Packer HCL2 Dynamic Blocks: Building Multi‑Region AMIs Without Copy‑Paste Drift

The problem: duplicated builder blocks across regions

Teams that ship the same Ubuntu base image to five AWS regions often end up with five nearly identical source "amazon-ebs" blocks. A change to the AMI name, instance type, or user‑data script means editing every block — and inevitably one region gets left behind.

Thesis: dynamic blocks turn a map of regions into parallel builders at parse time

Packer 1.7 introduced HCL2 and, with it, dynamic blocks that expand a for_each loop into concrete source blocks before any builder runs. The result is a single source definition that yields N builders, each named ubuntu-2204., while keeping provisioners and post‑processors shared.

Dynamic blocks in practice

Define a variable that holds region‑specific settings — AMI IDs, subnet IDs, tags — then iterate over it:

variable "regions" {
  type = map(object({
    ami_id     = string
    subnet_id  = string
    tags       = map(string)
  }))
  default = {
    us-east-1 = { ami_id = "ami-0abc123", subnet_id = "subnet-111", tags = { Env = "prod" } }
    eu-west-1 = { ami_id = "ami-0def456", subnet_id = "subnet-222", tags = { Env = "prod" } }
  }
}

source "amazon-ebs" "ubuntu-2204" {
  dynamic "source" {
    for_each = var.regions
    content {
      region      = source.key
      source_ami  = source.value.ami_id
      subnet_id   = source.value.subnet_id
      instance_type = "t3.micro"
      tags        = merge(source.value.tags, { Name = "ubuntu-2204-${source.key}" })
    }
  }
  # shared provisioners go here
  provisioner "shell" {
    inline = ["sudo apt-get update && sudo apt-get install -y nginx"]
  }
}

build {
  sources = ["source.amazon-ebs.ubuntu-2204"]
  post-processor "manifest" { output = "manifest.json" }
}

Running packer inspect on this template lists two builders: amazon-ebs.ubuntu-2204.us-east-1 and amazon-ebs.ubuntu-2204.eu-west-1. A single packer build invocation launches both in parallel.

Variable validation catches mis‑configured AMI IDs before any API call

Since Packer 1.8 you can attach a validation block to any input variable. The check runs during packer validate (or build) and fails fast if a required field is empty or malformed:

variable "regions" {
  # …type definition…
  validation {
    condition     = alltrue([for r in var.regions : length(r.ami_id) > 0])
    error_message = "Every region must provide a non‑empty ami_id"
  }
}

If a CI pipeline accidentally passes an empty map, packer validate -var-file=prod.pkrvars.hcl exits with a clear error instead of spinning up instances.

Trade‑off: expansion happens at configuration load time

Dynamic blocks cannot reference resources that are created later in the same build (no dependency graph). The for_each map must be fully known from input variables or locals — you cannot, for example, query the AWS API for the latest AMI inside the loop. If you need data‑driven counts, compute the map in a preceding step (e.g., a Terraform data source) and pass it as a variable.

Actionable next step

1. Upgrade your CI runners to Packer ≥1.7.0 (packer version).
2. Convert any remaining JSON templates with packer convert, then hand‑tune the generated dynamic blocks for readability.
3. Add a validation block for each critical variable and run packer validate -var-file=env.pkrvars.hcl in your pipeline before the build stage.
4. Verify the generated builder names with packer inspect to confirm the expected region count.

With these two HCL2 features — dynamic blocks and variable validation — you eliminate copy‑paste drift, catch configuration errors at parse time, and keep a single source of truth for multi‑region image pipelines.
