Choosing an Envoy Load Balancing Policy: Decision Guide for Service-to-Service Traffic

The Decision: Pick One Policy Per Cluster

Envoy selects a load balancing policy per upstream cluster via the lb_policy field. The choice determines how requests are distributed across healthy endpoints, whether session affinity is provided, and how the cluster reacts to endpoint changes. Constraints include:

• Need for request affinity (stateful gRPC streams, WebSocket)
• Heterogeneous endpoint capacity or request latency
• Cluster size (tens to thousands of endpoints)
• Frequency of endpoint membership changes (e.g., Kubernetes pod churn)
• Zone-aware routing requirements

All policies respect health checks, outlier detection, and zone-aware routing. Zone affinity can be enabled per cluster to prefer local-zone endpoints before crossing AZ boundaries.

Quick Comparison

Algorithm	Best For	Session Affinity	Load Adaptation	Scale Suitability	Config Complexity
Round Robin (default)	Simple, homogeneous workloads	No	None (ignores load variance)	Any	Low
Least Request	General-purpose RPC/HTTP, heterogeneous workloads	No	Picks two random endpoints, sends to the one with fewer active requests (P2C)	Any	Low (set choice_count: 2)
Ring Hash	Stateful protocols requiring affinity	Yes (consistent hashing)	No	Up to ~1000 endpoints	Medium (requires hash_policy)
Maglev	Large clusters (>1000 endpoints) needing affinity	Yes (consistent hashing, faster lookup)	No	Thousands of endpoints	Medium (requires hash_policy, CPU-intensive table generation)
Random	Avoiding synchronization spikes at startup	No	Statistically equivalent to Round Robin over time	Any	Low

Trade-offs and Cautions

Least Request (Recommended Default)

Least Request with choice_count: 2 adapts to heterogeneous workloads and reduces tail latency without per-endpoint state. In Envoy 1.26+, active_request_bias can weight by latency for highly skewed request costs. It works well for most service-to-service RPC and HTTP traffic.

Ring Hash vs. Maglev for Affinity

Both provide session affinity via consistent hashing. Ring Hash uses a configurable ring size (default 1024 virtual nodes per host). Maglev uses a permutation table for O(1) lookup and better distribution at scale. Choose Maglev for clusters exceeding ~1000 endpoints. Both require a hash_policy (header, cookie, or connection properties) to define the affinity key. Hash policies using headers or cookies expose affinity to client manipulation; prefer connection properties (source IP, TLS peer cert) for untrusted clients.

Endpoint Churn and Reshuffling

Ring Hash and Maglev reshuffle on endpoint membership changes. Control virtual node count with min_ring_size and max_ring_size to limit disruption. Maglev table generation is CPU-intensive on cluster updates; avoid frequent endpoint churn (e.g., per-pod IPs in large Kubernetes clusters) or increase table_size incrementally.

Zone-Aware Routing

Zone affinity prefers local-zone endpoints. Perfect balance requires identical endpoint counts per zone; otherwise cross-zone traffic may exceed cross_zone_fallback_ratio.

Deprecated Policy

Envoy 1.28 deprecated lb_policy: CLUSTER_PROVIDED in favor of explicit policy names. Update configs before upgrading.

Concrete Implementation Examples

Least Request Cluster (General Purpose)

clusters:
- name: backend_service
  type: EDS
  lb_policy: LEAST_REQUEST
  least_request_lb_config:
    choice_count: 2
    active_request_bias: 1.0  # optional, Envoy 1.26+
  health_checks:
  - timeout: 5s
    interval: 10s
    unhealthy_threshold: 3
    healthy_threshold: 2
    http_health_check:
      path: /healthz
  outlier_detection:
    consecutive_5xx: 5
    interval: 30s
    base_ejection_time: 30s
  # Zone-aware routing (optional)
  locality_lb_policies:
  - zone: us-east-1a
    lb_policy: LEAST_REQUEST
  - zone: us-east-1b
    lb_policy: LEAST_REQUEST

Ring Hash Cluster (Affinity Required)

clusters:
- name: stateful_service
  type: EDS
  lb_policy: RING_HASH
  ring_hash_lb_config:
    min_ring_size: 1024
    max_ring_size: 8192
  hash_policy:
  - header:
      header_name: x-session-id
    # For untrusted clients, use connection properties instead:
    # connection_properties:
    #   source_ip: true
  health_checks:
  - timeout: 5s
    interval: 10s
    unhealthy_threshold: 3
    healthy_threshold: 2
    http_health_check:
      path: /healthz

Replace x-session-id with the header or cookie that carries your session identifier. For Maglev, change lb_policy: MAGLEV and add maglev_lb_config: with table_size (default 65537, must be prime).

Validation Steps

1. Confirm Active Policy via Admin Interface

Run on the Envoy host (requires access to admin port, typically 9901):

curl -s http://localhost:9901/clusters?format=json | jq '.[] | select(.name=="backend_service") | {name, lb_policy, load_balancing_policy}'

Expected output shows lb_policy" : "LEAST_REQUEST" (or the policy you set). Risk: exposing admin port publicly; restrict to localhost or trusted network.

2. Synthetic Load Test

From a test client with hey or wrk installed:

hey -n 10000 -c 50 http:///service/endpoint

Then check request distribution:

curl -s http://localhost:9901/stats?filter=cluster.backend_service.upstream_rq* | grep upstream_rq

Least Request should show roughly even counts across endpoints; Round Robin will show sequential pattern. Risk: load test may affect production traffic; run against a staging cluster.

3. Trace Affinity Adherence (Ring Hash/Maglev)

Enable access logging with upstream host and request ID:

access_log:
- name: envoy.access_loggers.file
  typed_config:
    "@type": type.googleapis.com/envoy.extensions.access_loggers.file.v3.FileAccessLog
    path: /var/log/envoy/access.log
    log_format:
      text_format: "%START_TIME% %REQ(:METHOD)% %REQ(X-REQUEST-ID)% %UPSTREAM_HOST% %RESPONSE_CODE%\n"

Inspect logs to verify that requests with the same hash key consistently route to the same upstream host.

Limitations and Practical Checks

• Zone imbalance: If zones have unequal endpoint counts, cross-zone traffic may exceed the fallback ratio. Monitor cluster..upstream_cx_cross_zone stats.
• Maglev CPU spikes: On large clusters with frequent endpoint updates, watch CPU usage during cluster reloads. Consider increasing table_size gradually.
• Hash policy security: Header/cookie based affinity can be spoofed. Use connection_properties with source_ip or tls_peer_cert for untrusted clients.
• Deprecated config: Validate config with envoy -c config.yaml --mode validate before deployment to catch CLUSTER_PROVIDED usage.

Practical verification: after deployment, monitor /stats for upstream_rq_pending_active, upstream_rq_per_try_timeout, and upstream_cx_destroy_remote_active_rq to ensure the policy behaves as expected under real traffic.
