Build One Template, Multiple Architectures: Packer’s Multi‑Arch Builder Simplified

The Real Problem

When you need images for both amd64 and arm64—for example, an Ubuntu 20.04 AMI that runs on both x86‑64 and ARM‑based EC2 instances—you’re forced to duplicate almost every line of a Packer template. You create two separate templates, each with its own builders block, and you copy‑paste provisioners, post‑processors, and variables. That duplication is easy to error‑prone and hard to keep in sync.

What Packer 1.8+ Gives You Instead

Starting with version 1.8, Packer supports a platforms array inside a single builds block. The builder automatically spawns a parallel build for each architecture you list. The result is a single, DRY template that produces a separate image per architecture, each named with the architecture suffix.

Key Syntax Elements

• builds – top‑level block that can contain multiple build definitions.
• builder – the type of builder (e.g., amazon-ebs, virtualbox-iso).
• platforms – array of strings like "amd64" or "arm64" that Packer will iterate over.
• post-processor – applied to each architecture build; you can target specific architectures with platforms inside the post‑processor too.

Concrete Example: Ubuntu 20.04 AMIs for AWS

Below is a minimal HCL2 template that builds two AMIs—one for amd64 and one for arm64—using the same source ISO, provisioners, and post‑processor. Replace <YOUR-AWS-REGION> and other placeholders with your actual values.

variable "aws_region" {
  default = "<YOUR-AWS-REGION>"
}

variable "source_iso" {
  default = "ubuntu-20.04.5-live-server-amd64.iso"
}

build {
  name = "ubuntu-20.04"

  builder {
    type      = "amazon-ebs"
    ami_name  = "ubuntu-20.04-${var.platform}"
    instance_type = "t2.micro"
    source_ami_filter {
      filters = {
        name                = "ubuntu/images/hvm-ssd/ubuntu-focal-20.04-amd64-server-*"
        root-device-type    = "ebs"
        virtualization-type = "hvm"
      }
      most_recent = true
      owners      = ["099720109477"]
    }
    region = var.aws_region
    platform = var.platform
  }

  provisioner "file" {
    source      = "setup.sh"
    destination = "/tmp/setup.sh"
  }

  provisioner "shell" {
    inline = ["chmod +x /tmp/setup.sh", "/tmp/setup.sh"]
  }

  post-processor "manifest" {
    output = "manifest-${var.platform}.json"
  }
}

# The multi‑arch loop
locals {
  archs = ["amd64", "arm64"]
}

# This block expands into two builds, one per architecture
build {
  for_each = local.archs
  name     = "ubuntu-20.04-${each.key}"
  sources  = ["build.ubuntu-20.04"]
  variables = {
    platform = each.key
  }
}

Run it with:

packer build -debug template.pkr.hcl

During execution you’ll see two parallel build logs, one for amd64 and one for arm64. After completion, the output directory will contain:

• ubuntu-20.04-amd64.json – the manifest for the x86 image
• ubuntu-20.04-arm64.json – the manifest for the ARM image
• Any other post‑processor artifacts, each suffixed with the architecture.

Trade‑offs & Practical Limits

• Builder Support – Not every builder can target every architecture. For example, virtualbox-iso only supports amd64, so attempting to build arm64 will error during the builder phase. Always check the builder documentation for supported platforms.
• Resource Consumption – Parallel builds run concurrently, which can double or triple CPU and disk I/O on a CI runner. If your environment is constrained, use the parallelism flag or wrap the builds in a for_each that limits concurrency.
• Variable Scope – The platform variable is injected into the inner build via variables. If you need to reference the architecture elsewhere (e.g., in a shell script), expose it as an environment variable with environment_vars = [{"PLATFORM" = var.platform}].
• Naming Conflicts – Packer automatically appends the architecture suffix to the ami_name and any post‑processor output filenames. If you override naming conventions, you may need to manually add the suffix.

Actionable Next Steps

1. Verify you’re on Packer 1.8+ by running packer version.
2. Start with the example above, replacing placeholders with your own ISO path, AWS credentials, and region.
3. Run packer build -debug template.pkr.hcl locally to confirm that two parallel builds start and finish successfully.
4. Integrate the template into your CI pipeline. If you’re using GitHub Actions, add a runs-on: ubuntu-latest job and set packer build -parallelism=2 to control concurrency.
5. Monitor resource usage. If you hit limits, consider running the builds sequentially with packer build -parallelism=1 or splitting the template into separate files.
6. Once the images are built, test them on each target architecture to ensure that provisioners ran correctly and the system boots as expected.

By leveraging Packer’s platforms array, you cut template duplication in half and guarantee that every architecture receives the same configuration. The only real cost is the extra resources needed for parallel execution, which most CI environments can handle with a small tweak to concurrency settings.
