MODX Contexts for Multisite: Architecture Decisions and Operational Reality

When Contexts Make Sense — and When They Don’t

MODX Revolution’s context system lets a single core installation serve multiple distinct websites, each with its own resource tree, system settings, and domain mapping. This works well for organizations managing a handful of related sites — marketing microsites, regional variants, or brand subsidiaries — where shared content blocks, user accounts, and a unified manager interface reduce overhead. It stops making sense when tenants need true isolation, independent deployments, or separate scaling.

Requirements That Fit the Model

• Two to ~ten sites sharing a codebase, database, and manager access
• Content editors who work across sites but need per‑site permissions
• Common snippets, plugins, and templates reused with minor variations
• Single team responsible for updates, backups, and security patches

If any site requires its own PHP version, custom extensions, or database schema changes, contexts cannot accommodate that — they share one core/ directory and one MySQL/MariaDB database.

Smallest Suitable Design: One Context Per Site

Create exactly one context per website. Do not split a single site into multiple contexts for “sections” (blog, shop, docs) — that adds routing complexity without isolation benefit. Each context needs:

• A unique key (e.g., site_en, site_de)
• http_host and site_url context settings matching the public domain
• Its own root resource (the homepage) and resource tree
• Optionally, a dedicated media source with basePath/baseUrl scoped to the context

Shared assets (global snippets, chunks, system plugins) live in the default web context or a dedicated “shared” context. Site‑specific overrides go in each context’s namespace.

Routing: The Gateway Decision

MODX does not route by hostname automatically. You must choose one mechanism:

Method	Where It Runs	Typical Use Case
ContextRouter plugin (or similar)	MODX OnHandleRequest event	Simple setups, all domains on one vhost
Nginx/Apache map or rewrite rules	Web server layer	High traffic, need to avoid PHP boot for wrong host
Cloudflare Workers / edge logic	CDN edge	Multi‑region, want routing before origin

Common breakage: A plugin checks $_SERVER['HTTP_HOST'] but the request arrives via a load balancer sending X-Forwarded-Host. The plugin sees the balancer hostname, matches no context, and falls back to web — serving the wrong site. Fix: read X-Forwarded-Host (validated against a trusted proxy list) in your routing logic.

Trust and Data Boundaries

Contexts are an organizational boundary, not a security boundary. All contexts share:

• The same manager users and passwords
• The same database (tables prefixed per context only for resources, not users/sessions)
• The same PHP process and core/ codebase
• The same snippet/plugin execution environment

A compromised manager account, a malicious snippet, or a runaway query in one context affects every site. If you host a client’s site alongside your own, a vulnerability in their custom snippet can exfiltrate your data. For true tenant isolation, use separate MODX installations (containers or VMs).

Access Control: Least Privilege Per Context

MODX’s ACL system (User Groups → Roles → Context Access Policies) is granular but easy to misconfigure. Do not rely on the default “Editor” role — it grants access to all contexts. Instead:

1. Create a user group per context: Editors_site_en, Editors_site_de
2. Assign a role with a context‑specific policy: ResourceEditPolicy restricted to that context’s resource tree
3. Add users only to the groups matching sites they should edit
4. Test by logging in as a restricted editor — they should see only their context’s resources in the tree

Verify: In the manager, switch to the user’s context via the context dropdown (top‑left). If resources from other contexts appear, the policy is too broad.

Operational Checks That Catch Drift

MODX caches context settings aggressively (in core/cache/context_settings/ and the main config.cache.php). After any change to context settings, ACLs, or routing rules:

# From MODX root (requires shell access, same user as web server)
php core/cache/clear_cache.php
# Or via manager: Manage → Clear Cache → All

Diagnostic routine when a site serves wrong content or 404s:

1. Confirm the incoming Host header matches a context’s http_host exactly (including www vs non‑www)
2. Check core/cache/logs/error.log for “Context not found” or routing plugin errors
3. Clear cache, then request the homepage with curl -I https://site.example/ — verify X-Powered-By: MODX and correct HTML
4. If still wrong, temporarily add $_SESSION['modx.context.key'] = 'site_en'; in index.php before $modx->initialize() to force a context and isolate whether routing or resource resolution is at fault

Failure Modes and Their Symptoms

Failure	Symptom	Root Cause	Mitigation
Stale context cache	New site_url ignored; old domain redirects persist	Settings cached in context_settings/; not cleared after change	Automate cache clear in deployment pipeline
Gateway misroute	All domains show same homepage (usually web)	Plugin/web server rule matches wrong host or falls back silently	Log matched context key at OnHandleRequest; alert on unexpected fallback
Shared snippet context leak	Snippet reads $modx->getOption('site_url') and gets wrong site’s URL	Snippet uses global setting instead of $modx->context	Audit snippets for $modx->context usage; enforce in code review
Database contention	One site’s heavy query slows all contexts	Single DB, no query isolation	Monitor slow query log; move high‑load sites to separate installs
Media source collision	Editors upload to wrong site’s asset folder	Default media source not scoped per context	Create per‑context media sources with basePath: [[!++context_key]]/assets/

Conditions That Change the Design

Move to separate MODX installations (or containers) when any of these appear:

• Tenant isolation required: Client A must not share DB/users/code with Client B
• Independent release cycles: Site A needs MODX 3.1, Site B stays on 2.8
• Independent scaling: Site A gets 10× traffic; you need separate PHP‑FPM pools, DB read replicas, or CDN configs
• Regulatory data residency: Site A’s data must stay in EU, Site B in US
• Custom PHP extensions: One site needs imagick, another sodium, host only allows one PHP build

The migration path: export each context’s resources via modx export (or Packager), import into a fresh install, update DNS, and decommission the shared instance. Expect 2–4 hours per site for a clean cutover.

Verification Checklist Before Go‑Live

1. Create a second context (site_test) with distinct http_host/site_url, point a test hostname (e.g., test.local via /etc/hosts), confirm correct homepage renders
2. Log in as a restricted editor (only Editors_site_test group); verify tree shows only site_test resources
3. Change a context setting (e.g., site_name), clear cache, confirm change appears on frontend without manager reload
4. Break the gateway rule temporarily (rename plugin or comment Nginx map); request a known hostname and observe fallback — should be a 404 or explicit error, not silent wrong‑site render

Document the routing mechanism, cache‑clear procedure, and ACL group names in your runbook. Contexts are convenient until they’re not — know the exit criteria before you commit.
