Diagnosing Envoy Outlier Detection Ejections: A Step‑by‑Step Guide

Recognizable Condition

You notice increased latency or error rates for a service, and Envoy logs show messages like "[outlier detection] host ejected" or the admin endpoint reports rising ejection_* counters for a cluster. Traffic to one or more upstream hosts drops suddenly while other hosts appear healthy.

Cause/Diagnostic Table

Symptom	Likely Cause	Key Indicator
Sudden drop in requests to a specific host	Host marked as outlier and ejected	Increase in cluster..outlier_detection.ejection_eject counter
Elevated latency across the pool	Success‑rate or latency threshold too low, causing premature ejection	High success_rate or success_rate_requests_total with low success ratio
No ejection events but errors persist	Outlier detection disabled or mis‑configured	Zero ejection_* counters; outlier_detection block missing or disabled

Ordered Checks

1. Verify admin access

   Ensure you can reach Envoy’s admin interface (default port 9901) from your workstation or a bastion host. You need read‑only permission on the /stats endpoint.

   curl -s http://localhost:9901/stats | grep outlier_detection

   Look for counters such as cluster.my_service.outlier_detection.ejection_eject and cluster.my_service.outlier_detection.success_rate.

2. Check recent ejection events

   If the counter is non‑zero, note the timestamp (Envoy exports a histogram ejection_time that can be queried via stats with the :value suffix).

   curl -s http://localhost:9901/stats | grep ejection_eject

3. Inspect the cluster’s outlier detection configuration

   Retrieve the current configuration via xDS or the static file. For a static config, examine the outlier_detection block:

   cluster:
     name: my_service
     outlier_detection:
       interval: 10s
       base_ejection_time: 30s
       max_ejection_percent: 10
       success_rate_minimum_hosts: 5
       success_rate_request_volume: 100
       success_rate_stdev_factor: 1900  # ~19.0% success rate threshold
       consecutive_gateway_failure: 5
       consecutive_5xx: 5


   If using xDS, run:

   curl -s http://localhost:9901/config_dump | jq '.configs[].dynamic_clusters[] | select(.name=="my_service") | .outlier_detection'

4. Correlate with application metrics

   From the upstream service, verify error rates and latency during the same window. If the upstream is healthy but Envoy still ejects, the thresholds are likely too aggressive.

5. Test with controlled failure

   In a staging environment, use a tool like hey or wrk to generate a known number of 5xx responses or added latency to a single host, then watch the ejection counter increase.

   hey -z 30s -m GET -h "Host: upstream-host" http://envoy-admin:9901/...

   Observe whether ejection occurs after the configured consecutive_gateway_failure or success_rate threshold.

Fixes Tied to Findings

• Host truly unhealthy

  If the upstream is returning errors or latency spikes, fix the root cause (application bug, resource exhaustion). Once the host passes health checks, Envoy will automatically stop ejecting it after the base_ejection_time elapses.

• Thresholds too low

  Increase success_rate_stdev_factor (or the equivalent success_rate value) to require a larger deviation before ejection. For TCP, raise consecutive_connection_failure or increase base_ejection_time to reduce churn.

  Example adjustment:

  outlier_detection:
    success_rate_stdev_factor: 2100  # ~21% success rate threshold
    base_ejection_time: 60s


• Feature disabled

  Ensure the outlier_detection block is present and not set to {} (which disables the feature). Add or restore the block with sensible defaults.

Escalation Criteria

1. Ejection counters continue to rise after threshold adjustments and host health is confirmed.
2. Multiple clusters exhibit simultaneous ejection storms, suggesting a mis‑configured global runtime or xDS delivery issue.
3. Admin endpoint shows outlier_detection counters stuck at zero while upstream logs indicate failures—possible configuration not being loaded (check config_dump for stale version).
4. In these cases, collect Envoy logs (--log-level debug) and the full configuration dump, then engage the platform team to verify xDS version consistency and restart Envoy if needed.
