Diagnosing k6 Thresholds That Do Not Trigger

Recognizable condition

You run a k6 test and the final output shows a thresholds section with all PASS results, but you expected at least one FAIL because a metric (e.g., response time) exceeded the limit you defined.

Cause / diagnostic table

Symptom	Likely cause
Threshold never evaluates (no PASS/FAIL line)	Metric name in threshold does not match any collected metric
Threshold evaluates but always PASS despite high values	Wrong aggregation (e.g., using avg on a spiky metric) or threshold value too lax
Metric absent from output	Metric not enabled (missing --out, --summary-export, or not collected by default)
Threshold defined but ignored after test	Threshold object placed incorrectly (e.g., inside a function) or overridden later in script

Ordered checks

1. Verify metric collection

   Run the test with --vus 1 --duration 10s and look for the metric in the metrics section of the output. Example:

   k6 run --vus 1 --duration 10s script.js

   If the metric (e.g., http_req_duration) does not appear, it is not being collected.

2. Confirm threshold syntax

   Check that the key in the thresholds object exactly matches the metric name as printed (case‑sensitive).

   export const options = {
     thresholds: {
       'http_req_duration': ['avg<200']   // note the quotes and exact name
     }
   };

3. Inspect aggregation window

   Some metrics (like http_reqs) are counters; thresholds on raw counters may need a rate or sum. Ensure you are using the appropriate aggregation function (avg, p(95), max, etc.).

4. Review test execution logs

   Add --log-level debug to see if k6 reports "no samples" for the metric. Missing samples indicate the metric was not generated during the test.

   k6 run --vus 10 --duration 30s --log-level debug script.js

5. Ensure sufficient iterations

   If the test ends before any iteration completes (e.g., --duration 1s with a 2‑second init), there may be no data to evaluate. Increase VUs or duration.

Fixes tied to findings

• Metric name mismatch – Rename the threshold key to match the exact metric string shown in the output.
• Wrong aggregation – Change the aggregation function; for latency spikes consider p(95)<500 instead of avg<200.
• Metric not collected – Enable the metric explicitly, e.g., add --out json=results.json or ensure the relevant http call is made in the script.
• Threshold placed incorrectly – Move the thresholds object to the top level of the options export.
• Insufficient data – Raise vus or duration to guarantee at least one sample.

Escalation criteria

If after completing the ordered checks the threshold still does not fire:

1. Create a minimal reproducible script (see example below) that isolates the issue.
2. Capture the full k6 output (--log-level debug) and the script.
3. Open an issue in the k6 GitHub repository or ask in the k6 community forum, attaching the reproducer and logs.

Example: minimal verification script

Use this script to confirm that thresholds work in your environment:

import http from 'k6/http';
import { sleep } from 'k6';

export const options = {
  thresholds: {
    'http_req_duration': ['avg<200']   // expect average under 200ms
  },
  vus: 5,
  duration: '30s'
};

export default function () {
  const res = http.get('https://httpbin.org/delay/1');
  sleep(1);
};

Run it:

k6 run verify_thresholds.js

Check the output for a section similar to:

     █ thresholds
     █ http_req_duration: avg<200 ................. FAIL

If you see PASS while the printed average is above 200 ms, the threshold is not evaluating correctly; revisit the checks above.

Limitations and practical verification

• Thresholds for counter‑type metrics (e.g., http_reqs) are evaluated only at test end; intermediate spikes will not trigger a fail.
• Changing a threshold after a test run does not affect past results; you must re‑execute the test to see the impact.
• Overly strict thresholds on noisy metrics can cause false failures; consider adding a tolerance or using a longer aggregation window (e.g., p(95 over 10s)<500).

To verify that a fix worked, re‑run the test and confirm that the thresholds section now shows the expected PASS or FAIL matching the metric value printed in the summary.
