Kubernetes: How DRA Works

This page describes how Kubernetes allocates devices to workloads with dynamic resource allocation (DRA), and how pre-scheduled Pods interact with the process.

How resource allocation with DRA works

The following sections describe the workflow for the various types of DRA users and for the Kubernetes system during dynamic resource allocation.

Workflow for users

1. Driver creation: device owners or third-party entities create drivers that can create and manage ResourceSlices in the cluster. These drivers optionally also create DeviceClasses that define a category of devices and how to request them.
2. Cluster configuration: cluster admins create clusters, attach devices to nodes, and install the DRA device drivers. Cluster admins optionally create DeviceClasses that define categories of devices and how to request them.
3. Resource claims: workload operators create ResourceClaimTemplates or ResourceClaims that request specific device configurations within a DeviceClass. In the same step, workload operators modify their Kubernetes manifests to request those ResourceClaimTemplates or ResourceClaims.

Workflow for Kubernetes

1. ResourceSlice creation: drivers in the cluster create ResourceSlices that represent one or more devices in a managed pool of similar devices.

2. Workload creation: the cluster control plane checks new workloads for references to ResourceClaimTemplates or to specific ResourceClaims.

   • If the workload uses a ResourceClaimTemplate, a controller named the resourceclaim-controller generates ResourceClaims for the workload.
   • If the workload uses a specific ResourceClaim, Kubernetes checks whether that ResourceClaim exists in the cluster. If the ResourceClaim doesn't exist, the Pods won't deploy.

3. ResourceSlice filtering: for every Pod, Kubernetes checks the ResourceSlices in the cluster to find a device that satisfies all of the following criteria:

   • The nodes that can access the resources are eligible to run the Pod.
   • The ResourceSlice has unallocated resources that match the requirements of the Pod's ResourceClaim.

4. Resource allocation: after finding an eligible ResourceSlice for a Pod's ResourceClaim, the Kubernetes scheduler updates the ResourceClaim with the allocation details. The scheduler uses a first-fit strategy and evaluates pools and ResourceSlices in lexicographical order by their names. Drivers can prioritize specific slices or pools by naming them appropriately. For details, see Naming and prioritization.

5. Pod scheduling: when resource allocation is complete, the scheduler places the Pod on a node that can access the allocated resource. The device driver and the kubelet on that node coordinate via gRPC to configure the device and the Pod's access to the device, unless the driver declared optional node operations for devices that do not require node-local preparation or cleanup.

Pre-scheduled Pods

When you - or another API client - create a Pod with spec.nodeName already set, the scheduler gets bypassed. If some ResourceClaim needed by that Pod does not exist yet, is not allocated or not reserved for the Pod, then the kubelet will fail to run the Pod and re-check periodically because those requirements might still get fulfilled later.

Such a situation can also arise when support for dynamic resource allocation was not enabled in the scheduler at the time when the Pod got scheduled (version skew, configuration, feature gate, etc.). kube-controller-manager detects this and tries to make the Pod runnable by reserving the required ResourceClaims. However, this only works if those were allocated by the scheduler for some other pod.

It is better to avoid bypassing the scheduler because a Pod that is assigned to a node blocks normal resources (RAM, CPU) that then cannot be used for other Pods while the Pod is stuck. To make a Pod run on a specific node while still going through the normal scheduling flow, create the Pod with a node selector that exactly matches the desired node:

apiVersion: v1
kind: Pod
metadata:
  name: pod-with-cats
spec:
  nodeSelector:
    kubernetes.io/hostname: name-of-the-intended-node
  ...

You may also be able to mutate the incoming Pod, at admission time, to unset the .spec.nodeName field and to use a node selector instead.

Device binding conditions

Feature state: Beta since Kubernetes v1.36; enabled by default

Device Binding Conditions allow the Kubernetes scheduler to delay Pod binding until external resources, such as fabric-attached GPUs or reprogrammable FPGAs, are confirmed to be ready.

This waiting behavior is implemented in the PreBind phase of the scheduling framework. During this phase, the scheduler checks whether all required device conditions are satisfied before proceeding with binding.

This improves scheduling reliability by avoiding premature binding and enables coordination with external device controllers.

To use this feature, device drivers (typically managed by driver owners) must publish the following fields in the Device section of a ResourceSlice. Cluster administrators must enable the DRADeviceBindingConditions and DRAResourceClaimDeviceStatus feature gates for the scheduler to honor these fields.

bindingConditionsA list of condition types that must be set to True (in the .status.conditions field of the associated ResourceClaim) before the Pod can be bound. These conditions typically represent readiness signals, such as DeviceAttached or DeviceInitialized.bindingFailureConditionsA list of condition types that, if set to True in status.conditions field of the associated ResourceClaim, indicate a failure state. If any of these conditions are True, the scheduler will abort binding and reschedule the Pod.bindsToNodeif set to true, the scheduler records the selected node name in the status.allocation.nodeSelector field of the ResourceClaim. This does not affect the Pod's spec.nodeSelector. Instead, it sets a node selector inside the ResourceClaim, which external controllers can use to perform node-specific operations such as device attachment or preparation.

All condition types listed in bindingConditions and bindingFailureConditions are evaluated from the status.conditions field of the ResourceClaim. External controllers are responsible for updating these conditions using standard Kubernetes condition semantics (type, status, reason, message, lastTransitionTime).

The scheduler waits up to 600 seconds (default) for all bindingConditions to become True. If the timeout is reached or any bindingFailureConditions are True, the scheduler clears the allocation and reschedules the Pod. A cluster administration can configure this timeout duration by editing the kube-scheduler configuration file.

An example of configuring this timeout in KubeSchedulerConfiguration is given below:

apiVersion: kubescheduler.config.k8s.io/v1
kind: KubeSchedulerConfiguration
profiles:
- schedulerName: default-scheduler
  pluginConfig:
  - name: DynamicResources
    args:
      apiVersion: kubescheduler.config.k8s.io/v1
      kind: DynamicResourcesArgs
      bindingTimeout: 60s

Example

Here is an example of a ResourceSlice that you might see in a cluster where there's a DRA driver in use, and that driver supports binding conditions:

apiVersion: resource.k8s.io/v1
kind: ResourceSlice
metadata:
  name: gpu-slice-1
spec:
  driver: dra.example.com
  nodeSelector:
    nodeSelectorTerms:
    - matchExpressions:
      - key: accelerator-type
        operator: In
        values:
        - "high-performance"
  pool:
    name: gpu-pool
    generation: 1
    resourceSliceCount: 1
  devices:
    - name: gpu-1
      attributes:
        vendor:
          string: "example"
        model:
          string: "example-gpu"
      bindsToNode: true
      bindingConditions:
        - dra.example.com/is-prepared
      bindingFailureConditions:
        - dra.example.com/preparing-failed

This example ResourceSlice has the following properties:

• The ResourceSlice targets nodes labeled with accelerator-type=high-performance, so that the scheduler uses only a specific set of eligible nodes.
• The scheduler selects one node from the selected group (for example, node-3) and sets the status.allocation.nodeSelector field in the ResourceClaim to that node name.
• The dra.example.com/is-prepared binding condition indicates that the device gpu-1 must be prepared (the is-prepared condition has a status of True) before binding.
• If the gpu-1 device preparation fails (the preparing-failed condition has a status of True), the scheduler aborts binding.
• The scheduler waits up to 600 seconds (default) for the device to become ready.
• External controllers can use the node selector in the ResourceClaim to perform node-specific setup on the selected node.

Device binding conditions is controlled by the DRADeviceBindingConditions feature gate in the kube-apiserver and kube-scheduler.

Node allocatable resources

Feature state: Alpha since Kubernetes v1.36; disabled by defaultMore information about this feature

To use this feature, you (or a cluster administrator) will need to enable the DRANodeAllocatableResources feature gate for all relevant components in your cluster.

See Enable Or Disable Feature Gates for more information.

Devices managed by DRA can have an underlying footprint composed of node allocatable resources, such as cpu, memory, or hugepages. This feature integrates these DRA-based requests into the scheduler's standard accounting alongside regular Pod spec requests for these resources.

DRA drivers define how devices consume node allocatable resources using two distinct models:

• Direct Resource Mapping (mapping): The DRA device directly provides a standard node resource (such as a custom CPU core pool or memory block). The claim allocation directly maps to standard CPU or memory capacity on the node.
• Auxiliary Device Overhead (overhead): The DRA device (such as a GPU or accelerator) requires host resources (such as host RAM) as secondary overhead to operate when allocated to a Pod or container.

Considerations for Pod Authors

When authoring a PodSpec using claims for these types of devices, there are a few things to be aware of:

• When Pod-level resources are used, the scheduler strictly validates them against both container requests and limits:
  • The sum of all container requests and DRA claim resources must not exceed the Pod-level requests; otherwise, the Pod will fail to schedule.
  • Each individual container's limit plus its DRA allocations must not exceed the Pod-level limits; otherwise, the Pod will fail to schedule.
• A container's total resource requirement is the sum of its container-level resources and any node allocatable resources from its associated resource claims.
• Claim Sharing Restriction: Claims that use direct resource mappings (mapping) cannot be shared across multiple Pods. Claims for devices with overhead can support device sharing and overhead is tracked per Pod or per container.
• Pods with DRA claims support in-place resizing for standard requests in spec. The scheduler ensures that resized standard requests combined with static DRA allocations still fit on the node.

Details for DRA Driver Authors

DRA drivers declare this node allocatable resource footprint using the nodeAllocatableResources field on devices within a ResourceSlice. This defines the translation of the requested DRA device or capacity into standard resources that are tracked in the node's status.allocatable (note that extended resources are not supported for this field). This is useful both for drivers that directly expose native resources (like a CPU or Memory DRA driver) and for devices that require auxiliary node dependencies (like an accelerator that needs host memory).

The nodeAllocatableResources field supports two different use cases:

• Mapping: Used when the DRA device directly represents the standard resource (e.g., a CPU or Memory DRA driver). The scheduler calculates the exact quantity by scaling the capacity using capacityMultiplier, or scaling the device count using deviceMultiplier.
• Overhead: Used when the device requires auxiliary node dependencies (e.g., host memory consumed by a GPU). This can be defined as a flat perPod cost or a variable perContainer cost that scales linearly with the number of referencing containers.

Example: CPU DRA Driver (Mapping)

Here is an example where a CPU DRA driver exposes a CPU socket as a pool of 128 CPUs using DRA consumable capacity. The capacityKey links the consumed cpu.example.com/cpu capacity directly to the node's standard cpu allocatable resource:

apiVersion: resource.k8s.io/v1
kind: ResourceSlice
metadata:
  name: my-node-cpus
spec:
  driver: cpu.example.com
  nodeName: my-node
  pool:
    name: socket-cpus
    generation: 1
    resourceSliceCount: 1
  devices:
  - name: socket0cpus
    allowMultipleAllocations: true
    capacity:
      "cpu.example.com/cpu": "128"
    nodeAllocatableResources:
      mapping:
        cpu:
          capacityKey: "cpu.example.com/cpu"
  - name: socket1cpus
    allowMultipleAllocations: true
    capacity:
      "cpu.example.com/cpu": "128"
    nodeAllocatableResources:
      mapping:
        cpu:
          capacityKey: "cpu.example.com/cpu"
          capacityMultiplier: 1

Example: Accelerator with Auxiliary Resources (Overhead)

Here is an example of a resource slice where an accelerator requires an additional 8Gi of memory per Pod to function:

apiVersion: resource.k8s.io/v1
kind: ResourceSlice
metadata:
  name: my-node-xpus
spec:
  driver: xpu.example.com
  nodeName: my-node
  pool:
    name: xpu-pool
    generation: 1
    resourceSliceCount: 1
  devices:
  - name: xpu-model-x-001
    attributes:
      example.com/model:
        string: "model-x"
    nodeAllocatableResources:
      overhead:
        memory:
          perPod: "8Gi"

After a Pod is successfully bound to the node, the exact quantities of node allocatable resources allocated via DRA are aggregated by the kube-scheduler and embedded directly into the Pod's status.nodeAllocatableResourceClaimStatuses field. This provides a clear, persistent handoff from the scheduler to the kubelet.

Crucially, the kubelet natively consumes this API to perfectly align system-level boundaries:

• cgroups: Pod and container cgroups would now include DRA based allocations, preventing workloads from being artificially throttled by the kernel.
• OOM Scores: The kubelet factors the container's DRA memory requests into its effective memory request.

Node allocatable resources is an alpha feature and is enabled when the DRANodeAllocatableResources feature gate is enabled in the kube-apiserver, kube-scheduler, and kubelet.
