Kubernetes: About cgroup v2

On Linux, control groups constrain resources that are allocated to processes.

The kubelet and the underlying container runtime need to interface with cgroups to enforce resource management for pods and containers which includes cpu/memory requests and limits for containerized workloads.

There are two versions of cgroups in Linux: cgroup v1 and cgroup v2. cgroup v2 is the new generation of the cgroup API.

What is cgroup v2?

Feature state: Stable since Kubernetes v1.25

cgroup v2 is the next version of the Linux cgroup API. cgroup v2 provides a unified control system with enhanced resource management capabilities.

cgroup v2 offers several improvements over cgroup v1, such as the following:

• Single unified hierarchy design in API
• Safer sub-tree delegation to containers
• Newer features like Pressure Stall Information
• Enhanced resource allocation management and isolation across multiple resources
  • Unified accounting for different types of memory allocations (network memory, kernel memory, etc)
  • Accounting for non-immediate resource changes such as page cache write backs

Some Kubernetes features exclusively use cgroup v2 for enhanced resource management and isolation. For example, the MemoryQoS feature improves memory QoS and relies on cgroup v2 primitives.

Using cgroup v2

The recommended way to use cgroup v2 is to use a Linux distribution that enables and uses cgroup v2 by default.

To check if your distribution uses cgroup v2, refer to Identify cgroup version on Linux nodes.

Requirements

cgroup v2 has the following requirements:

• OS distribution enables cgroup v2
• Linux Kernel version is 5.8 or later
• Container runtime supports cgroup v2. For example:
  • containerd v1.4 and later
  • cri-o v1.20 and later
• The kubelet and the container runtime are configured to use the systemd cgroup driver

Linux Distribution cgroup v2 support

For a list of Linux distributions that use cgroup v2, refer to the cgroup v2 documentation

• Container Optimized OS (since M97)
• Ubuntu (since 21.10, 22.04+ recommended)
• Debian GNU/Linux (since Debian 11 bullseye)
• Fedora (since 31)
• Arch Linux (since April 2021)
• RHEL and RHEL-like distributions (since 9)

To check if your distribution is using cgroup v2, refer to your distribution's documentation or follow the instructions in Identify the cgroup version on Linux nodes.

You can also enable cgroup v2 manually on your Linux distribution by modifying the kernel cmdline boot arguments. If your distribution uses GRUB, systemd.unified_cgroup_hierarchy=1 should be added in GRUB_CMDLINE_LINUX under /etc/default/grub, followed by sudo update-grub. However, the recommended approach is to use a distribution that already enables cgroup v2 by default.

Migrating to cgroup v2

To migrate to cgroup v2, ensure that you meet the requirements, then upgrade to a kernel version that enables cgroup v2 by default.

The kubelet automatically detects that the OS is running on cgroup v2 and performs accordingly with no additional configuration required.

There should not be any noticeable difference in the user experience when switching to cgroup v2, unless users are accessing the cgroup file system directly, either on the node or from within the containers.

cgroup v2 uses a different API than cgroup v1, so if there are any applications that directly access the cgroup file system, they need to be updated to newer versions that support cgroup v2. For example:

• Some third-party monitoring and security agents may depend on the cgroup filesystem. Update these agents to versions that support cgroup v2.
• If you run cAdvisor as a stand-alone DaemonSet for monitoring pods and containers, update it to v0.43.0 or later.
• If you deploy Java applications, prefer to use versions which fully support cgroup v2:
  • OpenJDK / HotSpot: jdk8u372, 11.0.16, 15 and later
  • IBM Semeru Runtimes: 8.0.382.0, 11.0.20.0, 17.0.8.0, and later
  • IBM Java: 8.0.8.6 and later
• If you are using the uber-go/automaxprocs package, make sure the version you use is v1.5.1 or higher.
• If you deploy Node.js applications, prefer to use versions that detect cgroup v2 memory limits. Node.js reads cgroup v2 memory limits (through libuv) starting with Node.js v20.3.0. The v18 release line does not reliably detect cgroup v2 memory limits. Versions without this support may read the host's total memory instead of the limit applied to the pod, which can lead to an incorrectly sized heap and out-of-memory (OOM) terminations. On affected versions, set the heap size explicitly, for example with the --max-old-space-size flag.

Identify the cgroup version on Linux Nodes

The cgroup version depends on the Linux distribution being used and the default cgroup version configured on the OS. To check which cgroup version your distribution uses, run the stat -fc %T /sys/fs/cgroup/ command on the node:

stat -fc %T /sys/fs/cgroup/

For cgroup v2, the output is cgroup2fs.

For cgroup v1, the output is tmpfs.

Deprecation of cgroup v1

Feature state: Deprecated since Kubernetes v1.35

Kubernetes has deprecated cgroup v1. Removal will follow Kubernetes deprecation policy.

Kubelet will no longer start on a cgroup v1 node by default. To disable this setting a cluster admin should set failCgroupV1 to false in the kubelet configuration file.
