K3s Embedded SQLite Datastore: Architecture Note for Single‑Node Deployments

Requirements

For a lightweight Kubernetes distribution the control plane must start without external dependencies, store all API objects persistently, and run on devices with limited RAM and storage (e.g., Raspberry Pi, edge gateways). The datastore therefore needs to be zero‑configuration, file‑based, and usable by a single server process.

Smallest Suitable Design

K3s satisfies the above by using SQLite as its default datastore. When no --datastore-endpoint flag is supplied, the server opens the file /var/lib/rancher/k3s/server/db.sqlite directly. No separate etcd cluster is launched, removing the need for additional binaries, network ports, or quorum logic.

The server process holds the SQLite file open for the lifetime of the API server; all read and write operations are performed via the SQLite C API inside the same process.

Trust and Data Boundaries

The SQLite file is a regular file on the host filesystem. By default it is owned by root with mode 0600 (-rw-------), meaning only the user running the k3s server (typically root) can read or write it. No network socket is exposed, so the trust boundary is limited to the host’s local access controls.

If the file’s permissions are loosened (e.g., 0644), any local user could read the cluster state, including secrets stored in etcd‑like objects. Conversely, making the file unwritable by the k3s user prevents the server from starting.

Operational Checks

1. Verify the datastore in use

   Run on the host where k3s is executed:

   ps -ef | grep k3s

   Look for either the absence of an explicit --datastore-endpoint flag (default SQLite) or a line similar to:

   ... --datastore-endpoint='sqlite:///var/lib/rancher/k3s/server/db.sqlite'

   If a different endpoint appears, the node is not using the embedded SQLite store.

2. Check file ownership and permissions

   ls -l /var/lib/rancher/k3s/server/db.sqlite

   Expected output (ownership may vary if you run k3s as a non‑root user):

   -rw------- 1 root root 12M Sep 30 09:00 /var/lib/rancher/k3s/server/db.sqlite

   Anything more permissive than 0600 should be tightened with chmod 600 and chown root:root.

3. Run an integrity check

   Stop the k3s server temporarily (or use a read‑only copy) and execute:

   sqlite3 /var/lib/rancher/k3s/server/db.sqlite "PRAGMA integrity_check;"

   A healthy database returns the single word ok. Any other output indicates corruption and requires restore from backup.

4. Monitor size and vacuum

   SQLite does not automatically return freed pages to the filesystem. Periodic VACUUM can reclaim space:

   sqlite3 /var/lib/rancher/k3s/server/db.sqlite "VACUUM;"

   Schedule this during a maintenance window; the operation locks the database, so API requests will pause briefly.

Failure Modes and Design Triggers

• Disk‑full or I/O errors – If the partition holding db.sqlite runs out of space, the server will fail to start or crash with messages like database disk image is malformed. Monitoring free space on the mount point (e.g., df -h /var/lib/rancher/k3s) and alerting on <10% remaining is a practical guard.
• SQLite corruption – Power loss during a write can leave the file in an inconsistent state. The integrity check described above detects this; restoration requires copying a known‑good backup back to db.sqlite and ensuring correct permissions.
• Concurrent writers – SQLite supports multiple readers but only one writer at a time. Running two k3s server processes pointing to the same db.sqlite will lead to write conflicts and eventual corruption. This is why the embedded store is only suitable for a single‑node control plane.

When the Design Must Change

If any of the following conditions appear, migrate to an external datastore (etcd, MySQL, or PostgreSQL):

1. The cluster exceeds a few dozen nodes and the API server experiences sustained high write load (e.g., frequent pod scaling, heavy controller activity). SQLite’s write performance degrades noticeably under such workloads.
2. High‑availability is required. A single SQLite file cannot survive a node failure without shared storage; an external datastore provides replication and quorum.
3. Operational policies demand separation of the control plane from the host filesystem (e.g., immutable host images). Placing the datastore on a network‑mounted volume or external DB satisfies this.

To switch, start k3s with an explicit endpoint, for example:

k3s server \
  --datastore-endpoint='mysql://user:password@tcp(mysql-host:3306)/k3s' \
  --tls-san $(hostname)

Before changing, etcd‑snapshot or mysqldump the current SQLite file (after stopping the server) and import it into the target datastore following the vendor’s migration guide.

Practical Verification Checklist

• Confirm the server is using SQLite via ps output.
• Validate file permissions are 0600 (or appropriate for your runtime user).
• Run PRAGMA integrity_check; and expect ok.
• Monitor disk usage on the volume containing db.sqlite; set alerts for <10% free space.
• Review logs for messages containing database disk image is malformed or SQLITE_BUSY as early signs of trouble.
