Node Declared Features

Feature state: Stable since Kubernetes v1.37More information about this feature

This is a stable feature in Kubernetes, and has been since version v1.37. It was first available in the v1.35 release. You can no longer disable or opt out of this feature or behavior (it is locked); if you explicitly set a value for the associated feature gate NodeDeclaredFeatures, Kubernetes ignores it but does not report any error.

Kubernetes nodes use declared features to report the availability of specific features that are new or feature-gated. Control plane components use this information to make better decisions. The kube-scheduler, via the NodeDeclaredFeatures plugin, ensures Pods are only placed on nodes that explicitly support the features the Pod requires. Additionally, the NodeDeclaredFeatureValidator admission controller validates Pod updates against a node's declared features.

This mechanism helps manage version skew and improve cluster stability, especially during cluster upgrades or in mixed-version environments where nodes might not all have the same features enabled. This is intended for Kubernetes feature developers introducing new node-level features and works in the background; application developers deploying Pods do not need to interact with this framework directly.

How it works

A declared feature is a string that a node lists in the .status.declaredFeatures field of the Node object. Each declarable feature identifies a node-level feature that is still graduating through the Kubernetes feature stages.

1. Kubelet Feature Reporting: At startup, the kubelet on each node detects which managed Kubernetes features are currently enabled and reports them in the .status.declaredFeatures field of the Node. Only features under active development are included in this field.

2. Scheduler Filtering: The default kube-scheduler uses the NodeDeclaredFeatures plugin. This plugin:

   • In the PreFilter stage, checks the PodSpec to infer the set of node features required by the Pod.
   • In the Filter stage, checks if the features listed in the node's .status.declaredFeatures satisfy the requirements inferred for the Pod. Pods are not scheduled onto nodes that lack the required features.

   Custom schedulers can also use the .status.declaredFeatures field to enforce similar constraints.

3. Admission Control: The NodeDeclaredFeatureValidator admission controller can reject Pods that require features not declared by the node they are bound to, preventing issues during Pod updates.

4. Kubelet Admission: As a final safeguard, the kubelet re-checks a Pod's feature requirements against the features available on its node before running the Pod, and rejects the Pod if a required feature is missing.

5. Post-GA Cleanup: Once a feature is available on all nodes of a cluster (after the feature graduates to GA and the supported version skew between the control plane and nodes has passed), nodes stop declaring the feature. This is achieved by setting a maximum version (MaxVersion) for each declared feature: kubelets newer than this version stop listing the feature in .status.declaredFeatures, and the scheduler and the admission controller treat the feature as universally available and stop checking for it. The feature is eventually removed from the set of declared features as part of the standard post-GA feature cleanup.

Example of a declared feature

The RestartAllContainersOnContainerExits declared feature indicates that a node supports in-place restarts of all containers in a Pod. When the RestartAllContainersOnContainerExits feature gate is enabled for the kubelet, the kubelet declares this feature in the status of its Node:

apiVersion: v1
kind: Node
metadata:
  name: example-node
status:
  declaredFeatures:
  - RestartAllContainersOnContainerExits

A Pod requires this feature if one of its containers specifies a restart rule with the RestartAllContainers action:

apiVersion: v1
kind: Pod
metadata:
  name: example-pod
spec:
  containers:
  - name: main
    image: registry.k8s.io/busybox:1.27.2
    restartPolicy: Never     # Container restart policy must be specified if rules are specified
    restartPolicyRules:      # Restart the whole Pod in place on exit code 42
    - action: RestartAllContainers
      exitCodes:
        operator: In
        values: [42]

When scheduling this Pod, the kube-scheduler only considers nodes that list RestartAllContainersOnContainerExits in their .status.declaredFeatures. In a cluster where only some nodes have that feature gate enabled (for example, part way through a cluster upgrade), this prevents the Pod from being assigned to a node whose kubelet would ignore the restart rule.

Declared features also gate updates to running Pods. For example, the InPlacePodVerticalScalingInitContainers declared feature indicates that a node supports resizing the resources of init containers in place. If there is an attempt to resize an init container in a running Pod, the NodeDeclaredFeatureValidator admission controller rejects the update unless the node running that Pod declares this feature.
