Zero-Downtime Reloads with PM2 Cluster Mode: Signals, Timeouts, and the wait_ready Flag

The problem: deployments that drop in-flight requests

When a Node.js service restarts, the operating system closes the listening socket. Any request that arrives during the restart window gets a connection-refused error. PM2’s cluster mode solves this by keeping a master process alive and replacing workers one at a time, but only if the application cooperates with the signals PM2 sends.

How PM2 orchestrates a graceful reload

In cluster mode, PM2 uses Node’s built-in cluster module. The master holds the TCP port and forks N workers (where N is the instances value in the ecosystem file). A reload proceeds as follows:

1. The master picks a worker and sends a SIGINT signal.
2. The worker has a grace period (default 1.6s, configurable via kill_timeout) to finish current work, close its HTTP server, and exit.
3. If the worker is still alive after the grace period, the master sends SIGKILL to force termination.
4. The master spawns a fresh worker. When wait_ready is enabled, the new worker must call process.send('ready') before PM2 marks it healthy and routes traffic to it.
5. These steps repeat for each worker until the entire cluster is updated.

Because the master never releases the port, new connections are always accepted by at least one healthy worker.

Key configuration knobs

Option	Purpose	Typical Value
exec_mode: 'cluster'	Enables multi-worker mode	Required for zero-downtime
instances: 'max'	Fork one worker per CPU core	'max' or a number
wait_ready: true	Wait for explicit ready message	true
listen_timeout: 5000	Max ms to wait for ready before kill	5000–10000
kill_timeout: 3000	Grace period after SIGINT before SIGKILL	3000–10000
max_memory_restart: '200M'	Restart worker when heap exceeds limit	Optional

These settings are defined in the ecosystem.config.js file to ensure behavior is reproducible across environments.

Worked example: Express app that signals readiness

// ecosystem.config.js
module.exports = {
  apps: [{
    name: 'api',
    script: 'server.js',
    exec_mode: 'cluster',
    instances: 'max',
    wait_ready: true,
    listen_timeout: 8000,
    kill_timeout: 5000,
    env: { NODE_ENV: 'production' }
  }]
};

// server.js
const express = require('express');
const app = express();

app.get('/health', (req, res) => res.send('ok'));

const server = app.listen(process.env.PORT || 3000, () => {
  console.log(`Worker ${process.pid} listening`);
  // Tell PM2 this worker is ready to receive traffic
  if (process.send) process.send('ready');
});

// Graceful shutdown on SIGINT
process.on('SIGINT', () => {
  console.log(`Worker ${process.pid} received SIGINT`);
  server.close(() => {
    console.log('HTTP server closed');
    process.exit(0);
  });
  // Force exit if close takes too long
  setTimeout(() => process.exit(1), 4000);
});

To deploy this configuration, run the following on the target host (requires global PM2 installation):

pm2 start ecosystem.config.js

Trigger a zero-downtime reload after updating your code:

pm2 reload api --update-env

Verify the transition by watching the logs:

pm2 logs api --lines 50

You should see each worker log received SIGINT, then HTTP server closed, followed by a new worker PID printing listening and sending ready.

Trade-offs and limitations

• Application Signal Handling: If your code ignores SIGINT, in-flight requests are dropped when the worker is eventually killed by SIGKILL.
• Sticky Sessions and WebSockets: PM2 does not migrate live sockets between workers. Use an external load balancer with sticky routing or the pm2-websocket module for WebSocket affinity.
• wait_ready Deadlock: If the application fails to send ready (e.g., due to a startup crash), the reload hangs until listen_timeout expires, which may cause a brief outage.
• Native Addons: Some C++ addons are not fork-safe; each worker loads its own copy, which increases memory usage and can break global state.
• Master SPOF: The PM2 master is a single point of failure. If it crashes, workers become orphaned. Use pm2 startup to generate a systemd/launchd unit to ensure the master restarts automatically.

Actionable closing checklist

1. Implement process.on('SIGINT', ...) and process.send('ready') in your entry point.
2. Set wait_ready: true and a sensible listen_timeout in ecosystem.config.js.
3. Run pm2 reload <app> --update-env and verify via pm2 logs that workers exit cleanly.
4. Confirm cluster mode and timeouts are active using pm2 show <app>.
5. Execute pm2 startup and check the generated unit (e.g., systemctl cat pm2-user) to ensure master resilience.
