Diagnosing HTTP/2 Enablement Issues in Tomcat 9+ with the NIO2 Connector

Recognizable Condition

Clients connect to https://…:8443 and receive a 400 Bad Request or the Tomcat log contains:

2026-10-14 18:01:44,123 ERROR [http-nio-8443-exec-1] org.apache.coyote.http11.Http11Nio2Protocol - Failed to accept HTTP/2 connection: ALPN not available

Despite the connector being configured for HTTP/2, the upgrade never occurs. The goal is to determine why.

Common Causes & Diagnostic Table

Cause	Diagnostic Check	Expected Log
Missing ALPN provider on the JVM classpath	Check if alpn-boot-*.jar is present or if the JDK has built‑in ALPN	"ALPN not available" error
Connector not upgraded to HTTP/2	Verify <upgradeProtocol> entry in server.xml	"Failed to accept HTTP/2 connection"
TLS protocol limited to TLSv1.0/1.1	Inspect sslProtocol or sslEnabledProtocols	"Failed to accept HTTP/2 connection"
Firewall blocks port 8443	Run telnet 127.0.0.1 8443 or nc -vz	No TLS handshake, connection reset

Ordered Checks

1. Verify Connector Configuration

   In conf/server.xml confirm the connector uses the NIO2 protocol and includes the HTTP/2 upgrade protocol:

   <Connector port="8443" protocol="org.apache.coyote.http11.Http11Nio2Protocol"
           maxThreads="200" scheme="https" secure="true" SSLEnabled="true"
           sslProtocol="TLS"
           keyAlias="tomcat" keyPass="changeit" keyStoreFile="/path/to/keystore.p12" keyStorePass="changeit"
           keyStoreType="PKCS12"
           clientAuth="false"
           sslEnabledProtocols="TLSv1.2,TLSv1.3"
           org.apache.coyote.http2.Http2Protocol
           >


   Missing the <upgradeProtocol> tag will prevent HTTP/2 negotiation.

2. Check ALPN Availability

   Run:

   java -jar alpn-boot-version.jar -verbose


   If the JVM is 8u261+ or 9+, ALPN may already be built‑in. Verify by inspecting java -XshowSettings:properties -version for jdk.http2.provider or by checking the log for ALPN not available.

3. Validate TLS Protocols

   HTTP/2 requires TLSv1.2 or higher. Ensure the connector’s sslEnabledProtocols includes them. Run:

   openssl s_client -connect localhost:8443 -tls1_2


   A successful handshake indicates the server accepts TLSv1.2.

4. Test the Upgrade Path

   From a client that supports HTTP/2 (modern browsers or curl 7.62+), issue:

   curl -I --http2 https://localhost:8443/


   Expect a response line like HTTP/2 200. If the status line shows HTTP/1.1, the upgrade failed.

5. Check Firewall / Network Filters

   Verify that port 8443 is reachable from the client machine:

   telnet localhost 8443
   # or
   nc -vz localhost 8443


   Connection timeouts or refusals point to a network block.

Fixes Tied to Findings

• ALPN Provider Missing

  Download the appropriate alpn-boot jar for your JDK and place it in $CATALINA_HOME/lib or add it to the JVM classpath:

  java -cp alpn-boot-version.jar -jar bootstrap.jar


  Restart Tomcat and confirm the log no longer shows the ALPN error.

• Connector Not Upgraded

  Add or correct the <upgradeProtocol> entry as shown above. Restart Tomcat.

• TLS Version Too Low

  Update sslEnabledProtocols to TLSv1.2,TLSv1.3 or remove the attribute to let Tomcat default to the JDK’s enabled protocols. Restart.

• Firewall Blocking Port

  Open the port in the host firewall (e.g., ufw allow 8443/tcp or iptables -A INPUT -p tcp --dport 8443 -j ACCEPT). Re‑run the connectivity test.

• Client Compatibility

  Ensure the client supports HTTP/2. If using older browsers, plan for graceful fallback to HTTP/1.1 by keeping the upgrade protocol optional.

Escalation Criteria

If after applying the above fixes the server still logs ALPN not available or clients cannot upgrade, consider:

• Verify that the JDK version supports ALPN natively (Java 9+). If using Java 8, ensure the ALPN jar matches the exact JDK build.
• Check for classpath conflicts: another library may provide a conflicting ALPN implementation. Use java -verbose:class to trace the loading of org.eclipse.jetty.alpn.ALPN or similar classes.
• Inspect the catalina.out log for stack traces that reference the servlet container’s HTTP/2 module. A missing org.apache.coyote.http2.Http2Protocol class indicates the module wasn’t packaged.
• Consult the Tomcat issue tracker or community mailing list for known bugs in the specific Tomcat version (e.g., 9.0.89 had a regression with ALPN on OpenJDK 11).

Practical Verification Checklist

1. Restart Tomcat after changes.
2. Run curl -I --http2 https://localhost:8443/ and confirm HTTP/2 200 in the response line.
3. Look for no ALPN not available entries in catalina.out.
4. Verify openssl s_client -connect localhost:8443 -tls1_2 succeeds.

By following this step‑by‑step diagnostic path you can isolate the root cause of HTTP/2 failure in Tomcat 9+ and apply the appropriate fix, ensuring secure, multiplexed connections for modern web clients.
