Using K3s' Built‑In Traefik Ingress Controller: Setup, Limits and Pitfalls

Problem: Exposing services without a separate load balancer

When you run a K3s cluster you often need to make HTTP/HTTPS traffic reach your applications from outside the cluster. Installing an external load balancer adds cost and complexity. K3s ships with a ready‑to‑use ingress controller—Traefik—that runs as a hostNetwork pod on each node, listening directly on ports 80 and 443. If you leave Traefik enabled (the default) you can expose services simply by creating an Ingress object.

Useful takeaway

By keeping Traefik enabled and defining an Ingress that references your Service, traffic arriving at any node’s port 80 or 443 is routed to the correct backend without needing an external load balancer.

How Traefik works in K3s

K3s launches Traefik as a DaemonSet‑like pod in the kube-system namespace. The pod spec sets hostNetwork: true, so the container shares the node’s network stack and binds to the node’s IP on ports 80 and 443. Traefik watches the Kubernetes Ingress API and updates its internal routing table automatically.

Minimal working example

1. Deploy a test service (run as a user with kubectl access to the cluster):

   kubectl create deployment nginx --image=nginx:stable
   kubectl expose deployment nginx --port=80 --target-port=80


2. Create a simple Ingress that sends all host‑based traffic to the nginx service:

   cat <<EOF | kubectl apply -f -
   apiVersion: networking.k8s.io/v1
   kind: Ingress
   metadata:
     name: nginx-ingress
     annotations:
       # optional: redirect HTTP to HTTPS if you later add TLS
       ingress.kubernetes.io/redirect-entry-point: https
   spec:
     rules:
     - host: example.local  # replace with a name you can resolve to the node IP
       http:
         paths:
         - path: /
           pathType: Prefix
           backend:
             service:
               name: nginx
               port:
                 number: 80
   EOF


3. Verify from a workstation (you need network reachability to the node’s IP):

   # Replace  with the IP of any node in the cluster
   curl -v http://example.local/  # add -H "Host: example.local" if DNS is not set


   You should see the nginx welcome page. If you get a connection refused, check that Traefik is running and that the Ingress was accepted.

Adding TLS (optional)

Traefik will serve HTTPS only if a TLS secret exists in the same namespace as the Ingress and is referenced by the Ingress tls block.

1. Create a TLS secret (replace tls.crt and tls.key with your own certificate and key):

   kubectl create secret tls nginx-tls \
     --cert=path/to/tls.crt \
     --key=path/to/tls.key \
     -n default


2. Update the Ingress to use the secret:

   cat <<EOF | kubectl apply -f -
   apiVersion: networking.k8s.io/v1
   kind: Ingress
   metadata:
     name: nginx-ingress-tls
     annotations:
       ingress.kubernetes.io/force-ssl-redirect: "true"
   spec:
     tls:
     - hosts:
       - example.local
       secretName: nginx-tls
     rules:
     - host: example.local
       http:
         paths:
         - path: /
           pathType: Prefix
           backend:
             service:
               name: nginx
               port:
                 number: 80
   EOF


3. Check the result:

   curl -kI https://example.local/  # -k skips cert verification if using a self‑signed cert


   Look for HTTP/2 200 and the server header showing Traefik.

Limits and common mistakes

• Traefik is the only default ingress. If you disable it with --disable traefik you must install another ingress controller or expose services via type: LoadBalancer Services; otherwise external traffic will fail.
• HostNetwork mode requires privileged access. The Traefik pod runs with hostNetwork: true, which some pod security policies or network policies may block. Verify that the policy allows traffic to ports 80 and 443 on the host.
• TLS secret must be in the same namespace as the Ingress. If you create the secret in a different namespace, Traefik will ignore it and fall back to HTTP, leading to “certificate not trusted” warnings in browsers.
• Image version is tied to the K3s release. Upgrading K3s may upgrade Traefik automatically. Custom annotations or middleware that relied on an older Traefik API version can break. Review the Traefik release notes when you upgrade K3s.
• Advanced features need explicit configuration. Rate limiting, request headers modification, or custom middleware must be defined in a Traefik ConfigMap or via annotations; missing configuration results in the feature being disabled silently.
• Port conflicts on the node. If another process already binds to port 80 or 443 on the node, Traefik will fail to start. Check with ss -tlnp | grep ':80\|:443' before deploying K3s or change the host ports via the --traefik-arg flag (advanced, not covered here).

Practical verification steps

1. Confirm Traefik is running:

   kubectl get pod -n kube-system -l app.kubernetes.io/name=traefik -o wide


   Look for READY 1/1 and the HOSTNETWORK column showing true (you can also view the spec with -o yaml).
2. Check the image tag (helps you know which Traefik version you are running):

   kubectl get pod -n kube-system -l app.kubernetes.io/name=traefik -o jsonpath='{.items[0].spec.containers[0].image}'


3. Test routing as shown in the minimal example above; a successful HTTP 200 response indicates Traefik is accepting traffic and forwarding it to the Service.
4. Validate TLS (if you added a secret):

   curl -vI https://example.local/ 2>&1 | grep -i "certificate"


   The output should show the certificate you created, not a self‑signed Traefik default.
5. Inspect logs for errors:

   kubectl logs -n kube-system -l app.kubernetes.io/name=traefik --tail=20


   Look for lines like Starting provider ******* or error messages about binding ports.

Rollback considerations

Disabling Traefik changes cluster state: external ingress stops working unless you replace it. To rollback, simply remove the --disable traefik flag from the K3s service/restart the K3s agent, which will redeploy the default Traefik pod. No data loss occurs because Traefik does not store persistent state.
