Fix: Ensure both compilers target the same architecture: gcc -m64 and gfortran -m64 (or -m32 for both).

Runtime Crash or Wrong Results

• Type/kind mismatch: Fortran real(c_double) vs C double is correct; real (default kind) or double precision may differ on some platforms. Always use c_double, c_int, c_float from iso_c_binding.
• Array layout: Fortran is column-major; C is row-major. For 1-D arrays this doesn't matter. For multi-dimensional arrays, either transpose in Fortran before passing, or write the C function to expect column-major order.
• Missing value attribute: Without value, Fortran passes scalars by reference (pointer), causing the C function to read an address as a double.
• Intent attributes: Use intent(in) for read-only arrays, intent(out) or intent(inout) for outputs. The value attribute implies intent(in) for scalars.

Character String Handling

C expects null-terminated char*; Fortran strings are fixed-length without a terminator. For Fortran 2018+:

use, intrinsic :: iso_c_binding
character(kind=c_char), allocatable :: c_str
c_str = "hello" // c_null_char
call c_func(c_str)

For older standards, manually append c_null_char to a character(kind=c_char), dimension(:) array and pass the address of the first element.

Variadic Functions, Function Pointers, C++ Mangling

ISO_C_BINDING (Fortran 2003) does not support these directly. Write a C shim function with a fixed prototype that calls the variadic function or C++ method, then bind to the shim.

Verification Checklist

Check	Command / Method	Pass Criteria
Symbol names match	nm clib.o and nm main.o | grep U	Undefined in Fortran object matches defined in C object exactly
ABI compatibility	objdump -d main.o | head -30 or compile with -S to inspect assembly	Calling convention matches (System V AMD64 on Linux x86_64, Microsoft x64 on Windows)
Numerical correctness	Run program, compare c_sqrt(x) vs sqrt(x)	Relative difference < 1e-15 for double precision
No memory errors	valgrind ./app (Linux)	No invalid reads/writes, no leaks from the call

Limitations

• This guide covers Fortran 2003 ISO_C_BINDING. Fortran 2018 adds CFI_cdesc_t descriptors for assumed-shape/allocatable arrays and c_f_strptr/c_f_pointer for strings—those are not covered here.
• Compiler-specific extensions (Intel's !DEC$ ATTRIBUTES, GNU's bind(C) extensions) are avoided; the examples use only standard syntax.
• Linking with C++ libraries requires extern "C" wrappers and using the C++ compiler as the linker driver (or explicitly adding -lstdc++).

Minimal Complete Example for Testing

Save these three files in one directory, then run the commands below:

# clib.h
#ifndef CLIB_H
#define CLIB_H
double c_sqrt(double x);
#endif

# clib.c
#include
#include "clib.h"
double c_sqrt(double x) { return sqrt(x); }

! main.f90
program call_c_sqrt
    use, intrinsic :: iso_c_binding
    implicit none
    interface
        function c_sqrt(x) bind(C, name="c_sqrt")
            import :: c_double
            real(c_double), value :: x
            real(c_double) :: c_sqrt
        end function
    end interface
    real(c_double) :: x, y
    x = 2.0_c_double
    y = c_sqrt(x)
    print *, "C result: ", y
    print *, "Fortran reference: ", sqrt(x)
end program

gcc -c -O2 -std=c11 clib.c -o clib.o
 gfortran -c -O2 main.f90 -o main.o
 gfortran main.o clib.o -o app
 ./app

Expected output (values may vary in last digit):

 C result:    1.4142135623730951
 Fortran reference:    1.4142135623730951
