Diagnosing Fortran Array Bounds Violations Across gfortran, ifort, and nvfortran

Recognizable Conditions

When a Fortran program fails with a segmentation fault (SIGSEGV), prints a runtime error such as Array reference out of bounds, or produces incorrect results without crashing, the most likely culprit is an array bounds violation. The symptom may vary depending on the compiler and the platform:

• Crash – often a SIGSEGV or a core dump.
• Runtime error – e.g., Runtime error: Array reference out of bounds when bounds checking is enabled.
• Silent corruption – wrong values appear in output or later calculations.

All three major Fortran compilers – gfortran, ifort (Intel LLVM), and nvfortran – provide bounds‑checking options, but the exact flags and diagnostic output differ slightly.

Causes & Diagnostic Table

Cause	Typical Symptom	Diagnostic Hint
Explicit index exceeds declared dimension	Crash or runtime error	Check loop bounds; use LBOUND/UBOUND
Assumed‑shape dummy argument mismatch	Runtime error when callee expects larger array	Verify caller’s actual size vs dummy’s shape
Unallocated pointer/allocatable array accessed	Segfault or garbage data	Check ALLOCATED() before use
C interoperability writes past bounds	Crash or data corruption	Confirm C array size and layout matches Fortran expectations
Automatic array exceeds stack limit	Segfault or stack‑overflow message	Move to ALLOCATABLE or increase stack size
Coarray index out of image bounds	Hang or MPI error	Guard indices with THIS_IMAGE() and NUM_IMAGES()

Ordered Checks

1. Enable bounds checking

   Recompile with:

   # gfortran / nvfortran
   gfortran -fcheck=bounds -fbacktrace prog.f90

   # Intel LLVM (ifort/ifx)
   ifort -check bounds -traceback prog.f90


   Run the program again. A bounds error will now point to the offending line.

2. Add backtrace / traceback

   These flags provide a call stack that shows how the offending line was reached, which is crucial if the error occurs in a subroutine called from many places.

3. Use a sanitizer

   Compile with AddressSanitizer to catch heap and stack overflows that bounds checking might miss:

   # gfortran / nvfortran
   gfortran -fsanitize=address -fno-omit-frame-pointer prog.f90

   # Intel LLVM
   ifort -fsanitize=address -fno-omit-frame-pointer prog.f90


   Run under ASAN_OPTIONS=detect_stack_use_after_return=1 to catch post‑deallocation use.

4. Validate caller‑callee interfaces

   For assumed‑shape arguments, ensure the caller provides an explicit interface (module or interface block) and that the actual array’s bounds satisfy the dummy’s shape. Missing interfaces can silence bounds errors.

5. Check allocation status

   Before accessing a pointer or allocatable array, insert:

   if (.not. ALLOCATED(ptr)) then
     print *, "Pointer not allocated"
     stop
   end if


6. Review OpenMP/coarray regions

   When using SIMD or parallel directives, speculative loads can cross array ends. Use compiler‑specific pragmas (e.g., !$OMP SIMD SAFELEN) or disable vectorization for critical loops.

Fixes Tied to Findings

• Incorrect loop bounds – Replace hard‑coded limits with LBOUND(array) or UBOUND(array).
• Assumed‑shape mismatch – Change dummy to (:) or provide an explicit interface that matches the caller’s actual bounds.
• Unallocated array – Add ALLOCATE(array(n)) or ALLOCATE(array, SOURCE=initial) before first use.
• C interop overflow – Use ISO_C_BINDING to bind C pointers and verify the C side’s size. Convert Fortran arrays to C contiguous order with column-major vs row-major awareness.
• Stack overflow – Replace large automatic arrays with ALLOCATABLE or increase the OS stack limit with ulimit -s.
• Coarray index out of bounds – Guard with if (idx <= UBOUND(array,1) .and. idx >= LBOUND(array,1)) and use THIS_IMAGE() to avoid out‑of‑image accesses.

Escalation Criteria

Condition	Escalate To
Bounds checking passes but sanitizer reports a heap overflow	Suspect ABI mismatch or compiler bug; file minimal reproducible example with vendor.
Silent corruption persists across compilers	Introduce assertions on indices; review algorithm logic.
Stack overflow only occurs at large problem sizes	Redesign memory layout; consider module‑level ALLOCATABLE arrays or SAVE attribute.
Coarray errors manifest as hangs	Enable -fcoarray=lib for better diagnostics or switch to MPI if appropriate.

Practical Example

Below is a minimal program that deliberately writes past the end of an array. Compile with bounds checking and observe the error.

program out_of_bounds
  implicit none
  integer, dimension(5) :: a
  integer :: i

  do i = 1, 6  ! Off‑by‑one bug
    a(i) = i
  end do
end program

Compile:

# gfortran -fcheck=bounds -fbacktrace prog.f90 -o prog

Run:

$ ./prog
Runtime error: Array reference out of bounds
  at line 6 column 5 of file out_of_bounds.f90
  at line 6 column 5 of file out_of_bounds.f90
  at line 6 column 5 of file out_of_bounds.f90
...  (stack trace)

Notice the line number and file name. If you had a subroutine, the backtrace would show the chain of calls that led to the error.

Limitations & Practical Checks

• Bounds checking only detects violations that actually occur at runtime; it will not catch logic errors where indices stay within bounds but are semantically wrong.
• Assumed‑size arrays ((*)) and assumed‑rank arrays ((..)) disable bounds checking for the affected dimension. Prefer assumed‑shape ((:)) with an explicit interface.
• Automatic arrays in recursive procedures can overflow the stack before bounds checking triggers. Test with ulimit -s and move large arrays to ALLOCATABLE if needed.
• Coarray diagnostics may be less clear on older compilers; use -fcoarray=lib for enhanced error messages.
• On GPU offload (nvfortran), bounds checking is available for host code but may require -Mbounds on device kernels.

To verify that a fix works, recompile with bounds checking enabled and confirm that the program no longer crashes and that the output matches expected values. For silent corruption, add runtime assertions or print statements to confirm data integrity.

Compiler‑Specific Notes

• gfortran – -fcheck=all enables bounds, do‑loop, and memory checks. Use -fbacktrace for stack traces.
• Intel LLVM (ifort/ifx) – -check all covers bounds, format, and output conversion. -traceback provides a stack trace.
• nvfortran – -Mbounds activates host bounds checking; -Minfo=all gives additional diagnostics.

Bounds checking typically incurs a 2–10× slowdown. In production builds, disable it via build profiles and rely on static analysis and unit tests to catch the same errors earlier.
