Observability of Dynamic Resources

This page describes how to observe the status and health of resources that are dynamically allocated with DRA.

Observability of dynamic resources

You can check the status of dynamically allocated resources by using any of the following methods:

• kubelet device metrics
• ResourceClaim status
• Device health monitoring

kubelet device metrics

The PodResourcesLister kubelet gRPC service lets you monitor in-use devices. The DynamicResource message provides information that's specific to dynamic resource allocation, such as the device name and the claim name. For details, see Monitoring device plugin resources.

ResourceClaim device status

Feature state: Stable since Kubernetes v1.37; enabled by defaultMore information about this feature

This is a stable feature in Kubernetes, and has been since version 1.37. It was first available in the v1.32 release.

DRA drivers can report driver-specific device status data for each allocated device in the status.devices field of a ResourceClaim. For example, the driver might list the IP addresses that are assigned to a network interface device. Updating this field requires specific synthetic RBAC permissions, see Hardening Guide - Dynamic Resource Allocation and Harden Dynamic Resource Allocation in Your Cluster.

The accuracy of the information that a driver adds to a ResourceClaim status.devices field depends on the driver. Evaluate drivers to decide whether you can rely on this field as the only source of device information.

If you disable the DRAResourceClaimDeviceStatus feature gate, the status.devices field automatically gets cleared when storing the ResourceClaim. A ResourceClaim device status is supported when it is possible, from a DRA driver, to update an existing ResourceClaim where the status.devices field is set.

In the following example, the status.devices field of a ResourceClaim has been populated by the driver (resource-driver.example.com) responsible for managing the allocated device:

apiVersion: resource.k8s.io/v1
kind: ResourceClaim
metadata:
  name: macvlan-eth0
spec:
...
status:
  allocation:
    devices:
      results:
      - device: eth0
        driver: resource-driver.example.com
        pool: nic-worker-a
        request: macvlan-eth0
        shareID: 8e7acdf9-0290-4ecd-a801-a654b021d2b7
        consumedCapacity:
          resource-driver.example.com/bandwidth: 1G
  devices:
  - conditions:
    - lastTransitionTime: "2025-10-21T08:38:17Z"
      message: Device successfully allocated and assigned to the pod
      reason: NetworkReady
      status: "True"
      type: NetworkReady
    device: eth0
    driver: resource-driver.example.com
    networkData:
      hardwareAddress: 00:01:ec:84:fb:51
      interfaceName: net1
      ips:
      - 10.10.1.2/24
      - 2001:db8::1/64
    pool: nic-worker-a
    shareID: 8e7acdf9-0290-4ecd-a801-a654b021d2b7

If a device has not been allocated, a driver's request to update the status.devices field of the ResourceClaim with that device is rejected. When a device is deallocated (removed from status.allocation.devices), the corresponding entry in status.devices is automatically removed.

For details about the status.devices field, see the ResourceClaim API reference.

Device Health Monitoring

Feature state: Beta since Kubernetes v1.36; enabled by default

Kubernetes provides a mechanism for monitoring and reporting the health of dynamically allocated infrastructure resources. For stateful applications running on specialized hardware, it is critical to know when a device has failed or become unhealthy. It is also helpful to find out if the device recovers.

To use this functionality, the ResourceHealthStatus feature gate must be enabled (beta and enabled by default since v1.36), and the DRA driver must implement the DRAResourceHealth gRPC service.

When a DRA driver detects that an allocated device has become unhealthy, it reports this status back to the kubelet. This health information is then exposed directly in the Pod's status. The kubelet populates the allocatedResourcesStatus field in the status of each container, detailing the health of each device assigned to that container. Each resource health entry can include an optional message field with additional human-readable context about the health status, such as error details or failure reasons.

If the kubelet does not receive a health update from a DRA driver within a timeout period, the device's health status is marked as "Unknown". DRA drivers can configure this timeout on a per-device basis by setting the health_check_timeout_seconds field in the DeviceHealth gRPC message. If not specified, the kubelet uses a default timeout of 30 seconds. This allows different hardware types (for example, GPUs, FPGAs, or storage devices) to use appropriate timeout values based on their health-reporting characteristics.

This provides crucial visibility for users and controllers to react to hardware failures. For a Pod that is failing, you can inspect this status to determine if the failure was related to an unhealthy device.

Note:

Device health status is not updated in the Pod status after a Pod has terminated (for example, in Failed state).

Resource pool status

Feature state: Alpha since Kubernetes v1.36; disabled by defaultMore information about this feature

To use this feature, you (or a cluster administrator) will need to enable the DRAResourcePoolStatus feature gate for all relevant components in your cluster.

See Enable Or Disable Feature Gates for more information.

You can query the availability of devices in resource pools using the ResourcePoolStatusRequest API. This provides visibility into how many devices are available, allocated, or unavailable across your cluster's DRA resource pools.

To check resource pool status:

1. Create a ResourcePoolStatusRequest specifying the driver name (required) and optionally a limit on the number of pools returned. You can also limit it to a single pool by specifying a pool name:

   apiVersion: resource.k8s.io/v1alpha3
   kind: ResourcePoolStatusRequest
   metadata:
     name: check-gpus
   spec:
     driver: example.com/gpu
     # Optional: filter to a specific pool
     # poolName: my-pool
     # Optional: limit number of pools returned (default: 100, max: 1000)
     # limit: 10


2. Wait for the controller to process the request:

   kubectl wait --for=condition=Complete resourcepoolstatusrequest/check-gpus --timeout=30s


3. Read the status to see pool availability:

   kubectl get resourcepoolstatusrequest/check-gpus -o yaml


   The status includes:

   • poolCount: total number of pools matching the filter (may exceed the number of pools listed if truncated by the limit).
   • pools: a list of pool details, each containing:
     • driver and poolName: identify the pool.
     • generation: the latest pool generation observed across ResourceSlices.
     • resourceSliceCount: the number of ResourceSlices making up the pool.
     • totalDevices: total devices in the pool.
     • allocatedDevices: devices currently allocated to claims.
     • availableDevices: devices available for allocation (totalDevices - allocatedDevices - unavailableDevices).
     • unavailableDevices: devices not available due to taints or other conditions.
     • nodeName: the node associated with the pool, if any.
     • validationError: set when the pool's data could not be fully validated (for example, during a generation rollout). When set, device count fields may be unset.
     • partitionSummary: for partitionable pools, per-partition-type allocatability (see Partition summary).
     • shareableSummary: for pools with shareable devices, aggregate capacity usage (see Shareable summary).
   • conditions: includes Complete (success) or Failed (error) condition types.

4. Delete the request when done:

   kubectl delete resourcepoolstatusrequest/check-gpus


ResourcePoolStatusRequest objects are processed once by a controller in kube-controller-manager. The spec is immutable once created, and the entire object becomes immutable once the status is populated. To get updated availability data, delete and recreate the request. Completed requests are automatically cleaned up after 1 hour.

This feature requires explicit RBAC permissions on the ResourcePoolStatusRequest resource. No default ClusterRoles include this permission.

Resource pool status is controlled by the DRAResourcePoolStatus feature gate in the kube-apiserver and kube-controller-manager.

Partition summary

Feature state: Alpha since Kubernetes v1.37; disabled by defaultMore information about this feature

To use this feature, you (or a cluster administrator) will need to enable the DRAPartitionableDevicesType feature gate for all relevant components in your cluster.

See Enable Or Disable Feature Gates for more information.

A single physical device such as a GPU may be advertised as several partition types (for example, a full GPU versus a half-sized MIG slice) that draw from the same shared counters. Because these partitions compete for the same underlying capacity, a plain device count does not tell you how many of each type can still be allocated. For partitionable pools, the partitionSummary view answers that question. For each partition type it reports:

• attribute: the fully qualified name of the device attribute whose value groups this entry. It is the ResourceSlice's spec.partitionTypeAttribute, or the request's spec.defaultPartitionTypeAttribute when the slice declares none.
• type: the value of that attribute on the device (for example, Full or Half).
• total: the number of devices of this partition type in the pool.
• allocatable: how many additional devices of this partition type could still be allocated given current shared-counter consumption.

The named attribute must be a string attribute. If a partitionable device's partition-type attribute is missing or is not a string (for example, an integer, boolean, or version value), the pool reports a validation error instead of a partition summary. There is no special handling for list-type attributes; a non-string attribute is simply not a valid partition-type attribute.

To produce this view, the driver labels each partitionable device with a string attribute whose value names the partition type, and names that attribute in the ResourceSlice's partitionTypeAttribute field:

apiVersion: resource.k8s.io/v1
kind: ResourceSlice
# ...
spec:
  # Every partitionable device in this slice carries this attribute; devices
  # that share a value share the same shared-counter cost.
  partitionTypeAttribute: gpu.example.com/profile

If a driver has not yet been updated to declare partitionTypeAttribute, a request can still obtain a partition summary by naming a fallback attribute in its spec. A slice's own partitionTypeAttribute always takes precedence; the request-level default applies only to devices whose slice does not declare one:

apiVersion: resource.k8s.io/v1alpha3
kind: ResourcePoolStatusRequest
metadata:
  name: check-gpu-partitions
spec:
  driver: gpu.example.com
  # Fallback grouping attribute for slices that don't declare one themselves.
  defaultPartitionTypeAttribute: gpu.example.com/profile

When neither the slice nor the request names an attribute, a partitionable pool reports no partitionSummary.

The partitionSummary view is controlled by the DRAPartitionableDevicesType feature gate in the kube-apiserver and kube-controller-manager, which in turn requires the DRAResourcePoolStatus and DRAPartitionableDevices feature gates to be enabled.

Shareable summary

For pools that contain shareable devices (devices that set allowMultipleAllocations and can be consumed by multiple claims), shareableSummary reports aggregate capacity usage across the pool:

• fullyAvailableDevices: shareable devices with no capacity consumed.
• partiallyAvailableDevices: shareable devices with some, but not all, capacity consumed.
• capacity: per capacity name, the aggregate total, consumed, and available (total minus consumed, never negative) amounts across the pool.

The shareableSummary is populated only when at least one device in the pool is shareable. It is part of the resource pool status feature (the DRAResourcePoolStatus feature gate) and does not require DRAPartitionableDevicesType; the shareable devices it summarizes come from the consumable capacity feature.

DRA device metadata in containers

Feature state: Beta since Kubernetes v1.37

DRA drivers can expose device metadata such as device attributes (PCI bus addresses or mediated device UUIDs) and network configuration directly to containers as JSON files. This lets applications discover information about allocated devices without querying the Kubernetes API or using custom controllers.

KEP-5304 defines a device metadata protocol that drivers must follow so that applications see a consistent layout across drivers and clusters. The DRA kubelet plugin library implements this protocol.

Device metadata follows the same rules as device access: it is available inside a container only when that container requests the device. For details, see Request devices in workloads using DRA.

Device metadata protocol

The protocol consists of four rules:

1. File paths. Metadata files live inside containers under /var/run/kubernetes.io/dra-device-attributes. For a directly referenced ResourceClaim, the path is resourceclaims/<claimName>/<requestName>/<driverName>-metadata.json. For a claim created from a ResourceClaimTemplate, the path is resourceclaimtemplates/<podClaimName>/<requestName>/<driverName>-metadata.json, where podClaimName is pod.spec.resourceClaims[].name.

   When a request uses a prioritized list, only the top-level request name is used for the <requestName> path segment. The requests[].name field in the file contains the full <request>/<subrequest> reference, such as gpu/high-memory.

   The path constants are defined in k8s.io/dynamic-resource-allocation/api/metadata.

2. JSON API. Each file is a stream of one or more DeviceMetadata objects. Each object has apiVersion and kind, following Kubernetes API conventions. The same metadata is encoded once per configured API version in the order selected by the driver. Consumers use the first version that they can decode and skip unknown versions. A malformed object in a known version is an error.

3. Generation. The initial file has metadata.generation set to 1. Each update increments the generation so that consumers can detect changes.

4. Container exposure. The DRA kubelet plugin library uses CDI to bind-mount each file read-only. Other implementations can use a different mechanism as long as the file appears at the required path and is read-only.

Enable device metadata in a driver

Device metadata is a driver-side feature. It has no Kubernetes feature gate and is disabled by default in the DRA kubelet plugin library. A driver must enable the feature and explicitly select the versions that it writes:

kubeletplugin.EnableDeviceMetadata(true, []schema.GroupVersion{
	metadatav1beta1.SchemeGroupVersion,
	metadatav1alpha1.SchemeGroupVersion,
})

The v1beta1 version is required. A driver can also write v1alpha1 for compatibility with older consumers. The order in the slice is the order in the metadata stream; the framework does not sort the versions. Drivers should put the newest version first. Enabling device metadata with no versions, without v1beta1, or with an unknown version causes the plugin to fail during startup.

For each prepared device, the driver can populate Device.Metadata with kubeletplugin.DeviceMetadata. Drivers should include the attributes that they publish for that device in its ResourceSlice, so workloads see the same information at runtime. Drivers can also include attributes that are only relevant at runtime. For network devices, drivers can add interface names, IP addresses, and hardware addresses after CNI configuration by calling UpdateRequestMetadata.

The kubelet plugin API links above describe integration for driver authors. The DRA framework does not define a universal command-line flag, so cluster operators enable the feature through the deployment configuration provided by their driver.

When enabled, the DRA kubelet plugin library writes metadata files while preparing allocated devices. It also writes CDI specifications to /var/run/cdi by default. The container runtime must be configured to discover CDI specifications from that directory. The library determines the minimum CDI specification version required for each generated specification.

When one request allocates devices from multiple DRA drivers, each driver writes its own metadata file. Consumers that know the driver name should construct the exact path from the claim, request, and driver names. Go consumers can use ReadResourceClaimMetadata or ReadResourceClaimTemplateMetadata to read and merge all per-driver files for a request.

Metadata schema

Each object in a metadata file conforms to the DeviceMetadata API (metadata.resource.k8s.io/v1beta1).

The schema contains:

• Standard object metadata for the ResourceClaim, including its name, namespace, UID, and metadata generation.
• The optional podClaimName for a claim generated from a ResourceClaimTemplate.
• A list of requests. Each request has a required name and a list of allocated devices.
• The driver, pool, and name for each device.
• Optional device attributes and network data.

Attribute values use the same representation as ResourceSlice device attributes. Each attribute has exactly one scalar value (int, bool, string, or version) or list value (ints, bools, strings, or versions). Device capacity values are not included in device metadata.

Network data can contain interfaceName, ips, and hardwareAddress. For field constraints, see the DeviceMetadata API documentation.

The following example shows one object in a metadata stream for a GPU device allocated through a ResourceClaimTemplate:

{
  "kind": "DeviceMetadata",
  "apiVersion": "metadata.resource.k8s.io/v1beta1",
  "metadata": {
    "name": "pod0-gpu-2kqrd",
    "namespace": "gpu-test1",
    "uid": "c7e7b22e-239b-4498-b27c-7f1344481e14",
    "generation": 1
  },
  "podClaimName": "gpu",
  "requests": [
    {
      "name": "gpu",
      "devices": [
        {
          "driver": "gpu.example.com",
          "pool": "worker-0",
          "name": "gpu-0",
          "attributes": {
            "driverVersion": {
              "version": "1.0.0"
            },
            "index": {
              "int": 0
            },
            "model": {
              "string": "LATEST-GPU-MODEL"
            },
            "uuid": {
              "string": "gpu-18db0e85-99e9-c746-8531-ffeb86328b39"
            }
          }
        }
      ]
    }
  ]
}

The DRA kubelet plugin does not validate metadata before writing it. Go consumers can opt in to generated validation when decoding a stream. Decoding and validation have separate results: a validation error does not prevent a successfully decoded object from being returned. For usage, see Access DRA device metadata.

Immediate and deferred metadata

For immediate metadata, the driver supplies attributes or network data while it prepares the claim. The DRA kubelet plugin writes the file with generation 1 before the consuming container starts.

For deferred metadata, the driver can prepare a device without attributes or network data. The initial generation 1 file contains the device identity. The driver later calls UpdateRequestMetadata to replace the complete stream atomically and increment the generation. An update requires the initial file to exist. If device preparation returns no devices for a request, the framework creates neither a metadata file nor a metadata CDI device for that request.

Metadata remains available to each consuming container for the lifetime of that container. The framework removes the metadata files and CDI specifications after the claim is unprepared.

To learn how to use device metadata in your workloads, see Access DRA device metadata.

Custom drivers

Custom drivers that do not use the DRA kubelet plugin library must implement the device metadata protocol themselves. This includes writing the versioned DeviceMetadata stream at the correct paths, incrementing metadata.generation on every update, and exposing files read-only through CDI or an equivalent mechanism.
