Recommended Labels

You can visualize and manage Kubernetes objects with more tools than kubectl and the dashboard. A common set of labels allows tools to work interoperably, describing objects in a common manner that all tools can understand.

In addition to supporting tooling, the recommended labels describe applications in a way that can be queried.

The metadata is organized around the concept of an application. Kubernetes is not a platform as a service (PaaS) and doesn't have or enforce a formal notion of an application. Instead, applications are informal and described with metadata. The definition of what an application contains is loose.

Note:

These are recommended labels. They make it easier to manage applications but aren't required for any core tooling.

Shared labels and annotations share a common prefix: app.kubernetes.io. Labels without a prefix are private to users. The shared prefix ensures that shared labels do not interfere with custom user labels.

Labels

In order to take full advantage of using these labels, they should be applied on every resource object.

Key	Description	Example	Type
app.kubernetes.io/name	The name of the application	mysql	string
app.kubernetes.io/instance	A unique name identifying the instance of an application	mysql-abcxyz	string
app.kubernetes.io/version	The current version of the application (e.g., a SemVer 1.0, revision hash, etc.)	5.7.21	string
app.kubernetes.io/component	The component within the architecture	database	string
app.kubernetes.io/part-of	The name of a higher level application this one is part of	wordpress	string
app.kubernetes.io/managed-by	The tool being used to manage the operation of an application	Helm	string

To illustrate these labels in action, consider the following StatefulSet object:

# This is an excerpt
apiVersion: apps/v1
kind: StatefulSet
metadata:
  labels:
    app.kubernetes.io/name: mysql
    app.kubernetes.io/instance: mysql-abcxyz
    app.kubernetes.io/version: "5.7.21"
    app.kubernetes.io/component: database
    app.kubernetes.io/part-of: wordpress
    app.kubernetes.io/managed-by: Helm

Applications And Instances Of Applications

An application can be installed one or more times into a Kubernetes cluster and, in some cases, the same namespace. For example, WordPress can be installed more than once where different websites are different installations of WordPress.

The name of an application and the instance name are recorded separately. For example, WordPress has a app.kubernetes.io/name of wordpress while it has an instance name, represented as app.kubernetes.io/instance with a value of wordpress-abcxyz. This enables the application and instance of the application to be identifiable. Every instance of an application must have a unique name.

Examples

To illustrate different ways to use these labels the following examples have varying complexity.

A Simple Stateless Service

Consider the case for a simple stateless service deployed using Deployment and Service objects. The following two snippets represent how the labels could be used in their simplest form.

The Deployment is used to oversee the pods running the application itself.

apiVersion: apps/v1
kind: Deployment
metadata:
  labels:
    app.kubernetes.io/name: myservice
    app.kubernetes.io/instance: myservice-abcxyz
...

The Service is used to expose the application.

apiVersion: v1
kind: Service
metadata:
  labels:
    app.kubernetes.io/name: myservice
    app.kubernetes.io/instance: myservice-abcxyz
...

Web Application With A Database

Consider a slightly more complicated application: a web application (WordPress) using a database (MySQL), installed using Helm. The following snippets illustrate the start of objects used to deploy this application.

The start to the following Deployment is used for WordPress:

apiVersion: apps/v1
kind: Deployment
metadata:
  labels:
    app.kubernetes.io/name: wordpress
    app.kubernetes.io/instance: wordpress-abcxyz
    app.kubernetes.io/version: "4.9.4"
    app.kubernetes.io/managed-by: Helm
    app.kubernetes.io/component: server
    app.kubernetes.io/part-of: wordpress
...

The Service is used to expose WordPress:

apiVersion: v1
kind: Service
metadata:
  labels:
    app.kubernetes.io/name: wordpress
    app.kubernetes.io/instance: wordpress-abcxyz
    app.kubernetes.io/version: "4.9.4"
    app.kubernetes.io/managed-by: Helm
    app.kubernetes.io/component: server
    app.kubernetes.io/part-of: wordpress
...

MySQL is exposed as a StatefulSet with metadata for both it and the larger application it belongs to:

apiVersion: apps/v1
kind: StatefulSet
metadata:
  labels:
    app.kubernetes.io/name: mysql
    app.kubernetes.io/instance: mysql-abcxyz
    app.kubernetes.io/version: "5.7.21"
    app.kubernetes.io/managed-by: Helm
    app.kubernetes.io/component: database
    app.kubernetes.io/part-of: wordpress
...

The Service is used to expose MySQL as part of WordPress:

apiVersion: v1
kind: Service
metadata:
  labels:
    app.kubernetes.io/name: mysql
    app.kubernetes.io/instance: mysql-abcxyz
    app.kubernetes.io/version: "5.7.21"
    app.kubernetes.io/managed-by: Helm
    app.kubernetes.io/component: database
    app.kubernetes.io/part-of: wordpress
...

With the MySQL StatefulSet and Service you'll notice information about both MySQL and WordPress, the broader application, are included.
