Container Lifecycle Hooks

This page describes how kubelet managed Containers can use the Container lifecycle hook framework to run code triggered by events during their management lifecycle. Overview Analogous to many programming language frameworks that have component lifecycle hooks, such as Angular, Kubernetes provides Co

This page describes how kubelet managed Containers can use the Container lifecycle hook framework to run code triggered by events during their management lifecycle.

Overview

Analogous to many programming language frameworks that have component lifecycle hooks, such as Angular, Kubernetes provides Containers with lifecycle hooks. The hooks enable Containers to be aware of events in their management lifecycle and run code implemented in a handler when the corresponding lifecycle hook is executed.

Container hooks

There are two hooks that are exposed to Containers:

PostStart

This hook is executed immediately after a container is created. It runs concurrently with the container's ENTRYPOINT (main process), meaning the hook may run before, during, or after the main process starts.

No parameters are passed to the handler.

Note:

While the hook runs concurrently with the container process, it can delay container status updates; the container may not transition to Running until the hook completes.

PreStop

This hook is called immediately before a container is terminated due to an API request or management event such as a liveness/startup probe failure, preemption, resource contention and others. A call to the PreStop hook fails if the container is already in a terminated or completed state and the hook must complete before the TERM signal to stop the container can be sent. The Pod's termination grace period countdown begins before the PreStop hook is executed, so regardless of the outcome of the handler, the container will eventually terminate within the Pod's termination grace period. No parameters are passed to the handler.

A more detailed description of the termination behavior can be found in Termination of Pods.

StopSignal

The StopSignal lifecycle can be used to define a stop signal which would be sent to the container when it is stopped. If you set this, it overrides any STOPSIGNAL instruction defined within the container image.

A more detailed description of termination behaviour with custom stop signals can be found in Stop Signals.

Hook handler implementations

Containers can access a hook by implementing and registering a handler for that hook. There are three types of hook handlers that can be implemented for Containers:

Exec - Executes a specific command, such as pre-stop.sh, inside the cgroups and namespaces of the Container. Resources consumed by the command are counted against the Container.
HTTP - Executes an HTTP request against a specific endpoint on the Container.
Sleep - Pauses the container for a specified duration.

Hook handler execution

When a Container lifecycle management hook is called, the Kubernetes management system executes the handler according to the hook action, httpGet, tcpSocket (deprecated) and sleep are executed by the kubelet process, and exec is executed in the container.

The PostStart hook handler call is initiated when a container is created, meaning the container ENTRYPOINT and the PostStart hook are triggered simultaneously. (This means it generally doesn't make sense to use an HTTP hook for PostStart, since there is no guarantee that the container's process will have fully started up when the hook runs.) If the PostStart hook takes too long to execute or if it hangs, it can prevent the container from transitioning to a running state.

PreStop hooks are not executed asynchronously from the signal to stop the Container; the hook must complete its execution before the TERM signal can be sent. If a PreStop hook hangs during execution, the Pod's phase will be Terminating and remain there until the Pod is killed after its terminationGracePeriodSeconds expires. This grace period applies to the total time it takes for both the PreStop hook to execute and for the Container to stop normally. If, for example, terminationGracePeriodSeconds is 60, and the hook takes 55 seconds to complete, and the Container takes 10 seconds to stop normally after receiving the signal, then the Container will be killed before it can stop normally, since terminationGracePeriodSeconds is less than the total time (55+10) it takes for these two things to happen.

If either a PostStart or PreStop hook fails, it kills the Container.

Users should make their hook handlers as lightweight as possible. There are cases, however, when long running commands make sense, such as when saving state prior to stopping a Container.

Hook delivery guarantees

Hook delivery is intended to be at least once, which means that a hook may be called multiple times for any given event, such as for PostStart or PreStop. It is up to the hook implementation to handle this correctly.

Generally, only single deliveries are made. If, for example, an HTTP hook receiver is down and is unable to take traffic, there is no attempt to resend. In some rare cases, however, double delivery may occur. For instance, if a kubelet restarts in the middle of sending a hook, the hook might be resent after the kubelet comes back up.

Debugging Hook handlers

The logs for a Hook handler are not exposed in Pod events. If a handler fails for some reason, it broadcasts an event. For PostStart, this is the FailedPostStartHook event, and for PreStop, this is the FailedPreStopHook event. To generate a failed FailedPostStartHook event yourself, modify the lifecycle-events.yaml file to change the postStart command to "badcommand" and apply it. Here is some example output of the resulting events you see from running kubectl describe pod lifecycle-demo:

Events:
  Type     Reason               Age              From               Message
  ----     ------               ----             ----               -------
  Normal   Scheduled            7s               default-scheduler  Successfully assigned default/lifecycle-demo to ip-XXX-XXX-XX-XX.us-east-2...
  Normal   Pulled               6s               kubelet            Successfully pulled image "nginx" in 229.604315ms
  Normal   Pulling              4s (x2 over 6s)  kubelet            Pulling image "nginx"
  Normal   Created              4s (x2 over 5s)  kubelet            Created container lifecycle-demo-container
  Normal   Started              4s (x2 over 5s)  kubelet            Started container lifecycle-demo-container
  Warning  FailedPostStartHook  4s (x2 over 5s)  kubelet            Exec lifecycle hook ([badcommand]) for Container "lifecycle-demo-container" in Pod "lifecycle-demo_default(30229739-9651-4e5a-9a32-a8f1688862db)" failed - error: command 'badcommand' exited with 126: , message: "OCI runtime exec failed: exec failed: container_linux.go:380: starting container process caused: exec: \"badcommand\": executable file not found in $PATH: unknown\r\n"
  Normal   Killing              4s (x2 over 5s)  kubelet            FailedPostStartHook
  Normal   Pulled               4s               kubelet            Successfully pulled image "nginx" in 215.66395ms
  Warning  BackOff              2s (x2 over 3s)  kubelet            Back-off restarting failed container
