Streamlit Caching in Production: Choosing Between cache_data and cache_resource

The Problem: Cache Confusion in Production

You deploy a Streamlit app that loads a 500 MB model and queries a PostgreSQL database. After the first user session, memory usage climbs. A second user hits the same endpoint and gets a stale DataFrame. The logs show CachedWidgetWarning spam. You added @st.cache everywhere because the docs said it speeds things up — but now the app behaves unpredictably.

Since Streamlit 1.18, the legacy @st.cache decorator has been split into two distinct primitives: st.cache_data for serializable return values and st.cache_resource for unserializable objects like database connections, ML models, and HTTP clients. Understanding this distinction isn't optional for production apps — it's the difference between a stable deployment and a memory leak that crashes your container.

When to Use Each Decorator

The rule of thumb: if the return value can be pickled and you want a fresh copy on each cache hit, use st.cache_data. If the return value holds open file descriptors, GPU memory, or network sockets — things that cannot be meaningfully copied — use st.cache_resource.

st.cache_data: Serializable Data

• Pandas DataFrames, NumPy arrays, dicts, lists, primitives
• Stores a pickled copy per argument signature
• Returns a deep copy by default (since 1.32, copy=False opts out)
• Ideal for query results, computed features, downloaded CSVs

st.cache_resource: Singleton Objects

• SQLAlchemy engines, Redis clients, transformers pipelines, requests.Session
• Stores the actual object instance in a global map keyed by function identity
• Same object returned across all sessions and reruns within the process
• Not garbage-collected when a user session ends

# cache_data: returns a fresh DataFrame copy each hit
@st.cache_data(ttl=300, max_entries=10)
def load_sales_data(region: str) -> pd.DataFrame:
    return pd.read_sql(f"SELECT * FROM sales WHERE region='{region}'", engine)

# cache_resource: returns the SAME engine instance every time
@st.cache_resource
def get_engine() -> sqlalchemy.Engine:
    return sqlalchemy.create_engine(
        "postgresql://user:pass@db:5432/app",
        pool_size=5, max_overflow=10
    )

engine = get_engine()  # singleton
sales_df = load_sales_data("EMEA")  # cached per region, TTL 5 min

Invalidation Strategies That Actually Work

Both decorators accept ttl (seconds or timedelta) and max_entries (LRU eviction). These operate independently: ttl expires entries by age, max_entries bounds memory by discarding least-recently-used entries.

Time-Based Expiration

Use ttl when data has a known freshness window — dashboard metrics, exchange rates, feature flags. The cache key includes the function's qualified name, source file hash, and argument values (via inspect.signature + pickle). Changing default argument values or the function body invalidates existing entries automatically.

Manual Invalidation

Call func.clear() to purge all entries for that function across all sessions. There is no per-session or per-user granularity without namespacing arguments yourself (e.g., include user_id in the cache key).

@st.cache_data(ttl=600, max_entries=50)
def fetch_user_features(user_id: int) -> dict:
    return api_client.get(f"/users/{user_id}/features").json()

# Invalidate for one user after a write
if st.button("Refresh features"):
    fetch_user_features.clear()  # clears ALL users — consider namespacing
    st.rerun()

Common Pitfalls and How to Avoid Them

Widget Calls Inside Cached Functions

Any st.* widget call inside a cached function raises CachedWidgetWarning and is ignored. Move widget calls outside and pass values as plain arguments:

# WRONG — widget inside cached function
@st.cache_data
def bad_example():
    threshold = st.slider("Threshold", 0, 100, 50)  # warning, ignored
    return query_db(threshold)

# RIGHT — widget outside, value passed in
@st.cache_data
def good_example(threshold: int):
    return query_db(threshold)

threshold = st.slider("Threshold", 0, 100, 50)
result = good_example(threshold)

Mutable Returns with copy=True (Default)

With st.cache_data, the default copy=True deep-copies the return value on every hit. Mutating the returned DataFrame in-place wastes CPU and memory without affecting the cache. For large DataFrames, use copy=False — but treat the returned object as read-only:

@st.cache_data(copy=False)
def large_dataframe() -> pd.DataFrame:
    return pd.read_parquet("s3://bucket/large.parquet")

# SAFE: read-only operations
df = large_dataframe()
st.dataframe(df.head())

# DANGEROUS: mutation persists in cache, affects other sessions
df["new_col"] = 1  # mutates the cached object!

Distributed Deployments: No Shared Cache

The in-process cache is not shared across replicas. Two containers behind a load balancer maintain independent caches. For cross-instance coherence, attach a persistent backend (Redis, Memcached, or a database) via a custom wrapper or packages like streamlit-cache-redis. This is not built into Streamlit core.

Worked Example: A Production-Ready Pattern

Here's a pattern used in a real-time analytics dashboard serving 200+ concurrent users. The app loads a 200 MB embedding model and queries a read-replica PostgreSQL cluster.

import streamlit as st
import sqlalchemy
from sentence_transformers import SentenceTransformer
import pandas as pd

# 1. Singleton resources — initialized once per process
@st.cache_resource
def get_db_engine() -> sqlalchemy.Engine:
    return sqlalchemy.create_engine(
        st.secrets["postgres_dsn"],
        pool_size=10, max_overflow=20,
        pool_pre_ping=True  # handles stale connections
    )

@st.cache_resource
def get_embedder() -> SentenceTransformer:
    # Loads ~200 MB model weights into GPU/CPU memory once
    return SentenceTransformer("sentence-transformers/all-MiniLM-L6-v2")

# 2. Cached data — TTL for freshness, LRU for memory bound
@st.cache_data(ttl=300, max_entries=200, copy=False)
def search_similar(query_embedding: list[float], top_k: int = 10) -> pd.DataFrame:
    engine = get_db_engine()
    # pgvector similarity search
    sql = """
        SELECT id, text, 1 - (embedding <=> %s) AS similarity
        FROM documents
        ORDER BY embedding <=> %s
        LIMIT %s
    """
    return pd.read_sql(sql, engine, params=(query_embedding, query_embedding, top_k))

# 3. UI layer — widgets outside cached functions
st.title("Semantic Search")
query = st.text_input("Search query")
top_k = st.slider("Results", 5, 50, 10)

if query:
    embedder = get_embedder()
    embedding = embedder.encode(query).tolist()
    results = search_similar(embedding, top_k)
    st.dataframe(results)

# 4. Admin: manual cache clear for deployments
with st.sidebar:
    if st.button("Clear all caches (admin)"):
        st.cache_data.clear()
        st.cache_resource.clear()
        st.success("Caches cleared")
        st.rerun()

Key decisions in this pattern:

• copy=False on search_similar avoids copying the result DataFrame (read-only downstream)
• pool_pre_ping=True prevents stale connection errors after database failover
• Embedding model loaded once per process via cache_resource, not per session
• Cache keys include query_embedding (list of floats) — hashable, stable
• Admin clear button calls both clear() methods for full reset after model updates

Trade-offs and Limitations

Concern	cache_data	cache_resource
Cross-replica sharing	No (in-process only)	No (in-process only)
Per-session granularity	Only via argument namespacing	Not supported
Memory growth	Bounded by max_entries	Unbounded — persists for process lifetime
Mutation risk	High if copy=False	High — same object everywhere
Serialization cost	Pickle on miss/hit (unless copy=False)	None — object stored directly

The biggest operational gap: no built-in distributed cache. If you run multiple replicas (Kubernetes, Cloud Run, Heroku), each replica warms its own cache independently. For read-heavy workloads, this means redundant computation. The workaround is a wrapper around Redis or a shared database table, but that adds infrastructure complexity.

Actionable Checklist for Your Next Deploy

1. Audit existing @st.cache decorators. Split each into cache_data or cache_resource based on return type. Remove allow_output_mutation and suppress_st_warning — they don't exist in the new API.
2. Add ttl and max_entries to every cache_data function. Start with ttl=300 (5 min) and max_entries=100; tune based on memory profiling.
3. Set copy=False on large DataFrame functions only after confirming downstream code treats them as read-only. Add a comment: # READ ONLY — cached object shared.
4. Move all st.* widget calls outside cached functions. Pass widget values as arguments. This eliminates CachedWidgetWarning and makes cache keys explicit.
5. Test invalidation. Run the app, trigger a cache hit, call func.clear() from a button, verify fresh data loads. Confirm streamlit cache clear CLI (added in 1.28) purges on-disk artifacts.
6. Plan for distributed deployment. If you'll run >1 replica, evaluate streamlit-cache-redis or a custom Redis wrapper before you need it.

Run the verification steps from the Streamlit docs: create a minimal app with @st.cache_data(ttl=10) returning a timestamp DataFrame, confirm updates only after TTL expiry. Wrap sqlalchemy.create_engine in @st.cache_resource and verify id(engine) is stable across reruns. These five-minute tests catch 90% of caching bugs before they reach production.
