Traces For Kubernetes System Components

Feature state: Beta since Kubernetes v1.27

System component traces record the latency of and relationships between operations in the cluster.

Kubernetes components emit traces using the OpenTelemetry Protocol with the gRPC exporter and can be collected and routed to tracing backends using an OpenTelemetry Collector.

Trace Collection

Kubernetes components have built-in gRPC exporters for OTLP to export traces, either with an OpenTelemetry Collector, or without an OpenTelemetry Collector.

For a complete guide to collecting traces and using the collector, see Getting Started with the OpenTelemetry Collector. However, there are a few things to note that are specific to Kubernetes components.

By default, Kubernetes components export traces using the grpc exporter for OTLP on the IANA OpenTelemetry port, 4317. As an example, if the collector is running as a sidecar to a Kubernetes component, the following receiver configuration will collect spans and log them to standard output:

receivers:
  otlp:
    protocols:
      grpc:
exporters:
  # Replace this exporter with the exporter for your backend
  exporters:
    debug:
      verbosity: detailed
service:
  pipelines:
    traces:
      receivers: [otlp]
      exporters: [debug]

To directly emit traces to a backend without utilizing a collector, specify the endpoint field in the Kubernetes tracing configuration file with the desired trace backend address. This method negates the need for a collector and simplifies the overall structure.

For trace backend header configuration, including authentication details, environment variables can be used with OTEL_EXPORTER_OTLP_HEADERS, see OTLP Exporter Configuration.

Additionally, for trace resource attribute configuration such as Kubernetes cluster name, namespace, Pod name, etc., environment variables can also be used with OTEL_RESOURCE_ATTRIBUTES, see OTLP Kubernetes Resource.

Component traces

kube-apiserver traces

The kube-apiserver generates spans for incoming HTTP requests, and for outgoing requests to webhooks, etcd, and re-entrant requests. It propagates the W3C Trace Context with outgoing requests but does not make use of the trace context attached to incoming requests, as the kube-apiserver is often a public endpoint.

Enabling tracing in the kube-apiserver

To enable tracing, provide the kube-apiserver with a tracing configuration file with --tracing-config-file=<path-to-config>. This is an example config that records spans for 1 in 10000 requests, and uses the default OpenTelemetry endpoint:

apiVersion: apiserver.config.k8s.io/v1
kind: TracingConfiguration
# default value
#endpoint: localhost:4317
samplingRatePerMillion: 100

For more information about the TracingConfiguration struct, see API server config API (v1).

kubelet traces

Feature state: Stable since Kubernetes v1.34More information about this feature

This is a stable feature in Kubernetes, and has been since version v1.34. It was first available in the v1.25 release. You can no longer disable or opt out of this feature or behavior (it is locked); if you explicitly set a value for the associated feature gate KubeletTracing, Kubernetes ignores it but does not report any error.

The kubelet CRI interface and authenticated http servers are instrumented to generate trace spans. As with the apiserver, the endpoint and sampling rate are configurable. Trace context propagation is also configured. A parent span's sampling decision is always respected. A provided tracing configuration sampling rate will apply to spans without a parent. Enabled without a configured endpoint, the default OpenTelemetry Collector receiver address of "localhost:4317" is set.

Enabling tracing in the kubelet

To enable tracing, apply the tracing configuration. This is an example snippet of a kubelet config that records spans for 1 in 10000 requests, and uses the default OpenTelemetry endpoint:

apiVersion: kubelet.config.k8s.io/v1beta1
kind: KubeletConfiguration
tracing:
  # default value
  #endpoint: localhost:4317
  samplingRatePerMillion: 100

If the samplingRatePerMillion is set to one million (1000000), then every span will be sent to the exporter.

The kubelet in Kubernetes v1.37 collects spans from the garbage collection, pod synchronization routine as well as every gRPC method. The kubelet propagates trace context with gRPC requests so that container runtimes with trace instrumentation, such as CRI-O and containerd, can associate their exported spans with the trace context from the kubelet. The resulting traces will have parent-child links between kubelet and container runtime spans, providing helpful context when debugging node issues.

Please note that exporting spans always comes with a small performance overhead on the networking and CPU side, depending on the overall configuration of the system. If there is any issue like that in a cluster which is running with tracing enabled, then mitigate the problem by either reducing the samplingRatePerMillion or disabling tracing completely by removing the configuration.

Stability

Tracing instrumentation is still under active development, and may change in a variety of ways. This includes span names, attached attributes, instrumented endpoints, etc. Until this feature graduates to stable, there are no guarantees of backwards compatibility for tracing instrumentation.
