Diagnosing Persisted Query Failures in Apollo GraphQL: A Step‑by‑Step Guide

Problem Overview

When an Apollo Client request returns a PersistedQueryNotFound or PersistedQueryNotSupported error, the client has sent a persisted query ID that the server cannot process. The error can surface after a deployment, a server restart, or a client bundle rebuild. It typically manifests as a GraphQL error in the response body, sometimes accompanied by a 404 or 500 status code.

Recognizable Condition

Typical symptoms:

• The client logs a GraphQL error with PersistedQueryNotFound or PersistedQueryNotSupported.
• The network tab shows a POST to /graphql with the header x-apollo-persisted-query-id but no query field.
• The server logs indicate PersistedQueryNotFound or that persisted queries are disabled.
• Occasional 404/500 responses appear when the client falls back to a full query.

Cause & Diagnostic Table

Cause	Diagnostic Check	Typical Fix
Server lacks persisted query cache entry	Confirm server logs show PersistedQueryNotFound for the hash.	Reload persisted queries on startup or persist cache to disk/Redis.
Persisted queries disabled in server config	Check persistedQueries option in ApolloServer constructor.	Enable persisted queries or add persistedQueries: { cache: new InMemoryLRUCache() }.
Client and server use different hash algorithms	Verify both use SHA‑256 of the query string.	Align hash strategy or upgrade both libraries to the same major version.
Client bundle missing persistedQueries plugin	Inspect build output for persistedQueries plugin registration.	Add persistedQueries plugin to client build.
CORS stripping x-apollo-persisted-query-id	Use devtools to confirm header is sent and not removed by proxy.	Configure CORS to allow custom headers or adjust proxy settings.
Server restart cleared in‑memory cache	Check if persisted queries are loaded on startup.	Persist queries to a shared store (Redis, file) and load them on boot.
Version mismatch between client and server	Confirm both use compatible Apollo packages (e.g., @apollo/server 4.x).	Upgrade or downgrade to matching major versions.

Ordered Diagnostic Checklist

1. Confirm the client is sending the persisted query ID.

   # In browser devtools, Network tab
   Request Headers:
     x-apollo-persisted-query-id: <hash>


   Run the client with networkInterface: { log: true } to print the outgoing headers. If the header is missing, the client isn’t using persisted queries.

2. Verify server accepts persisted queries.

   const server = new ApolloServer({
     typeDefs,
     resolvers,
     persistedQueries: { cache: new InMemoryLRUCache() }, // required
   });


   Check the server startup logs for "Persisted queries enabled". If absent, add the persistedQueries option.

3. Test the persisted query ID manually.

   curl -X POST \
     https://api.example.com/graphql \
     -H "Content-Type: application/json" \
     -d '{"extensions":{"persistedQuery":{"version":1,"sha256Hash":"<hash>"}}}'


   Expect a 200 response with data. A 404 indicates the server doesn’t recognize the hash.

4. Check server logs for cache hits.

   # In server code
   server.setPlugin({
     requestDidStart: () => ({
       willSendResponse: ({ request, response }) => {
         console.log(request.extensions?.persistedQuery?.found);
       },
     }),
   });


   Logs should show true for found. If false, the cache is missing the entry.

5. Validate hash algorithm consistency.

   // Both client and server
   const hash = crypto.createHash('sha256').update(queryString).digest('hex');


   Ensure no whitespace or formatting changes alter the string before hashing.

6. Inspect CORS configuration.

   app.use(cors({
     allowedHeaders: ['Content-Type', 'x-apollo-persisted-query-id'],
   }));


   Missing x-apollo-persisted-query-id in allowedHeaders will cause the header to be stripped.

7. Check shared cache across instances.

   const cache = new RedisCache({
     client: redisClient,
     namespace: 'apollo:persisted-queries',
   });


   Ensure all server instances point to the same Redis namespace.

8. Confirm fallback path works.

   // Temporarily disable persisted queries
   const server = new ApolloServer({
     typeDefs,
     resolvers,
     persistedQueries: false,
   });


   Send the same request; if it succeeds, the persisted query mechanism is the culprit.

Fixes Tied to Findings

• Reload persisted queries on startup. Add a script that reads the persisted query file and populates the cache before the server starts.
• Persist cache to disk or Redis. Use RedisCache or FileCache from @apollo/server.
• Align client and server versions. Run npm ls @apollo/client @apollo/server and bump to matching major releases.
• Enable custom header in CORS. Add x-apollo-persisted-query-id to allowedHeaders.
• Verify build includes persistedQueries plugin. Check the Webpack/Rollup config for persistedQueries.

Escalation Criteria

If after following the checklist the error persists:

• Check network logs for proxy or CDN stripping the header.
• Review server logs for permission issues accessing the persisted query store.
• Enable debug mode in Apollo Server and capture the full error stack.
• Raise an issue on the Apollo GitHub repository with reproducible steps and the minimal config that triggers the failure.

Practical Verification

After applying a fix, run a simple end‑to‑end test:

1. Build the client bundle.
2. Restart the server.
3. Open the application and trigger the query.
4. Verify the network request contains x-apollo-persisted-query-id and receives a 200 response.
5. Check server logs for PersistedQueryFound entry.

If all steps succeed, the persisted query flow is restored.
