Choosing a Compression Algorithm in RocksDB: A Decision Guide

Problem and Takeaway

RocksDB stores data in immutable SST files that are compressed block‑by‑block. The compression algorithm you pick determines three things at once: on‑disk size, CPU spent (de)compressing, and read latency caused by decompression. Because the setting lives at the column‑family level, you can tune it per data type, but you cannot change it for existing data without a full rewrite. The practical takeaway: start with Snappy for latency‑sensitive workloads, move to Zstd when storage is the bottleneck, and validate with a realistic micro‑benchmark before committing.

Supported Compression Types (RocksDB ≥ 6.20)

Algorithm	Typical Ratio	Compress Speed	Decompress Speed	Best Fit
kNoCompression	1.0×	N/A	N/A	Already‑compressed payloads (e.g., images, protobuf with snappy)
kSnappyCompression	1.5–2.5×	Very fast	Very fast	Low‑latency reads/writes, SSD, CPU‑constrained
kLZ4Compression	1.6–2.8×	Fast	Fast	Balanced speed/size, good default for mixed workloads
kLZ4HCCompression	2.0–3.5×	Slower (high‑compression mode)	Fast	Write‑once, read‑many data where extra CPU on write is acceptable
kZSTDCompression	2.5–4.5×	Moderate	Moderate	Storage‑constrained environments, HDD, archival data
kBZip2Compression	3.0–5.0×	Slow	Slow	Rarely used; only when maximum size reduction outweighs CPU cost

Decision Constraints

• Hardware: SSD vs. HDD changes the I/O‑vs‑CPU trade‑off. On SSD, decompression latency is more visible.
• Workload pattern: Write‑heavy (logs, time‑series) favors faster compressors; read‑heavy (lookup tables) can tolerate slower decompression if it saves I/O.
• CPU budget: If the server runs other latency‑sensitive services, keep compression CPU low.
• Data compressibility: Already‑compressed blobs gain nothing from further compression; use kNoCompression for those column families.

Concrete Configuration Example

Assume a database with two column families: metadata (small JSON blobs, high read rate) and events (large append‑only logs). The following C++ snippet shows per‑family tuning:

#include "rocksdb/options.h"
#include "rocksdb/db.h"

using namespace rocksdb;

Options db_opts;
db_opts.create_if_missing = true;

ColumnFamilyOptions meta_opts;
meta_opts.compression = kSnappyCompression;          // low latency reads
meta_opts.compression_per_level.resize(7);
meta_opts.compression_per_level[0] = kNoCompression; // level‑0 often hot, keep raw

ColumnFamilyOptions events_opts;
events_opts.compression = kZSTDCompression;          // maximize space savings
events_opts.compression_per_level.resize(7);
events_opts.compression_per_level[0] = kLZ4Compression; // level‑0 still fast

std::vector<ColumnFamilyDescriptor> cfd = {
    { "metadata", meta_opts },
    { "events",   events_opts }
};

std::vector<ColumnFamilyHandle*> handles;
DB* db;
Status s = DB::Open(db_opts, "/mnt/rocksdb", cfd, &handles, &db);
assert(s.ok());

Key points:

• compression_per_level lets you override the default for specific compaction levels (e.g., keep level‑0 uncompressed to avoid decompression on the hottest data).
• Changing compression after data exists only affects new SST files; old files stay with their original algorithm until they are compacted.

Validation Micro‑Benchmark

Run the built‑in db_bench tool on a staging node that mirrors production hardware. The command below writes 1 GiB of 1 KiB random keys/values with each compressor and reports write throughput, disk usage, and read latency.

# Run as the same user that owns the RocksDB data directory
for comp in snappy lz4 lz4hc zstd bzip2; do
  ./db_bench \
    --benchmarks=fillseq,readseq \
    --num=1000000 \
    --value_size=1024 \
    --compression_type=$comp \
    --db=/tmp/rocksdb_bench_$comp \
    --statistics=1 \
    --threads=4
  echo "--- $comp done ---"
done

What to check (run after each iteration):

1. Write throughput (MB/s) – higher is better for ingest.
2. Resulting DB size (bytes) – lower means better compression.
3. Average read latency (µs) – watch for spikes when decompression dominates.
4. CPU utilization (via top or pidstat) – ensure it stays within your budget.

Compare the numbers against your SLAs. If Zstd saves 30 % space but adds 150 µs read latency, decide whether the storage cost outweighs the latency penalty.

Limitations and Practical Checks

• No hot‑swap: Changing compression for existing data requires a full compaction or a CompactRange call that rewrites all SST files. Plan a maintenance window.
• Build‑time availability: Some distributions ship RocksDB without Zstd or BZip2. Verify with ldd $(which rocksdb) | grep -E 'zstd|bz2' or by attempting to open a DB with the desired type; RocksDB will log a warning if unsupported.
• Interaction with block size: Larger block sizes (default 4 KiB) improve compression ratio but increase read‑amplification for point lookups. Test block sizes 4 KiB, 16 KiB, 64 KiB together with your chosen compressor.
• Cache effects: Compressed blocks occupy less block‑cache space, potentially raising hit rates. Monitor rocksdb.block.cache.hit and miss counters after deployment.

Quick Verification Checklist

1. Open the DB with the target compression; confirm no Unsupported compression type warning in LOG.
2. Run the db_bench suite on a representative dataset.
3. Inspect rocksdb.stats for compression_ratio and compaction.read.bytes vs compaction.write.bytes.
4. Validate block‑cache hit rate stays ≥ 90 % for read‑heavy column families.
5. Document the chosen algorithm per column family in your deployment playbook.

Summary

Pick Snappy for latency‑critical paths, Zstd when disk is scarce, and LZ4/LZ4HC as a middle ground. Apply the setting per column family, use compression_per_level to keep the hottest level fast, and always benchmark on production‑like hardware before rolling out. The configuration is static for existing data, so treat a compression change as a data‑migration event.
