ReadTheDocs v2 Configuration: Pinning Builds, Adding Formats, and Migrating from Legacy YAML

Why the v2 config matters

The single most useful change you can make today is to add a .readthedocs.yaml file with version: 2 at the top. This pins the build image, Python interpreter, and output formats so every build — local or on ReadTheDocs — produces identical artifacts. The legacy .readthedocs.yml is still parsed for backward compatibility, but mixing the two files creates undefined precedence and should be avoided.

Worked example: a minimal Sphinx project

Place the following file at the repository root (or in a subdirectory if you run a monorepo). It selects Ubuntu 22.04, Python 3.11, installs dependencies from docs/requirements.txt, runs Sphinx, and emits HTML, PDF, and EPUB.

version: 2
build:
  os: ubuntu-22.04
  tools:
    python: "3.11"
  jobs:
    post_create_environment:
      - pip install -r docs/requirements.txt
    post_install:
      - cd docs && sphinx-build -b html . _build/html
formats:
  - pdf
  - epub

Key fields:

• build.os – chooses the build image (ubuntu-22.04 or ubuntu-20.04).
• build.tools.python – pins the interpreter; major.minor (e.g., 3.11) or a Miniconda specifier (miniconda3-4.12.0). Omitting this defaults to the platform Python, which varies by image and breaks reproducibility.
• build.jobs.post_create_environment – runs before the default pip install -r requirements.txt from the repo root. Use it for system‑level setup or to install a private index.
• build.jobs.post_install – runs after the root pip install. If your docs live in a subdirectory, cd explicitly (as shown) or invoke python -m pip install -r docs/requirements.txt.
• formats – adds PDF and EPUB output; HTML is always built.

Using conda for system dependencies

When you need non‑Python packages (e.g., graphviz, texlive), prefer the conda: section over the legacy apt_packages list. Conda environments are reproducible locally and on the build servers.

build:
  os: ubuntu-22.04
  tools:
    python: "3.11"
  conda:
    environment: docs/environment.yml
  jobs:
    post_install:
      - cd docs && sphinx-build -b html . _build/html
formats:
  - pdf

The referenced docs/environment.yml might contain:

name: docs-env
channels:
  - conda-forge
dependencies:
  - python=3.11
  - sphinx
  - graphviz
  - texlive-core
  - pip
  - pip:
    - -r requirements.txt

Run conda env create -f docs/environment.yml locally to verify the exact package set before pushing.

Environment variables injected at build time

ReadTheDocs injects several variables you can read in conf.py for version‑aware content:

• READTHEDOCS_VERSION_NAME – the version label (branch name, tag, or latest).
• READTHEDOCS_VERSION_TYPE – branch, tag, or external.
• READTHEDOCS_GIT_COMMIT_HASH – full SHA of the commit being built.
• READTHEDOCS – set to True only during the build; not present in the hosted HTML.

Example conf.py snippet:

import os
version_name = os.environ.get('READTHEDOCS_VERSION_NAME', 'local')
html_title = f"My Project – {version_name}"

These variables are not available to client‑side JavaScript, so any runtime feature detection must be baked into the generated HTML.

Monorepo support

Each subproject gets its own .readthedocs.yaml placed in its directory. In the dashboard, set the project's Configuration file path to that file (e.g., subproject-a/.readthedocs.yaml). The dashboard accepts only one config file per project, so you create a separate ReadTheDocs project for each subproject.

Pull‑request previews

Previews are enabled by default for connected GitHub/GitLab/Bitbucket repos. On every push to a PR branch, ReadTheDocs builds the docs and serves them at a unique URL like https://--pr-42--myproject.readthedocs.io. These builds do not create permanent versions; they disappear when the PR is closed or merged.

Limits and common mistakes

Legacy file conflict

If both .readthedocs.yml and .readthedocs.yaml exist, ReadTheDocs may read either with undefined precedence. Delete the old .yml after migration.

Missing cd in post_install

The default pip install -r requirements.txt runs from the repository root. Forgetting to change directory causes Sphinx to look for conf.py in the wrong place and the build fails with conf.py not found.

PDF build timeout

The Ubuntu 22.04 image includes TeX Live, but large font packages or complex LaTeX can exceed the 15‑minute build timeout. Trim font packages or split the PDF build into a separate job if you hit this limit.

Changing build.os or build.tools.python

Any change to these fields invalidates the cached environment. The next build will be slower because it provisions a fresh container. Plan such changes during a low‑traffic window.

Environment variables not in hosted HTML

READTHEDOCS and the version variables exist only during the build. Do not write JavaScript that checks process.env.READTHEDOCS — it will always be undefined in the browser.

Verification checklist

1. Create a test repo with the minimal v2 config above. Push to GitHub/GitLab.
2. Import the repo on readthedocs.org (or your self‑hosted instance).
3. Confirm v2 parsing – the build log should show lines like:

   Using config file: .readthedocs.yaml
   Version: 2


4. Check artifacts – after a successful build, open the version’s “Downloads” section; PDF and EPUB files must be present.
5. Inspect injected vars – add import os; print(os.environ.get('READTHEDOCS_VERSION_NAME')) to conf.py, rebuild, and verify the value appears in the build output.
6. Test PR preview – open a pull request; a unique preview URL should be generated and serve the built docs.
7. Validate conda reproducibility – run conda env create -f docs/environment.yml locally, then compare conda list output with the build log’s conda package list.

Rollback note

Changing the config file does not mutate persistent state beyond the next build. If a new config breaks the build, revert the commit containing .readthedocs.yaml and push; the next build will use the previous working configuration.
