Mixed Version Proxy

Feature state: Beta since Kubernetes v1.36; enabled by default

Kubernetes 1.37 includes a beta feature that lets an API Server proxy resource requests to other peer API servers. It also lets clients get a holistic view of resources served across the entire cluster through discovery. This is useful when there are multiple API servers running different versions of Kubernetes in one cluster (for example, during a long-lived rollout to a new release of Kubernetes).

This enables cluster administrators to configure highly available clusters that can be upgraded more safely, by :

1. ensuring that controllers relying on discovery to show a comprehensive list of resources for important tasks always get the complete view of all resources. We call this complete cluster-wide discovery Peer-aggregated discovery.
2. directing resource requests (made during the upgrade) to the correct kube-apiserver. This proxying prevents users from seeing unexpected 404 Not Found errors that stem from the upgrade process. This mechanism is called the Mixed Version Proxy.

Enabling Peer-aggregated Discovery and Mixed Version Proxy

Ensure that UnknownVersionInteroperabilityProxy feature gate is enabled when you start the API Server:

kube-apiserver \
--feature-gates=UnknownVersionInteroperabilityProxy=true \
# required command line arguments for this feature
--peer-ca-file=<path to kube-apiserver CA cert>
--proxy-client-cert-file=<path to aggregator proxy cert>,
--proxy-client-key-file=<path to aggregator proxy key>,
--requestheader-client-ca-file=<path to aggregator CA cert>,
# requestheader-allowed-names can be set to blank to allow any Common Name
--requestheader-allowed-names=<valid Common Names to verify proxy client cert against>,

# optional flags for this feature
--peer-advertise-ip=`IP of this kube-apiserver that should be used by peers to proxy requests`
--peer-advertise-port=`port of this kube-apiserver that should be used by peers to proxy requests`

# …and other flags as usual

Proxy transport and authentication between API servers

• The source kube-apiserver reuses the existing APIserver client authentication flags --proxy-client-cert-file and --proxy-client-key-file to present its identity that will be verified by its peer (the destination kube-apiserver). The destination API server verifies that peer connection based on the configuration you specify using the --requestheader-client-ca-file command line argument.

• To authenticate the destination server's serving certs, you must configure a certificate authority bundle by specifying the --peer-ca-file command line argument to the source API server.

Configuration for peer API server connectivity

To set the network location of a kube-apiserver that peers will use to proxy requests, use the --peer-advertise-ip and --peer-advertise-port command line arguments to kube-apiserver or specify these fields in the API server configuration file. If these flags are unspecified, peers will use the value from either --advertise-address or --bind-address command line argument to the kube-apiserver. If those too, are unset, the host's default interface is used.

Peer-aggregated discovery

When you enable the feature, discovery requests are automatically enabled to serve a comprehensive discovery document (listing all resources served by any apiserver in the cluster) by default.

If you would like to request a non peer-aggregated discovery document, you can indicate so by adding the following Accept header to the discovery request:

application/json;g=apidiscovery.k8s.io;v=v2;as=APIGroupDiscoveryList;profile=nopeer

Note:

Peer-aggregated discovery is only supported for Aggregated Discovery requests to the /apis endpoint and not for Unaggregated (Legacy) Discovery requests.

Mixed version proxying

When you enable mixed version proxying, the aggregation layer loads a special filter that does the following:

• When a resource request reaches an API server that cannot serve that API (either because it is at a version pre-dating the introduction of the API or the API is turned off on the API server) the API server attempts to send the request to a peer API server that can serve the requested API. It does so by identifying API groups / versions / resources that the local server doesn't recognise, and tries to proxy those requests to a peer API server that is capable of handling the request.
• If the peer API server fails to respond, the source API server responds with 503 ("Service Unavailable") error.

How it works under the hood

When an API Server receives a resource request, it first checks which API servers can serve the requested resource. This check happens using the non peer-aggregated discovery document.

• If the resource is listed in the non peer-aggregated discovery document retrieved from the API server that received the request(for example, GET /api/v1/pods/some-pod), the request is handled locally.

• If the resource in a request (for example, GET /apis/resource.k8s.io/v1beta1/resourceclaims) is not found in the non peer-aggregated discovery document retrieved from the API server trying to handle the request (the handling API server), likely because the resource.k8s.io/v1beta1 API was introduced in a newer Kubernetes version and the handling API server is running an older version that does not support it, then the handling API server fetches the peer API servers that do serve the relevant API group / version / resource (resource.k8s.io/v1beta1/resourceclaims in this case) by checking the non peer-aggregated discovery documents from all peer API servers. The handling API server then proxies the request to one of the matching peer kube-apiservers that are aware of the requested resource.

• If there is no peer known for that API group / version / resource, the handling API server passes the request to its own handler chain which should eventually return a 404 ("Not Found") response.

• If the handling API server has identified and selected a peer API server, but that peer fails to respond (for reasons such as network connectivity issues, or a data race between the request being received and a controller registering the peer's info into the control plane), then the handling API server responds with a 503 ("Service Unavailable") error.
