Preventing Dimensional Errors in F#: Units of Measure vs. Wrapper Types

The Cost of Dimensional Mismatches

In engineering and financial applications, a common source of critical bugs is the "primitive obsession" where different physical quantities—such as meters and feet, or kilograms and grams—are all represented as float. When a developer accidentally adds a value in meters to a value in feet, the compiler accepts the operation because both are floating-point numbers, leading to silent calculation errors.

The goal is to ensure that mass + time or meters + seconds results in a compile-time error rather than a runtime failure. In F#, you have two primary paths: using the built-in [<Measure>] attribute or creating custom wrapper types (Single-Case Discriminated Unions).

Comparing Safety and Performance

The following table compares the two most common strategies for enforcing dimensional safety in F# 5.0+ on .NET 6/7/8.

Feature	Units of Measure ([<Measure>])	Wrapper Types (SCDU)
Runtime Overhead	Zero (Erased at compile time)	Low (Boxing/Unwrapping cost)
Compile-time Safety	Strong (Prevents mismatched math)	Strong (Prevents mismatched types)
C# Interop	Seen as raw float/decimal	Seen as a distinct class/struct
Reflection	Unit labels are invisible	Type names are preserved
Arithmetic	Native operators (+, -, *, /)	Requires custom operator overloading

Trade-offs and Decision Logic

When to use Units of Measure

Use [<Measure>] when your primary concern is mathematical correctness and performance. Because the F# compiler erases these labels during compilation, there is no memory or CPU penalty. This is the ideal choice for high-frequency calculations or physics engines where you need the speed of a float but the safety of a type system.

When to use Wrapper Types

Use a Single-Case Discriminated Union (SCDU), such as type Kilograms = Kilograms of float, when the unit must survive the boundary of the F# project. If a C# project consumes your library, [<Measure>] provides no protection; the C# developer will see only a double. A wrapper type forces the C# consumer to explicitly handle the unit, preventing errors across language boundaries.

Implementation: Units of Measure

To implement units of measure, define the dimensions first. These act as labels for the compiler. You can then tag literals or variables using the <unit> syntax.

// Define the measures
type [<Measure>] m
type [<Measure>] s
type [<Measure>] kg

// Assign units to values
let distance = 10.0<m>
let time = 2.0<s>
let mass = 5.0<kg>

// Valid: Result is automatically calculated as m/s
let velocity = distance / time

// INVALID: This will trigger compiler error FS0001
// let error = distance + mass

Validation and Verification

To verify that your dimensional constraints are working, you can use the F# Interactive (dotnet fsi) tool or a standard build process:

1. Compile-time check: Attempt to add two different measures (e.g., 1.0<m> + 1.0<s>). The build must fail with a type mismatch error.
2. Runtime check: Use a debugger or printfn "%f" velocity to confirm the value is treated as a standard float.
3. Interop check: If using a C# project, reference the F# assembly and inspect the velocity property. It will appear as a double, confirming that the measure was erased.

Limitations and Risks

• API Boundaries: Units of measure are not enforced when reading from a JSON API or a database. You must manually validate or cast the raw input into the measured type at the edge of your system.
• Case Sensitivity: Measure names are case-sensitive. type [<Measure>] Kg and type [<Measure>] kg are treated as distinct, incompatible dimensions.
• Complexity in Generics: Writing generic functions that operate across different units can lead to verbose type signatures and complex compiler errors if the units are not explicitly handled.
