Kubernetes: Network Plugins

Kubernetes (version 1.3 through to the latest 1.37, and likely onwards) lets you use Container Network Interface (CNI) plugins for cluster networking. You must use a CNI plugin that is compatible with your cluster and that suits your needs. Different plugins are available (both open- and closed- source) in the wider Kubernetes ecosystem.

A CNI plugin is required to implement the Kubernetes network model.

You must use a CNI plugin that is compatible with the v0.4.0 or later releases of the CNI specification. The Kubernetes project recommends using a plugin that is compatible with the v1.0.0 CNI specification (plugins can be compatible with multiple spec versions).

Installation

A Container Runtime, in the networking context, is a daemon on a node configured to provide CRI Services for kubelet. In particular, the Container Runtime must be configured to load the CNI plugins required to implement the Kubernetes network model.

Note:

Prior to Kubernetes 1.24, the CNI plugins could also be managed by the kubelet using the cni-bin-dir and network-plugin command-line parameters. These command-line parameters were removed in Kubernetes 1.24, with management of the CNI no longer in scope for kubelet.

See Troubleshooting CNI plugin-related errors if you are facing issues following the removal of dockershim.

For specific information about how a Container Runtime manages the CNI plugins, see the documentation for that Container Runtime, for example:

• containerd
• CRI-O

For specific information about how to install and manage a CNI plugin, see the documentation for that plugin or networking provider.

Network Plugin Requirements

Loopback CNI

In addition to the CNI plugin installed on the nodes for implementing the Kubernetes network model, Kubernetes also requires the container runtimes to provide a loopback interface lo, which is used for each sandbox (pod sandboxes, vm sandboxes, ...). Implementing the loopback interface can be accomplished by re-using the CNI loopback plugin. or by developing your own code to achieve this (see this example from CRI-O).

Support hostPort

The CNI networking plugin supports hostPort. You can use the official portmap plugin offered by the CNI plugin team or use your own plugin with portMapping functionality.

If you want to enable hostPort support, you must specify portMappings capability in your cni-conf-dir. For example:

{
  "name": "k8s-pod-network",
  "cniVersion": "0.4.0",
  "plugins": [
    {
      "type": "calico",
      "log_level": "info",
      "datastore_type": "kubernetes",
      "nodename": "127.0.0.1",
      "ipam": {
        "type": "host-local",
        "subnet": "usePodCidr"
      },
      "policy": {
        "type": "k8s"
      },
      "kubernetes": {
        "kubeconfig": "/etc/cni/net.d/calico-kubeconfig"
      }
    },
    {
      "type": "portmap",
      "capabilities": {"portMappings": true},
      "externalSetMarkChain": "KUBE-MARK-MASQ"
    }
  ]
}

Support traffic shaping

Experimental Feature

The CNI networking plugin also supports pod ingress and egress traffic shaping. You can use the official bandwidth plugin offered by the CNI plugin team or use your own plugin with bandwidth control functionality.

If you want to enable traffic shaping support, you must add the bandwidth plugin to your CNI configuration file (default /etc/cni/net.d) and ensure that the binary is included in your CNI bin dir (default /opt/cni/bin).

{
  "name": "k8s-pod-network",
  "cniVersion": "0.4.0",
  "plugins": [
    {
      "type": "calico",
      "log_level": "info",
      "datastore_type": "kubernetes",
      "nodename": "127.0.0.1",
      "ipam": {
        "type": "host-local",
        "subnet": "usePodCidr"
      },
      "policy": {
        "type": "k8s"
      },
      "kubernetes": {
        "kubeconfig": "/etc/cni/net.d/calico-kubeconfig"
      }
    },
    {
      "type": "bandwidth",
      "capabilities": {"bandwidth": true}
    }
  ]
}

Now you can add the kubernetes.io/ingress-bandwidth and kubernetes.io/egress-bandwidth annotations to your Pod. For example:

apiVersion: v1
kind: Pod
metadata:
  annotations:
    kubernetes.io/ingress-bandwidth: 1M
    kubernetes.io/egress-bandwidth: 1M
...
