Run a Node.js Application in PM2 Cluster Mode for Better Performance and Fault Tolerance

Desired outcome

Start a Node.js application with PM2 in cluster mode so that multiple worker processes share the workload, use all available CPU cores, and are automatically restarted if they crash.

Prerequisites

• Node.js (v14 or later) installed.
• PM2 installed globally (npm install -g pm2).
• Application code that is stateless or relies on an external store (e.g., Redis, database) for session data.
• Basic familiarity with running a Node.js app via node app.js.

Procedure

1. Navigate to your project directory

   cd /path/to/your-node-app

2. Start the app in cluster mode

   Use the -i flag to specify the number of instances. max tells PM2 to fork one worker per CPU core.

   pm2 start app.js -i max --name my-app

   Replace app.js with your entry file. The --name option gives the process set a friendly identifier.

3. Optional: Declare instances in an ecosystem file

   Create ecosystem.config.js:

   module.exports = {
     apps : [{
       name   : 'my-app',
       script : 'app.js',
       instances : 'max',
       exec_mode : 'cluster'
     }]
   };


   Then start with:

   pm2 start ecosystem.config.js

Expected checks

• Verify instance count

  pm2 list

  The Online column should show the number of workers you requested (e.g., 4 on a quad‑core machine).

• Monitor resource usage

  pm2 monit

  Watch CPU and memory per worker; look for any process that repeatedly exits and restarts.

• Inspect logs

  pm2 logs my-app --lines 50

  Ensure there are no error spikes shortly after startup. Logs from all workers are aggregated; you can view a specific worker with pm2 show <id>.

Recovery options

• Automatic restart

  If a worker crashes, PM2 will respawn it to maintain the desired instance count.

• Manual scaling

  Increase or decrease workers without downtime:

  pm2 scale my-app 6   # scale to six instances
  pm2 scale my-app 2   # scale back to two

• Stop and delete

  To revert the changes made by starting the app:

  pm2 stop my-app
  pm2 delete my-app

  This removes the process set from PM2’s process list.

Limitations and practical verification

• The application must externalize any in‑memory state (e.g., session caches) to a shared store; otherwise each worker will have its own copy, leading to inconsistent behavior.
• Memory usage roughly scales with the number of workers; ensure sufficient RAM to avoid swapping.
• Verify that libraries you use are cluster‑aware or do not rely on single‑process globals.
