Building Real-Time Collaboration at the Edge with Cloudflare Durable Objects

The Problem: Stateful Edge Applications Without the Operational Burden

You need a real-time collaboration feature—shared cursors, live counters, collaborative editing—but you don't want to provision WebSocket servers, manage Redis clusters, or reason about cross-region consistency. Traditional architectures push state to a central database and stateless compute, adding latency for every interaction. Cloudflare Durable Objects flip this: they bring a single-threaded, strongly consistent compute instance to the edge, co-located with its own SQLite database, while Workers handle the stateless fan-out.

Actor Model at the Edge

Each Durable Object instance has a globally unique identifier (typically derived from a room ID, document key, or user session). The runtime guarantees that only one instance of a given ID executes at a time, anywhere in Cloudflare's network. This single-threaded execution eliminates race conditions without distributed locks. Workers scale horizontally around these objects, forwarding requests via RPC stubs.

The programming model is deliberately minimal: a JavaScript class with a constructor receiving DurableObjectState and Env, plus optional fetch, webSocketMessage, webSocketClose, and alarm handlers. The state.storage API provides a private SQLite database per object (since the 2023 sql storage backend), with ACID transactions and point-in-time recovery.

Worked Example: Real-Time Collaboration Counter

Consider a shared counter where multiple clients increment a value and see updates instantly. The Durable Object owns the count and the set of connected WebSockets.

// counter.ts
export class Counter {
  private count = 0;
  private sockets: WebSocket[] = [];

  constructor(private state: DurableObjectState, private env: Env) {
    // Load persisted count on cold start
    this.state.blockConcurrencyWhile(async () => {
      const stored = await this.state.storage.sql.exec(
        `SELECT value FROM counter WHERE key = 'count'`
      );
      this.count = stored[0]?.value ?? 0;
    });
  }

  async fetch(req: Request): Promise {
    const upgradeHeader = req.headers.get('Upgrade');
    if (upgradeHeader !== 'websocket') {
      return new Response('Expected WebSocket', { status: 400 });
    }
    const [client, server] = Object.values(new WebSocketPair());
    this.sockets.push(server);
    server.accept();
    server.send(JSON.stringify({ type: 'init', count: this.count }));
    return new Response(null, { status: 101, webSocket: client });
  }

  webSocketMessage(ws: WebSocket, message: string) {
    const msg = JSON.parse(message);
    if (msg.type === 'increment') {
      this.count++;
      // Persist atomically
      this.state.storage.sql.exec(
        `INSERT INTO counter (key, value) VALUES ('count', ?)
         ON CONFLICT(key) DO UPDATE SET value = excluded.value`,
        this.count
      );
      // Broadcast to all connected clients
      const payload = JSON.stringify({ type: 'update', count: this.count });
      this.sockets.forEach(s => s.send(payload));
    }
  }

  webSocketClose(ws: WebSocket) {
    this.sockets = this.sockets.filter(s => s !== ws);
  }
}

The Worker entry point routes by room ID:

// worker.ts
export default {
  async fetch(req: Request, env: Env): Promise {
    const url = new URL(req.url);
    const roomId = url.pathname.slice(1) || 'default';
    const id = env.COUNTER.idFromName(roomId);
    const stub = env.COUNTER.get(id);
    return stub.fetch(req);
  }
} satisfies ExportedHandler;

In wrangler.toml, define the binding and enable SQL storage:

[durable_objects]
bindings = [
  { name = "COUNTER", class_name = "Counter" }
]
migrations = [
  { tag = "v1", new_sqlite_classes = ["Counter"] }
]

Clients connect via wss://your-worker.your-subdomain.workers.dev/room-123. The first connection to a room cold-starts the object (50–200 ms), loads the count from SQLite, and subsequent messages are processed in-memory with sub-millisecond latency. When all sockets close, the object hibernates—serialized to disk, no object-hour charges accrue until the next message arrives.

WebSocket Hibernation and Billing Reality

Hibernation is the economic enabler for long-lived connections. Without it, an idle WebSocket would keep the object in memory, accruing object-hour charges 24/7. With webSocketMessage and webSocketClose handlers defined, the runtime automatically suspends the isolate after the last event handler returns. The next incoming message resumes execution from the same in-memory state (or reconstructs it from the serialized snapshot).

Billing components to watch:

• Object-hours: Wall-clock time the object exists in memory. Hibernated objects do not count.
• Requests: Each WebSocket upgrade counts as one request; subsequent messages over the same connection do not.
• CPU time: Only charged while your code executes.

For a collaboration room with 50 users connected 8 hours/day but active only 30 minutes total, hibernation reduces object-hours from ~400/month to ~15/month.

Trade-offs and Limitations

Single-location consistency. A Durable Object lives in one data center at a time. If that region fails, the object becomes unavailable until Cloudflare's control plane migrates it (typically seconds). For disaster recovery, you must implement your own replication—e.g., periodic exports via point-in-time recovery to R2—or accept the RTO.

Storage ceiling. Each object has a 128 MB SQLite limit (soft). Large blobs belong in R2; store only metadata and indexes in the object.

Cold starts for new IDs. First access to a never-before-seen room ID incurs isolate spin-up. For predictable hot rooms (e.g., scheduled events), pre-warm with a Cron Trigger that calls a no-op RPC method.

Local development gaps. wrangler dev uses an in-memory SQLite shim without fsync durability. Test migrations and persistence semantics against a remote preview deployment (wrangler deploy --dry-run + wrangler tail) before production.

Next Steps

1. Run npm create cloudflare@latest, choose "Workers with Durable Objects", and select the SQL storage backend.
2. Paste the counter example above, adjust wrangler.toml with your account details, and deploy.
3. Open two browser tabs to the same room URL; verify increments broadcast instantly.
4. In the Cloudflare dashboard > Workers & Pages > your Worker > Durable Objects tab, confirm storage usage shows a few KB and object-hours remain near zero after closing tabs.
5. Add a migration: create a v2 entry in migrations with a SQL script to add a last_updated column, then redeploy. The runtime applies it atomically on next object start.

Durable Objects won't replace every database, but for coordination-heavy, latency-sensitive workloads—presence, locking, session state, real-time sync—they eliminate an entire tier of infrastructure. Start with a single room, measure the cold-start and hibernation behavior, then scale the pattern.
