Configure Apollo Client InMemoryCache Field Policies for Paginated Queries

Desired Outcome

Configure Apollo Client's InMemoryCache with field policies so that fetchMore results for paginated lists merge into a single cached list without duplicates or gaps. This applies to both offset/limit and cursor‑based (Relay) pagination.

Prerequisites

• Apollo Client 3.x (@apollo/client) installed
• A GraphQL schema exposing paginated fields — either offset/limit arguments or Relay cursor connections (after/first, before/last)
• An existing InMemoryCache instance in your ApolloClient setup

Procedure

1. Define a TypePolicy for the paginated field

When creating the InMemoryCache, add a typePolicies entry that targets the type owning the field (usually Query for root fields or the parent object type for nested fields).

import { ApolloClient, InMemoryCache } from '@apollo/client';

const cache = new InMemoryCache({
  typePolicies: {
    Query: {
      fields: {
        // Offset/limit example
        products: {
          keyArgs: ['offset', 'limit', 'filter'],
          merge(existing = [], incoming, { args }) {
            if (args?.offset === 0) {
              return incoming; // first page replaces
            }
            return [...existing, ...incoming]; // append subsequent pages
          },
        },
        // Cursor‑based (Relay) example
        users: {
          keyArgs: ['after', 'first', 'filter'],
          merge(existing, incoming, { args }) {
            if (!existing) return incoming;
            if (args?.after == null) return incoming; // first page (no cursor)
            return {
              ...incoming,
              edges: [...existing.edges, ...incoming.edges],
            };
          },
        },
      },
    },
  },
});

const client = new ApolloClient({ cache });

2. Understand keyArgs behavior

keyArgs tells the cache which argument combinations should create separate entries. Include every pagination argument that should not split the cache:

• Offset/limit: ['offset', 'limit', 'filter'] – each unique filter gets its own list; offset/limit variations merge into that list
• Cursor‑based: ['after', 'first', 'filter'] – same principle
• Omitting keyArgs merges all argument combinations into one list, breaking pagination
• Setting keyArgs: false creates a separate entry per argument set, preventing merge

3. Write the merge function

The merge function receives (existing, incoming, { args, isReference, toReference }). Handle the first page and subsequent pages:

• First page: existing is undefined or args indicate first page (offset === 0 or no cursor). Return incoming directly.
• Subsequent pages: For offset/limit, concatenate arrays. For cursor connections, append edges while preserving pageInfo from incoming (it reflects the latest page).
• Non‑array fields: If the field returns an object with edges/nodes plus totalCount, merge the array portion and keep other fields from incoming.

4. Optional: Add a read function

A read function lets you return a slice of the cached list without a network request when the requested range is already present.

products: {
  keyArgs: ['offset', 'limit', 'filter'],
  merge(existing = [], incoming, { args }) {
    if (args?.offset === 0) return incoming;
    return [...existing, ...incoming];
  },
  read(existing, { args, toReference }) {
    if (!existing) return existing;
    const offset = args?.offset ?? 0;
    const limit = args?.limit ?? existing.length;
    return existing.slice(offset, offset + limit);
  },
}

Expected Checks

1. Cache inspection: Open Apollo DevTools → Cache tab. Verify a single entry for the field (e.g., Query.products) containing all fetched items in order.
2. No duplicate __ref entries: Each item should appear once. Duplicates indicate incorrect keyArgs or a merge function that doesn't deduplicate.
3. Network behavior: Only the first page and subsequent fetchMore calls fire network requests. Re‑reading the same page hits the cache.
4. Query consistency: A query with the original arguments returns the full merged list (or the sliced portion if a read function is defined).

Recovery Options

Evict and refetch a single field

// In a component or after a mutation
cache.evict({ fieldName: 'products' });
// Or with specific arguments
cache.evict({ id: 'ROOT_QUERY', fieldName: 'products', args: { filter: 'active' } });
// Then trigger a refetch
refetch(); // from useQuery

Reset entire cache

cache.reset(); // clears all normalized data
// Or create a fresh client (useful on logout)
const newClient = new ApolloClient({ cache: new InMemoryCache({ /* same policies */ }) });

Iterate on the policy

• Add missing filter arguments to keyArgs
• Handle existing === undefined in the merge function
• Preserve pageInfo from incoming for cursor pagination
