Enable HTTP/2 on Apache Tomcat 9 and 10 with TLS and ALPN

Desired outcome

Configure Apache Tomcat to accept HTTP/2 connections over TLS so clients that support ALPN can negotiate HTTP/2, while older clients continue working over HTTP/1.1 on the same port.

Prerequisites

• Apache Tomcat 9.0.30 or later, or Tomcat 10.0.0 or later.
• A Java runtime with ALPN support. Tomcat 9 on Java 8 may require the ALPN boot classpath; Java 9 and later, including the Java 11+ runtime used by Tomcat 10, include ALPN support in the JDK.
• A TLS keystore in JKS or PKCS12 format for the connector.
• Write access to $CATALINA_HOME/conf/server.xml and permission to restart the Tomcat service.

ALPN (Application-Layer Protocol Negotiation) is a TLS extension that lets the client and server agree on HTTP/2 during the handshake. $CATALINA_HOME is the Tomcat installation directory.

Configure the HTTP/2 connector

1. Open $CATALINA_HOME/conf/server.xml on the server running Tomcat.
2. Add or replace an HTTPS connector using the HTTP/2 protocol handler:

<Connector
    port="8443"
    protocol="org.apache.coyote.http2.Http2Protocol"
    maxThreads="200"
    scheme="https"
    secure="true"
    SSLEnabled="true"
    keystoreFile="/etc/tomcat/keystore.jks"
    keystorePass="changeit"
    clientAuth="false"
    sslProtocol="TLS"/>

Run the edit as the user who owns the Tomcat installation, commonly tomcat or root depending on your package layout. Replace /etc/tomcat/keystore.jks and changeit with your keystore path and password.

1. Save the file and restart Tomcat:

sudo systemctl restart tomcat

Risk: an incorrect keystore path, password, or missing ALPN provider can prevent Tomcat from starting. Back up server.xml before editing so you can restore the previous connector quickly.

Verify HTTP/2 negotiation

1. From a client that can reach the server, run:

curl -I --http2 https://localhost:8443

Expected check: the first line should read HTTP/2 200. If you see HTTP/1.1 200, the client did not negotiate HTTP/2.

1. Confirm ALPN directly with OpenSSL:

openssl s_client -connect localhost:8443 -alpn h2

Expected check: the output should show ALPN selecting h2. If ALPN is absent or empty, the JVM or connector configuration does not support HTTP/2 negotiation.

1. Watch Tomcat startup logs while the service restarts. Look for connector initialization errors; a missing ALPN provider usually appears as a failure to initialize the HTTPS connector rather than a guaranteed success message.

Limitations and fallback behavior

• HTTP/2 is only used when the client offers it during TLS negotiation. Clients without ALPN automatically fall back to HTTP/1.1 on the same connector.
• A reverse proxy in front of Tomcat must also support ALPN and HTTP/2 to the client; otherwise end users will not see HTTP/2 even if Tomcat is configured correctly.
• Large request headers or bodies may need larger maxHttpHeaderSize or maxPostSize values to avoid 400 errors.

Rollback

Because editing server.xml changes server state, restore the previous connector or comment out the HTTP/2 connector and restart:

sudo systemctl restart tomcat

Verify that HTTPS still works over HTTP/1.1 with:

curl -I --http1.1 https://localhost:8443
