Kubernetes: Annotations

You can use Kubernetes annotations to attach arbitrary non-identifying metadata to objects. Clients such as tools and libraries can retrieve this metadata.

Attaching metadata to objects

You can use either labels or annotations to attach metadata to Kubernetes objects. Labels can be used to select objects and to find collections of objects that satisfy certain conditions. In contrast, annotations are not used to identify and select objects. The metadata in an annotation can be small or large, structured or unstructured, and can include characters not permitted by labels. It is possible to use labels as well as annotations in the metadata of the same object.

Annotations, like labels, are key/value maps:

"metadata": {
  "annotations": {
    "key1" : "value1",
    "key2" : "value2"
  }
}

Note:

The keys and the values in the map must be strings. In other words, you cannot use numeric, boolean, list or other types for either the keys or the values.

Here are some examples of information that could be recorded in annotations:

• Fields managed by a declarative configuration layer. Attaching these fields as annotations distinguishes them from default values set by clients or servers, and from auto-generated fields and fields set by auto-sizing or auto-scaling systems.

• Build, release, or image information like timestamps, release IDs, git branch, PR numbers, image hashes, and registry address.

• Pointers to logging, monitoring, analytics, or audit repositories.

• Client library or tool information that can be used for debugging purposes: for example, name, version, and build information.

• User or tool/system provenance information, such as URLs of related objects from other ecosystem components.

• Lightweight rollout tool metadata: for example, config or checkpoints.

• Phone or pager numbers of persons responsible, or directory entries that specify where that information can be found, such as a team web site.

• Directives from the end-user to the implementations to modify behavior or engage non-standard features.

Instead of using annotations, you could store this type of information in an external database or directory, but that would make it much harder to produce shared client libraries and tools for deployment, management, introspection, and the like.

Syntax and character set

Annotations are key/value pairs. Valid annotation keys have two segments: an optional prefix and name, separated by a slash (/). The name segment is required and must be 63 characters or less, beginning and ending with an alphanumeric character ([a-z0-9A-Z]) with dashes (-), underscores (_), dots (.), and alphanumerics between. The prefix is optional. If specified, the prefix must be a DNS subdomain: a series of DNS labels separated by dots (.), not longer than 253 characters in total, followed by a slash (/).

If the prefix is omitted, the annotation Key is presumed to be private to the user. Automated system components (e.g. kube-scheduler, kube-controller-manager, kube-apiserver, kubectl, or other third-party automation) which add annotations to end-user objects must specify a prefix.

The kubernetes.io/ and k8s.io/ prefixes are reserved for Kubernetes core components.

Valid annotation values have no character set restrictions — unlike label values, annotation values may contain any string, including special characters, whitespace, and structured data such as JSON or YAML. If you plan to store binary data (such as CBOR), the Kubernetes project recommends that you base64 encode it. However, the total size of all annotations on a single object (keys and values combined) must not exceed 256 KiB.

For example, here's a manifest for a Pod that has the annotation imageregistry: https://hub.docker.com/ :

apiVersion: v1
kind: Pod
metadata:
  name: annotations-demo
  annotations:
    imageregistry: "https://hub.docker.com/"
spec:
  containers:
  - name: nginx
    image: nginx:1.14.2
    ports:
    - containerPort: 80
