Defining and Validating HTTP Response Time SLAs with k6 Thresholds

Desired outcome

Verify that, during a load test, the 95th percentile of HTTP request latency stays below a defined SLA (for example, 500 ms) and that the overall error rate remains under 1 %. If either condition is violated, the test should exit with a non‑zero status so that CI pipelines can fail fast.

Prerequisites

• k6 version ≥ 0.45.0 installed (older versions lack the http_req_failed metric and the --thresholds-abort flag).
• A test script that issues HTTP requests (e.g., a simple GET to an endpoint).
• Access to a terminal or CI environment where you can run k6.
• Optional: a time‑series backend such as InfluxDB/Grafana if you want to store detailed metrics for later analysis.

Procedure

1. Create or edit your k6 script – add a thresholds block that defines the two rules:

import http from 'k6/http';
import { check, sleep } from 'k6';

export const options = {
  thresholds: {
    // 95th percentile of request duration must be < 500 ms
    'http_req_duration{type:http}': ['p(95)<500'],
    // overall failed request rate must be < 1%
    'http_req_failed': ['rate<0.01'],
  },
};

export default function () {
  const res = http.get('https://test-api.k6.io/public/crocodiles/1/');
  check(res, {
    'status is 200': (r) => r.status === 200,
  });
  sleep(1);
}

1. Run the test locally or in CI:

# Run from the directory containing script.js
k6 run script.js

1. Observe the threshold evaluation – k6 prints a thresholds section at the end of the run:

     █ http_req_duration{type:http}......: avg=120ms min=45ms med=90ms p(95)=480ms p(99)=620ms
     █ http_req_failed................: 0.00%  ✓ 0 out of 5000
     █ thresholds....................: OK

If any rule fails, the corresponding line will show FAIL and the overall thresholds block will be marked FAIL.

Expected checks

• Textual output: look for the thresholds block; each rule should display OK or FAIL.
• Process exit code: after the run, execute echo $?. A value of 0 indicates all thresholds passed; any non‑zero value indicates at least one failure.
• Optional JSON summary: run k6 run --summary-export=summary.json script.js and inspect summary.json for "thresholds":[{"ok":true},{"ok":false},...].

Recovery options

When a threshold fails:

1. Inspect detailed metrics – export raw samples for post‑mortem:

k6 run --out json=results.json script.js
# results.json contains every sample; you can filter for high latency or errors.

1. Adjust load pattern – reduce the number of virtual users (VUs) or duration to see if the system can meet the SLA under lighter load.

1. Increase system capacity – scale the backend, add caching, or tune timeouts.

1. Re‑evaluate the SLA – if the system cannot meet the target after optimisation, consider whether the latency bound is realistic given the architecture.

Limitations and practical verification

• Thresholds are evaluated only after the test finishes unless you use the --thresholds-abort flag (available in k6 ≥ 0.45.0). Early failures will not stop the test automatically.
• Omitting the {type:http} selector on http_req_duration causes the rule to match no samples, leading to a silent pass. Always include the selector when you want to measure HTTP request latency.
• To verify that the threshold logic works as intended, you can deliberately violate a rule (e.g., change the URL to a non‑existent endpoint to generate errors) and confirm that the exit code becomes non‑zero and the thresholds block shows FAIL.
