Using Fortran allocatable arrays: allocation, use, and safe deallocation

Using Fortran allocatable arrays

To change the size of an array during program execution, declare it with the allocatable attribute, then use the allocate statement to bind storage to the desired shape. After the array is no longer needed, call deallocate to return the memory to the system. This three‑step pattern lets you work with arrays whose dimensions are only known at run time.

Example: allocating a two‑dimensional real array

program allocatable_example
  implicit none
  real, allocatable :: mat(:,:)
  integer :: n, m, i, j
  n = 100
  m = 50
  allocate(mat(n,m))
  do i = 1, n
     do j = 1, m
        mat(i,j) = real(i*j)
     end do
  end do
  print *, 'Sum of all elements = ', sum(mat)
  deallocate(mat)
end program allocatable_example

The allocate statement creates storage whose bounds match the expressions n and m. If either expression is negative or not an integer, most compilers will abort at runtime; a zero‑size extent is allowed by the standard but some implementations treat it as an error, so verify the size before calling allocate. After deallocate the array becomes undefined; any further reference (including as a dummy argument or in I/O) must be preceded by another allocate that specifies new bounds.

Limits and common mistakes

• Missing the allocatable attribute in the type declaration leads to a compile‑time error when allocate is encountered.
• Using an unallocated array (e.g., passing it to a subroutine or printing it) causes a runtime error or undefined behavior.
• Calling allocate on an already allocated array without first deallocating it (unless you use the source= or mold= options) results in a runtime error.
• Providing a shape expression that does not match the declared rank (e.g., allocating a vector with two bounds) triggers a compile‑time mismatch.
• Assuming that deallocation automatically resets the array to a known state; after deallocate the array is undefined and must be re‑allocated before use.

Verification and practical checks

Compile the example with checking enabled:

gfortran -fcheck=all -O2 allocatable_example.f90 -o alloc_example

Run the executable; if the program prints a sum and terminates without a runtime error, the allocation and deallocation succeeded. To confirm that the compiler actually emitted calls to the runtime allocation routines, you can inspect the intermediate representation:

gfortran -fdump-tree-all -O2 allocatable_example.f90 2>&1 | grep -i allocate

Look for lines that contain allocate and deallocate in the dump; their presence indicates the statements were not optimized away.

As a quick sanity check, you can add a conditional that prints the shape after allocation:

print *, 'Allocated shape = ', shape(mat)

If the program stops with an allocation error, verify that n and m are non‑negative integers before the allocate statement.
