Pod-level resource managers

Feature state: Beta since Kubernetes v1.37; disabled by defaultMore information about this feature

To use this feature, you (or a cluster administrator) will need to enable the PodLevelResourceManagers feature gate for all relevant components in your cluster.

See Enable Or Disable Feature Gates for more information.

Pod-level resource support for the existing resource managers (Topology, CPU, and Memory) extends them to handle pod-level resource specifications. When enabled (via the PodLevelResources and PodLevelResourceManagers feature gates), the resource managers can use .spec.resources directly as the basis for their allocation decisions, evolving from a strictly per-container allocation model to a Pod-centric one. This partitioning scheme introduces a more flexible and powerful resource management model, particularly for performance-sensitive workloads. It allows you to define hybrid allocation models where some containers in a Pod receive exclusive, NUMA-aligned resources, while others share the remaining resources from a pod-level shared pool.

To practice setting up kubelet resource managers with pod-level resources and observe allocation behaviors hands-on, follow the Use pod-level resources with kubelet resource managers tutorial.

To understand pod-level resource managers, it is helpful to contrast them with the traditional container-focused model. Previously, kubelet resource allocations were strictly all or nothing: to receive exclusive NUMA-aligned resources for your workload, every container in the Pod had to be Guaranteed (specifying requests equal to limits for both CPU and memory).

Pod-level resource managers use .spec.resources to enable flexible partitioning based on the configured Topology Manager scope:

• pod scope: The kubelet allocates and NUMA-aligns a single Pod bubble for the entire Pod based on .spec.resources. Containers requesting exclusive allocations carve out dedicated slices from within this Pod bubble, while all other containers share the remaining bubble capacity in a pod-isolated shared pool.
• container scope: Enables a hybrid allocation model. The kubelet allows individual containers to receive exclusive, NUMA-aligned resources directly from the Node's allocatable pool, while using the Pod's .spec.resources ceiling to cap collective consumption—allowing sidecars to run in the general Node shared pool without requiring every container in the Pod to be Guaranteed.

Both standard init containers and restartable init containers (sidecars) are fully supported. They can receive exclusive resource slices or use the Pod's shared pool, and the pod-level resource managers respect their lifecycle rules (for example, reusable resources for standard init containers vs. persistent reservations for sidecars).

Glossary

Pod level resources specificationThe resource budget defined at the Pod level in .spec.resources, that specifies the collective requests and limits for the entire Pod.Guaranteed containerA container that specifies resource requests equal to its limits for both CPU (exclusive CPU allocation requires a positive integer value) and Memory. Consistent with existing kubelet behavior, this makes the container eligible for exclusive resource allocation from the resource managers.Exclusive sliceA dedicated portion of resources (for example: specific CPUs or memory pages) allocated solely to a single container, ensuring isolation from other containers.Pod shared poolThe subset of a Pod's allocated resources that remains after all exclusive slices have been reserved. These resources are shared by all containers in the Pod that do not receive an exclusive allocation. While containers in this pool share resources with each other, they are strictly isolated from the exclusive slices and the general node-wide shared pool.

How pod-level resource managers work

The CPU and Memory resource managers operate differently depending on the configured Topology Manager scope.

Topology manager's pod scope and pod-level resources

When the Topology Manager scope is set to pod, the kubelet performs a single NUMA alignment for the entire Pod based on the resource budget defined in .spec.resources.

The resulting NUMA-aligned resource pool is then partitioned:

1. Exclusive slices: Containers that specify Guaranteed resources (requests equal to limits for both CPU and memory, and the CPU request is a positive integer) receive exclusive slices from the Pod's total allocation.
2. Pod shared pool: The remaining resources form a shared pool for all other containers in the Pod that do not receive an exclusive allocation. While containers in this pool share resources with each other, they are strictly isolated from the exclusive slices and the general node-wide shared pool.

Note that when standard init containers run to completion, their resources enter a per-Pod reusable set rather than returning to the Node's resource pool. Because they run sequentially, subsequent app containers can reuse these resources (either for their own exclusive slices or for the shared pool).

This allows you to co-locate containers that require exclusive resources (for example, a high-performance primary application) with those that do not (for example, sidecars for logging or monitoring), all within a single NUMA-aligned Pod.

Consider the containers in the following Pod spec, where the Topology Manager scope is pod and the Pod has a total budget of 4 CPUs. main-app requests an exclusive 2 CPU slice, while the sidecars share the remaining 2 CPUs in the Pod's shared pool:

pods/resource/pod-level-resource-managers-pod-scope-mixed.yaml Open diagram: Documentation illustration

apiVersion: v1
kind: Pod
metadata:
  name: pod-scope-mixed
  annotations:
    kubernetes.io/description: "A pod demonstrating pod-level scope where one container gets exclusive resources and others share the remaining pod resources in a shared pool."
spec:
  # At Pod level, the Pod has CPU request equal to limits and memory request
  # also equal to memory limits. The main-app container meets the requirements
  # for the Guaranteed QoS class at container level, and the sidecar containers
  # don't specify any resource request. Under pod scope, this means that the
  # kubelet could statically assign 4 CPUs to the overall Pod, of which 2 are
  # assigned exclusively to the main-app container, and the remaining 2 are
  # shared by the sidecars in the pod's shared pool.
  resources:
    requests:
      cpu: "4"
      memory: "4Gi"
    limits:
      cpu: "4"
      memory: "4Gi"
  initContainers:
  - name: metrics-sidecar
    # Note: This is a placeholder image for demonstration purposes, not an
    #actual metrics helper.
    image: registry.k8s.io/pause:3.9
    restartPolicy: Always
  - name: logging-sidecar
    # Note: This is a placeholder image for demonstration purposes, not an
    # actual logging agent.
    image: registry.k8s.io/pause:3.9
    restartPolicy: Always
  containers:
  - name: main-app
    # Note: This is a placeholder image for demonstration purposes.
    image: registry.k8s.io/pause:3.9
    resources:
      requests:
        cpu: "2"
        memory: "2Gi"
      limits:
        cpu: "2"
        memory: "2Gi"

Important considerations:

When using pod-level resources with the Topology manager's pod scope, there are some important considerations:

• Empty shared pool restriction: This configuration does not allow Pod specifications that would produce an empty Pod shared pool if there are containers that require one. If the sum of resource requests from all containers that are Guaranteed exactly equals the total resource budget, and there is at least one other container that requires a shared pool, the kubelet rejects the Pod at admission.

  For example, the following Pod asks for a pod-level budget of 4 CPUs. main-app requires an exclusive 3 CPUs and metrics-sidecar requires an exclusive 1 CPU. Because there are 0 CPUs left in the shared pool for logging-sidecar, the kubelet rejects this Pod (the same validation applies for memory):

  pods/resource/pod-level-resource-managers-empty-shared-pool.yaml Open diagram: Documentation illustration

  apiVersion: v1
  kind: Pod
  metadata:
    name: empty-shared-pool
    annotations:
      kubernetes.io/description: "A pod demonstrating a configuration that is rejected because exclusive containers consume the entire pod resource budget, leaving no resources for the remaining container in the shared pool."
  spec:
    # At Pod level, the Pod has CPU request equal to limits and memory request
    # also equal to memory limits. The main-app and metrics-sidecar containers
    # meet the requirements for the Guaranteed QoS class at container level, and
    # the logging-sidecar container doesn't specify any resource request. Because
    # the Guaranteed containers consume the entire pod resource budget,
    # leaving 0 CPUs for the shared pool required by logging-sidecar, this pod
    # will be rejected at admission.
    resources:
      requests:
        cpu: "4"
        memory: "4Gi"
      limits:
        cpu: "4"
        memory: "4Gi"
    initContainers:
    - name: metrics-sidecar
      # Note: This is a placeholder image for demonstration purposes, not an
      # actual metrics helper.
      image: registry.k8s.io/pause:3.9
      restartPolicy: Always
      resources:
        requests:
          cpu: "1"
          memory: "1Gi"
        limits:
          cpu: "1"
          memory: "1Gi"
    - name: logging-sidecar
      # Note: This is a placeholder image for demonstration purposes, not an
      # actual logging agent.
      image: registry.k8s.io/pause:3.9
      restartPolicy: Always
    containers:
    - name: main-app
      # Note: This is a placeholder image for demonstration purposes.
      image: registry.k8s.io/pause:3.9
      resources:
        requests:
          cpu: "3"
          memory: "3Gi"
        limits:
          cpu: "3"
          memory: "3Gi"


• Wasted resources: Any resources overallocated when using the pod scope (the total container requests sum to less than the pod-level budget and there are no shared pool containers, or the shared pool containers don't fully use the remaining amount) remain assigned and reserved for the Pod, effectively going to waste during the entire Pod execution.

• Persistent pool: The Pod's total resource pool (the NUMA alignment and total reserved capacity) is persistent. If a shared-pool container crashes and restarts, the Pod's overall resource reservation remains safely anchored on the Node. The Node releases the resources back to its general pool only when the entire Pod terminates.

Topology manager's container scope and pod-level resources

When the Topology Manager scope is set to container, the kubelet evaluates each container individually for exclusive allocation.

If the overall Pod achieves a Guaranteed QoS class (by specifying appropriate values in the Pod-level .spec.resources), you can mix and match containers:

• Containers with their own Guaranteed requests receive exclusive NUMA-aligned resources.
• Other containers in the Pod that do not specify Guaranteed requests run in the Node's shared pool.
• The collective resource consumption of all containers is still enforced by the Pod's .spec.resources limits.

This scope is useful when you have an infrastructure sidecar that needs to be aligned to a specific NUMA Node for device access, while the main workload can run in the general Node shared pool.

Consider the containers in the following Pod spec, where the Topology Manager scope is container and the Pod represents a workload with an infrastructure sidecar and two application workers, with a total budget of 4 CPUs. The infrastructure-sidecar gets an exclusive, NUMA-aligned 2 CPU slice. The two application workers (worker-1 and worker-2) run in the general, node-wide shared pool:

pods/resource/pod-level-resource-managers-container-scope-mixed.yaml Open diagram: Documentation illustration

apiVersion: v1
kind: Pod
metadata:
  name: container-scope-mixed
  annotations:
    kubernetes.io/description: "A pod demonstrating container-level scope where one container gets exclusive resources and others run in the node's shared pool."
spec:
  # At Pod level, the Pod has CPU request equal to limits and memory request
  # also equal to memory limits. The infrastructure-sidecar container meets the
  # requirements for the Guaranteed QoS class at container level, and the worker
  # containers don't specify any resource request. Under container scope, the
  # kubelet evaluates containers individually for exclusive allocation. This
  # means the infrastructure-sidecar gets an exclusive 2 CPU slice, while the
  # worker containers run in the node's general shared pool, all while bounded
  # by the overall pod limits.
  resources:
    requests:
      cpu: "4"
      memory: "4Gi"
    limits:
      cpu: "4"
      memory: "4Gi"
  initContainers:
  - name: infrastructure-sidecar
    # Note: This is a placeholder image for demonstration purposes, not an
    # actual infrastructure helper.
    image: registry.k8s.io/pause:3.9
    restartPolicy: Always
    resources:
      requests:
        cpu: "2"
        memory: "2Gi"
      limits:
        cpu: "2"
        memory: "2Gi"
  containers:
  - name: worker-1
    # Note: This is a placeholder image for demonstration purposes.
    image: registry.k8s.io/pause:3.9
  - name: worker-2
    # Note: This is a placeholder image for demonstration purposes.
    image: registry.k8s.io/pause:3.9

CPU quota (CFS)

When running mixed workloads within a Pod, the kubelet enforces isolation differently depending on the allocation:

• Exclusive containers: Containers with exclusive CPU slices have their CPU CFS quota enforcement disabled, allowing them to run without throttling by the Linux scheduler.
• Pod shared pool containers: Containers in the Pod shared pool have CPU CFS quotas enabled, ensuring they do not consume more than the leftover Pod budget and preventing them from interfering with the exclusive containers.

Persistent pool and restarts

The Pod's total resource pool (the NUMA alignment and total reserved capacity) is persistent. If a container in the Pod's shared pool crashes and restarts, the Pod's overall resource reservation remains safely anchored on the Node. The Node releases the resources back to its general pool only when the entire Pod terminates.

kubelet downgrades and state checkpoints

In Kubernetes 1.36, enabling PodLevelResourceManagers updated internal kubelet state checkpoint files (cpu_manager_state and memory_manager_state) to a format that older kubelet versions cannot load. If you downgrade a 1.36 kubelet after active use, the older kubelet fails to start; you must drain the Node, delete these checkpoint files, and restart the kubelet.

In Kubernetes 1.37, checkpoint files use a forward-compatible format to prevent start-up failures during downgrades, though 1.36 kubelet versions do not restore active pod-level resource assignments. For complete details on checkpoint formats and recovery, see the Pod-level resource managers reference.

Observability and metrics

You can monitor the behavior and health of the resource managers across both container-level and pod-level allocations using the following kubelet metrics (enabled via the PodLevelResourceManagers feature gate):

• resource_manager_allocations_total: Counts the total number of exclusive resource allocations performed by a manager. The source label ("pod" or "node") distinguishes between allocations drawn from the node-level pool versus a pre-allocated pod-level pool.
• resource_manager_allocation_errors_total: Counts errors encountered during exclusive resource allocation, distinguished by the intended allocation source ("pod" or "node").
• resource_manager_container_assignments: Tracks the cumulative number of containers that will be granted a specific type of resource assignment. The assignment_type label ("node_exclusive", "pod_exclusive", "pod_shared") provides visibility into how many containers are running with exclusive resources (from the node or pod pool) versus the pod-level shared pool.

PodResources API

In Kubernetes 1.37, the kubelet's node-local PodResources gRPC API includes pod-level resource allocations when PodLevelResourceManagers is enabled. Node-local monitoring agents and device plugins can query top-level Pod assignments (cpu_ids and memory) while avoiding double-counting container-level allocations.

For complete API schemas, field masks, and scope-by-scope reporting tables, see the Pod-level resource managers reference.

Limitations and caveats

• The functionality is only implemented for the static CPU Manager policy and the Static Memory Manager policy. Note that the BestEffort policy is not supported for the Memory Manager.
• This feature is only supported on Linux nodes. On Windows nodes, the resource managers will act as a no-op for pod-level allocations.
