Diagnosing k3OS Boot Stalls Due to Missing or Malformed cloud‑init User‑Data

Recognizable condition

The k3OS node stops before the k3s service starts. You see either an initramfs prompt or a repeating message such as "Waiting for cloud‑init data source" on the console or serial output. The system never proceeds to load the k3s container runtime.

Cause / diagnostic table

Possible cause	What to look for
Missing cloud‑init configuration file	/var/lib/rancher/k3os/cloud‑init.yml does not exist
Malformed YAML in cloud‑init	File exists but contains syntax errors (e.g., incorrect indentation, invalid anchors)
Network not ready when cloud‑init runs	DHCP lease not obtained; cloud‑init logs show timeout waiting for network

Ordered checks

1. Examine boot logs

   On the node console or serial connection, look for cloud‑init messages. Typical lines start with "cloud-init" and include "Cloud‑init v." followed by either "finished" or an error.

   # Run on the node (requires root or console access)
   journalctl -u cloud-init | grep -i cloud-init

2. Check for the cloud‑init file

   Verify whether the expected user‑data file is present.

   # On the node (root)
   ls -l /var/lib/rancher/k3os/cloud-init.yml

   If the file is missing, note the absence; if present, proceed to validate its content.

3. Validate YAML syntax

   Use a YAML parser to ensure the file is well‑formed.

   # On the node (root) – python3 is usually available
   python3 -m yaml.tool /var/lib/rancher/k3os/cloud-init.yml 2>&1
   # Alternatively, if yamllint is installed:
   yamllint /var/lib/rancher/k3os/cloud-init.yml

   Any output indicating an error points to a syntax problem.

4. Test network connectivity

   Confirm that the node can obtain an IP address via DHCP before cloud‑init runs.

   # On the node (root)
   dhclient -v eth0   # replace eth0 with the appropriate interface if needed
   # Or, if a static address is expected, verify it is configured:
   ip addr show eth0

   Look for a successful "bound to" message or a configured address.

Fixes tied to findings

• Missing cloud‑init file
  • If you have a backup of the intended user‑data, copy it back:

  # On the node (root)
  cp /path/to/backup/cloud-init.yml /var/lib/rancher/k3os/cloud-init.yml
  chmod 644 /var/lib/rancher/k3os/cloud-init.yml


  • Otherwise, re‑apply the user‑data via the k3os config URL (usually set in /etc/k3os/config.yaml) and reboot:

  # Edit the config to point to the correct source (requires reboot)
  vi /etc/k3os/config.yaml
  # Ensure the 'cloud_init_url' field is correct
  reboot


• Invalid YAML
  • Correct the syntax errors reported by the validator, then save the file.

  # Example fix: correct indentation
  vi /var/lib/rancher/k3os/cloud-init.yml
  # After editing, validate again:
  python3 -m yaml.tool /var/lib/rancher/k3os/cloud-init.yml


• Network not ready
  • Ensure a DHCP server is reachable on the network segment.
  • If DHCP cannot be used, configure a static network in /etc/k3os/config.yaml under the network section.

  # Example static config (edit then reboot)
  vi /etc/k3os/config.yaml
  network:
    interfaces:
      eth0:
        address: 192.168.1.42/24
        gateway: 192.168.1.1
        dns:
          - 8.8.8.8
  reboot


Escalation criteria

1. After applying the appropriate fix, reboot the node.
2. If the node still does not reach the k3s service after two consecutive reboots, collect the following logs for further analysis:

# On the node (root)
cp /var/log/cloud-init.log /tmp/cloud-init.log
cp /var/log/messages /tmp/messages.log
# Transfer the logs off the node (e.g., via scp) for inspection

Open a support ticket with the k3OS project, attaching the logs and a description of the steps already taken.
