Prevent Unit Mismatches in F# Code with Units of Measure

Problem: silent unit bugs in numeric code

When you write calculations that involve physical quantities — distances, times, masses, or even currency amounts — it is easy to accidentally add a length to a time or multiply a price in dollars by a quantity in euros. In many languages the mistake only surfaces at runtime, producing wrong results or exceptions that are hard to trace.

Thesis: F# Units of Measure give compile‑time dimensional safety with zero runtime cost

The F# type system can attach a unit symbol to any floating‑point value. The unit is checked during compilation and then erased, so the generated IL is identical to plain float. This lets you catch mismatches early without allocating wrappers or paying performance penalties.

1. Defining and using measures

First declare a unit with the [] attribute. The name can be any valid identifier.

[] type m   // metres
[] type s   // seconds
[] type kg  // kilograms

Annotate values when you bind them:

let distance = 10.0          // float
let time     = 2.0           // float
let mass     = 5.0          // float

The compiler now knows the dimension of each value. You can write functions that preserve units:

let speed (d: float) (t: float) = d / t   // returns float
let kinetic (m: float) (v: float) = 0.5 * m * v * v   // float

2. Generic unit parameters for reusable code

Sometimes you need algorithms that work for any unit, as long as the same unit appears on both arguments. A generic unit parameter 'u expresses this:

let addSameUnit (x: float<'u>) (y: float<'u>) = x + y

Calling addSameUnit 3.0 4.0 succeeds, while addSameUnit 3.0 4.0 fails with error FS0001: type mismatch.

3. Interop with untyped .NET APIs

Units exist only at compile time. To pass a measured value to a method that expects a plain double you must strip the unit explicitly:

// C# method: void Print(double d)
Print (float 10.0)   // float operator removes the unit, passes 10.0

The reverse direction — attaching a unit to a raw double — is done by multiplying with a unit‑valued constant:

let raw = 9.81   // from a .NET API
let g = raw * 1.0   // yields float

For frequent conversions the helper LanguagePrimitives.FloatWithMeasure is the officially supported path:

open Microsoft.FSharp.Core.LanguagePrimitives
let mFromDouble (x: float) = FloatWithMeasure x

Worked example: validating a physics simulation

Suppose we compute the period of a simple pendulum: T = 2 * π * sqrt(L / g). We want the compiler to guarantee that L is a length and g an acceleration.

[] type m
[] type s

let pi = 3.141592653589793
let g  = 9.81

let period (length: float) : float =
    2.0 * pi * sqrt (length / g)

// Usage
let L = 2.0
let T = period L   // T : float
printfn "Period = %f s" (float T)   // strip unit for printing

If we mistakenly pass a mass instead of a length:

let bad = period 5.0   // compile‑time error: expecting float, got float

The build stops before any code runs, preventing the bug.

Trade‑offs and limitations

• No runtime validation: Units are erased, so data read from JSON, a database, or user input must be explicitly annotated; a mismatched unit in the source will not be caught until a calculation uses it.
• Dimensionally equivalent units need explicit conversion: The type system treats mm and m as different units; you must write functions like let mmToM (x: float) = x / 1000.0.
• Generic unit polymorphism is structurally uniform: You cannot write if ('u = typeof) then …; all unit‑polymorphic code must behave identically for every unit.
• Tooling variance: IDEs show unit hints, but some refactorings (e.g., rename) may not update unit annotations consistently.

To verify that units are truly erased, inspect the compiled IL:

dotnet build -c Release
ildasm MyApp.dll

You will see method signatures and fields as plain float64 with no custom attributes.

Actionable steps to adopt Units of Measure

1. Add a [] block for the units your domain needs (e.g., m, s, USD).
2. Annotate existing numeric constants and function parameters.
3. Enable the warning --warnon:1182 to catch unitless literals in unit‑expected contexts.
4. Run the build and fix any FS0001 mismatches that appear.
5. When calling .NET APIs, use float to strip units or multiply by 1.0 to re‑attach them.
6. Periodically check the IL with ildasm to confirm erasure, especially after refactoring.

By following these steps you gain compile‑time protection against unit errors without sacrificing performance or adding runtime overhead.
