Choosing Between st.cache_data and st.cache_resource in Streamlit

The Decision: Store a Copy or Share a Reference?

Every Streamlit interaction reruns the whole script from top to bottom. Without caching, a large CSV load or a model initialization runs again on every button click and slider drag, and latency collapses. Streamlit ships two supported caching decorators, and picking the wrong one produces either pickling errors or cross-session state bugs.

The rule of thumb: use st.cache_data for functions that return serializable data — DataFrames, lists, dicts, scalars — and st.cache_resource for objects that should exist once per process, such as database connections, ML models, and thread pools. Both have been the stable caching API since Streamlit 1.18.

Side-by-Side Comparison

Aspect	st.cache_data	st.cache_resource
Intended for	Serializable results: DataFrames, lists, dicts, scalars	Objects that should exist once: connections, models, thread pools
Storage	Serialized (pickle-like) copy	Single shared reference
What a rerun receives	A fresh copy of the result	The same object instance
Session isolation	Safe by default; mutations stay local to one session	Shared; mutations affect every session
Overhead	Serialization and copying, grows with object size	None beyond first creation
Typical failure if misused	Pickling errors on connections or file handles	Accidental shared mutable state

Both decorators accept the same control knobs: ttl (seconds before eviction), max_entries (bounded cache size), show_spinner, and a per-function .clear() for manual resets.

Trade-offs in Practice

Copy-on-read is safe but costs memory

st.cache_data pickles the return value and hands each rerun a copy. Two users filtering the same DataFrame cannot corrupt each other's results. The price is memory: ten concurrent sessions each holding a copy of a large DataFrame can spike the server process's memory usage. For very large objects, cache a smaller derived result instead of the raw payload.

Shared references are fast but need guarding

st.cache_resource stores the object once and returns the same reference to every rerun and session. There is no serialization cost, which is exactly why connections and models belong here. The catch: concurrent sessions may call the object simultaneously, so it must be thread-safe. If sessions mutate the resource, add a lock or return copies from the cached function.

Unhashable arguments and the underscore prefix

Cache keys are derived from the function's code and its arguments. Passing an unhashable object — an open connection, for example — into a cached function raises an error. Prefix the parameter name with an underscore, as in _conn, to exclude it from the key while still receiving the value inside the function.

A Concrete Pattern: One Connection, Cached Queries

This pattern combines both decorators: the connection is cached as a resource, and query results are cached as data with a ten-minute TTL so stale rows eventually refresh.

import streamlit as st
import pandas as pd
import time

# Shared once per process; no reconnect on reruns.
@st.cache_resource
def get_connection():
    time.sleep(2)  # simulate expensive setup
    return "DB_CONNECTION_OBJECT"

# _conn is excluded from the cache key; the query drives invalidation.
@st.cache_data(ttl=600)
def run_query(_conn, sql):
    time.sleep(1)  # simulate data retrieval
    return pd.DataFrame({"result": [f"rows for {sql}"]})

conn = get_connection()
sql = st.text_input("Query", "SELECT * FROM sales")

if st.button("Run"):
    st.write(run_query(conn, sql))

Expected behavior: the first click takes roughly three seconds (connection setup plus query). Later clicks with the same query text are instant. Editing the text triggers only the one-second query path, because the connection is reused and the new query string forms a new cache key.

How to Validate the Behavior

• Print a timestamp inside each cached function. Rerun via a widget: the timestamp should stay frozen for identical inputs and change when inputs change.
• Set ttl=5 on run_query, wait six seconds, rerun, and confirm the function body executes again.
• With st.cache_resource, mutate the returned object in one rerun and observe the change persisting into the next — proof of shared-reference semantics.
• Call run_query.clear() during development to force a cold run on demand.

Limitations and Version Notes

• st.cache_data cannot serialize connections, sockets, or file handles; caching those raises a pickling error. Use st.cache_resource instead.
• Mutating a cache_resource object affects all sessions; guard with locks or return copies.
• Neither decorator detects upstream database changes. ttl is the practical refresh mechanism, not a change-detection system.
• Large cached objects increase memory pressure on the Streamlit server process; bound growth with max_entries or ttl.
• The legacy st.cache API and the st.experimental_memo / st.experimental_singleton names are deprecated. Confirm decorator signatures against the documentation for your installed Streamlit version before relying on parameter details.
