MODX Revolution Multi-Site Architecture: Contexts as Tenancy Primitives

The Problem: One Codebase, Multiple Distinct Sites

You need to serve example.com, shop.example.com, and api.example.com from a single MODX installation. Each site has its own domain, resource tree, configuration, and permission model. Spinning up three separate MODX installs multiplies maintenance, upgrades, and infrastructure cost. MODX Revolution solves this with Contexts—a built-in multi-tenancy primitive that isolates configuration and resource trees while sharing the core codebase and database.

Takeaway: Contexts give you logical isolation (separate site_url, site_start, ACLs, resource roots) without physical separation. They are not security boundaries by default; treat them as organizational boundaries unless you harden ACLs and session handling.

Requirements That Lead to Contexts

• Multiple domains or subdomains pointing to one document root
• Distinct resource trees (different home pages, templates, content structures)
• Per-site configuration (error pages, custom settings, URL schemes)
• Shared user base with context-scoped permissions
• Single deployment pipeline, single database backup

If you need hard data sovereignty (GDPR, client isolation), divergent PHP versions, or independent scaling, contexts are the wrong tool—use separate installations.

Smallest Suitable Design: Two Contexts, One Database

A minimal multi-site setup creates one additional context beyond the default web context. Example: a marketing site (web) and a headless API (api).

Step 1: Create the API Context

In the Manager: System → Contexts → Create New. Key fields:

Field	Value	Purpose
key	api	Internal identifier; used in context_key on resources
name	API	Manager display name
description	Headless JSON endpoints	Documentation
site_url	https://api.example.com/	Must match incoming Host header; trailing slash required
site_start	100	Resource ID of the API entry point (create after)
error_page	101	Resource ID for 404/500 JSON responses

Save. MODX writes a row to modx_context and creates core/cache/api/.

Step 2: Add Context Settings

Right-click the api context → Update Context Settings. Add overrides:

# Example settings for API context
api_version = v1
json_errors = 1
cors_enabled = 1
cors_origin = https://app.example.com

These live in modx_context_setting keyed by context_key. Access in templates/plugins via [[++api_version]] or $modx->getOption('api_version').

Step 3: Create API Resources

In the resource tree, switch context dropdown to API. Create a container resource (ID 100) with template Blank or a custom API template. Children become endpoints: /v1/products, /v1/users. Set content_type to json on each.

Step 4: Verify Routing

Run from a host that can reach the server (replace localhost with your server IP):

# Test web context (default)
curl -H 'Host: example.com' http://localhost/
# Expect: HTML of web home page

# Test api context
curl -H 'Host: api.example.com' http://localhost/
# Expect: JSON from resource 100

# Verify context setting resolution
curl -H 'Host: api.example.com' http://localhost/ -s | grep -o '"version":"[^"]*"'
# Expect: "version":"v1" if template outputs [[++api_version]]

Where to run: Any machine with network access to the MODX web root. Permissions: None beyond HTTP access. Risk: None—read-only verification.

Trust and Data Boundaries

What Contexts Share

• Single MySQL connection pool (same xpdo instance)
• Same PHP-FPM process / Apache thread
• Core tables: modx_users, modx_session, modx_transport_packages
• File system: core/, assets/, connectors/
• Cache backend (Redis, Memcached, or file) unless partitioned

What Contexts Isolate

• Resource tree root (context_key on modx_site_content)
• Configuration values (modx_context_setting)
• ACL policies: Context Access, Resource Group Access per context
• Cache directories: core/cache/web/ vs core/cache/api/

ACL Hardening Checklist

1. Create a Context Access ACL for each context: Security → Access Controls → Context Access → New. Principal: User Group API Editors. Target Context: api. Policy: ResourceEditor (or custom).
2. Create Resource Group ACLs scoped to context: assign API resources to API Resources group, grant API Editors access only to that group.
3. Deny cross-context access explicitly: no web context policy for API Editors.
4. Test: log in as an API Editors user in Manager; verify web resources are invisible.

Session Isolation

By default, session_cookie_path is / and session_cookie_domain is empty, so a session cookie set on example.com is sent to api.example.com. If the API context lacks a plugin to validate $modx->context->key === 'api' on OnHandleRequest, a user authenticated on the marketing site inherits that session on the API.

Fix: add a plugin on OnHandleRequest (priority 0):

if ($modx->context->key === 'api' && !$modx->user->hasSessionContext('api')) {
    $modx->user->removeSessionContext('web');
    $modx->sendUnauthorizedPage();
}

Or configure session_cookie_domain = .example.com and session_cookie_path = / in each context's settings, then use a plugin to invalidate cross-context sessions.

Operational Checks

Cache Partition Verification

After requests to both hosts, inspect cache directories:

ls -la core/cache/web/ core/cache/api/
# Both should contain config.cache.php, context_settings.cache.php, etc.
# File timestamps should update per-context on deploy

MODX 2.8+ prefixes cache keys with context automatically. On older versions, ensure plugins use $modx->cacheManager->get('key', ['context' => 'api']).

Configuration Drift Audit

SELECT context_key, `key`, value
FROM modx_context_setting
WHERE context_key IN ('web','api')
ORDER BY context_key, `key`;

Compare critical settings: site_url, site_start, error_page, publish_default, friendly_urls, use_alias_path.

Plugin Execution Order Debugging

Context loading happens in OnHandleRequest. A plugin that forces $modx->switchContext('web') before the router runs breaks multi-site. List plugins on that event:

SELECT p.name, p.priority, pe.event
FROM modx_plugins p
JOIN modx_plugin_events pe ON p.id = pe.pluginid
WHERE pe.event = 'OnHandleRequest'
ORDER BY pe.priority;

Ensure no plugin with priority lower than 0 (runs early) calls switchContext unconditionally.

Failure Modes

Symptom	Root Cause	Fix
Infinite redirect loop on api.example.com	site_url missing trailing slash or mismatched scheme (http vs https)	Set site_url = https://api.example.com/ exactly; clear cache
API returns marketing site HTML	Router matched web context first; site_url not unique enough	Ensure distinct hostnames; avoid overlapping subdirectory paths
Cache key collision leaks data	Pre-2.8 custom snippets using $modx->cacheManager->set('key', $data) without context	Upgrade or prefix keys manually: 'api_' . $key
DB connection exhaustion kills all sites	Single pool; one context's heavy query starves others	Read replicas per context; or separate installs for high-traffic contexts
Package install breaks API context	Transport package assumes web context during install	Install packages while web context active; test after

Conditions That Change the Design

Trigger: Hard Data Sovereignty Required

Client A and Client B cannot share a database (contractual, GDPR, HIPAA). Action: Split into separate MODX installations. Use a shared core via symlinks or Composer if code reuse is needed.

Trigger: One Context Consumes 80%+ of DB Connections

API context under load starves marketing site. Action: Move API to dedicated read replica with separate DB user, or spin up a second MODX install pointing to replica. Keep contexts only if traffic is balanced.

Trigger: Divergent PHP/Extension Requirements

Marketing site needs imagick; API needs swoole for async. Action: Containerize per context (Docker/K8s) with separate PHP-FPM pools, or separate installs.

Trigger: Migration to Headless/API-First

Add a new api context with site_url = https://api.example.com/, site_start pointing to a REST router resource (e.g., pdoTools @FILE snippet or custom modRestController). Keep web for editorial workflow. This is the lowest-risk path—no data migration, just new context.

Upgrade Considerations

MODX 2.x → 3.x removes ExtJS Manager. Context-specific manager customizations (custom grids, trees, dashboards) break. Test each context's front-end and manager workflows on staging:

1. Clone production DB and files to staging.
2. Run setup/ in-place upgrade.
3. For each context: hit site_url, verify home page, error page, 3 random resources.
4. Log into Manager as context-scoped user; verify resource tree, editing, publishing.
5. Check modx_context_setting for deprecated keys (e.g., manager_theme).

Verification Checklist for New Multi-Site Deploy

• Two contexts created with distinct site_url (including trailing slash)
• site_start and error_page point to existing resource IDs in each context
• curl -H 'Host: ...' returns correct context's home page
• [[++site_url]] and [[*id]] resolve per context in templates
• Cache directories core/cache/context_key/ exist and are writable by PHP user
• Context Access ACLs grant least privilege; cross-context access denied
• Resource Group ACLs align with context boundaries
• Session plugin invalidates cross-context sessions (if shared domain)
• modx_context_setting audited for drift
• Load test with wrk -t4 -c100 -d30s -H 'Host: api.example.com' http://localhost/ shows no DB connection errors

Limitations

• Contexts share a single point of failure: database, PHP process, filesystem.
• No native horizontal scaling per context; all contexts scale together.
• Manager UI shows all contexts to users with contexts permission; UI clutter grows with context count.
• Package ecosystem assumes web context; third-party extras may misbehave.

When these limitations become blockers, the architecture shifts from "contexts within one install" to "multiple installs with shared core via Composer." That decision is driven by operational pain, not theoretical purity.
