Using Git Worktrees for Parallel Development: An Architecture Note

Problem

You need to work on a feature branch while an urgent hotfix must be prepared from the same local repository. Stashing changes or repeatedly cloning the repo adds overhead and risks losing work. You want independent working directories that share the same object store to avoid duplication.

Requirements

• Maintain multiple active contexts (e.g., feature and hotfix) without stashing.
• Avoid the disk and time cost of full clones.
• Keep a single source of truth for commits and objects.
• Allow each context to have its own HEAD, index, and working tree files.

Smallest Suitable Design

Git’s worktree feature satisfies these requirements. From an existing repository, run:

# From the repository root
mkdir -p /tmp/worktrees
cd /tmp/worktrees
# Create a worktree for the feature branch
git -C /path/to/repo worktree add feature-worktree feature
# Create a worktree for the hotfix branch
git -C /path/to/repo worktree add hotfix-worktree hotfix

Each worktree gets its own directory with a separate .git file that points back to the shared $GIT_DIR of the original repository. Internally:

• The shared object database (.git/objects) and packed‑refs are used by all worktrees.
• Each worktree has its own HEAD ref, index, and working‑tree files.
• Configuration is shared unless overridden with -c or a worktree‑specific config file.

Trust and Data Boundaries

All worktrees share the same ref namespace and object store. Consequently:

• A destructive operation such as git reset --hard or git gc --prune=now in one worktree can affect the reachability of objects used by another worktree.
• Repository‑level settings (e.g., core.autocrlf, receive.denyNonFastForwards) apply to every linked worktree unless explicitly overridden.
• The only per‑worktree isolation is the working tree files and the individual HEAD reference.

Operational Checks

1. List active worktrees: git worktree list. Verify each entry shows the correct branch and path.
2. Confirm the shared gitdir: from any worktree run git rev-parse --git-dir; the output should be the original repository’s .git directory.
3. Run integrity checks on the shared store periodically: git fsck --full (run from the main repository). Look for dangling commits or corrupted objects.
4. Never edit the .git file or HEAD file inside a worktree manually; let Git manage them.
5. Prune stale worktree entries after removing a directory: git worktree prune removes lock files and administrative data.

Failure Modes

• Accidental directory deletion: Removing a worktree folder with rm -rf leaves a lock file in $GIT_DIR/worktrees. Subsequent git worktree add may fail until the lock is cleared (git worktree prune or manual removal).
• Branch checkout conflict: Git prevents the same branch from being checked out in two worktrees simultaneously. Attempting to do so yields an error like "refusing to overwrite worktree file". Use git worktree add -B new-branch to create a fresh branch if needed.
• Garbage collection risk: Running git gc or git prune while another worktree holds uncommitted work can delete objects that are still referenced only by that worktree’s index, causing data loss.
• Stale lock accumulation: Long‑lived worktrees that are abandoned without git worktree remove leave lock files that accumulate over time.

Conditions That Would Change the Design

• Need for true isolation of refs (e.g., each team must have its own namespace). In that case, separate clones or a server‑side namespace (e.g., using git clone --shared with separate refs) would be required.
• CI pipelines that require ephemeral, disposable checkouts. Shallow clones (git clone --depth 1) or git worktree add --detach with a temporary directory are lighter weight.
• Extremely large monorepos where cloning the full object store is prohibitive. Sparse‑checkout (git sparse-checkout init --cone) or partial clones (git clone --filter=blob:none) reduce data transfer, and worktrees can still be built on top of those.
• Environments running Git older than 2.5, where linked worktrees are not available. The fallback is to maintain separate clones.

Practical Verification

To confirm that a worktree is correctly linked:

1. Create a worktree: git -C /path/to/repo worktree add /tmp/test-wt dev.
2. From the worktree, check the gitdir: git -C /tmp/test-wt rev-parse --git-dir should output something like /path/to/repo/.git.
3. List worktrees: git worktree list should show an entry for /tmp/test-wt with the dev branch.
4. Make a change in the worktree, commit it, and verify that the commit appears in the main repository’s log: git -C /path/to/repo log --oneline -1.
5. Remove the worktree cleanly: git worktree remove /tmp/test-wt. Afterwards, git worktree list no longer lists the path, and ls $GIT_DIR/worktrees shows no leftover lock for that entry.

These steps provide confidence that the shared object store is intact and that the worktree mechanism is behaving as expected.
