Precision Placement: Using GCC Section Attributes in Embedded C

A large calibration table intended for Flash memory ends up occupying precious RAM because the compiler placed it in a default read-only section that the startup code copies to RAM. On a resource-constrained MCU, this wastes memory and increases boot time. The solution is using GCC's __attribute__((section)) to tag specific objects or functions for a named linker section, allowing the linker script to map them to a precise physical memory address.

How the Section Attribute Works

The __attribute__((section("name"))) is a GCC extension that tells the compiler to associate a declaration with a specific ELF (Executable and Linkable Format) section rather than the standard .text, .data, or .bss sections. This attribute must follow the declaration.

For a data object:

static const uint16_t calib_table[256] __attribute__((section(".calib"))) = { 0x1234, 0x5678 };

For a function:

void fast_isr(void) __attribute__((section(".fast_code")));

It is important to understand that the attribute only tags the object. It does not dictate the final memory address; that responsibility belongs to the linker script. If the linker script does not explicitly handle the named section, the linker may place it in a default area or throw an error depending on the configuration.

Connecting Attributes to the Linker Script

To make the attribute effective, the linker script must define a MEMORY region and a corresponding SECTIONS entry. The SECTIONS entry collects all input sections with the matching name and assigns them to a hardware region.

MEMORY
{
  FLASH (rx) : ORIGIN = 0x08000000, LENGTH = 512K
  RAM   (rwx) : ORIGIN = 0x20000000, LENGTH = 128K
}

SECTIONS
{
  .text : { *(.text*) } > FLASH
  .rodata : { *(.rodata*) } > FLASH

  /* Map the custom .calib section to Flash */
  .calib : { KEEP(*(.calib)) } > FLASH

  /* Map the custom .fast_code section to RAM for speed */
  .fast_code : { *(.fast_code) } > RAM
}

The KEEP() keyword is critical; it prevents the linker's garbage collection (--gc-sections) from removing the section if it isn't explicitly referenced elsewhere in the code.

Worked Example: Flash-Resident Calibration Data

Goal: Ensure a 512-byte calibration table stays in Flash to save RAM.

C Source Implementation:

/* Use a macro for portability and consistency */
#define FLASH_SECTION __attribute__((section(".calib"), aligned(4)))

static const uint16_t system_calib[256] FLASH_SECTION = { 0xAAAA, 0xBBBB };

Verification Steps:
Run these commands on your build host. No target hardware permissions are required for static analysis.

• Compile: Run gcc -Wall -Wextra -T linker.ld -o firmware.elf. Check for warnings regarding unknown attributes.
• Inspect Sections: Run objdump -h firmware.elf. Verify that a section named .calib exists and its size matches the expected 512 bytes.
• Verify Symbols: Run readelf -S firmware.elf to ensure system_calib is associated with the .calib section.
• Map File Check: Examine the .map file (generated via -Wl,-Map=firmware.map). Confirm the address of system_calib falls within the 0x08000000 FLASH range.

Risk: Misaligned sections can cause hardware hard faults on architectures like ARM Cortex-M if a 32-bit access is attempted on a non-4-byte boundary. Always use aligned(4) for 32-bit data.

Trade-offs and Limitations

While powerful, custom sections introduce overhead. Excessive fragmentation of memory can degrade cache performance and make the linker script difficult to maintain. Every new section is a new point of failure if the script is not updated in tandem with the code.

Portability is a significant limitation. IAR and Keil use different pragma-based syntax for memory placement. To support multiple toolchains, wrap the attribute in a conditional macro:

#ifdef __GNUC__
  #define PLACE_IN_FLASH __attribute__((section(".calib")))
#elif defined(__ICCARM__)
  #pragma location = ".calib"
  #define PLACE_IN_FLASH
#endif

Actionable Closing: Start by isolating a single large constant array. Move it to a named section, update your linker script, and verify the address using objdump. Once the workflow is verified, use a centralized header file for all section macros to avoid typos across the codebase.
