Apollo Federation: Stitch Two Subgraphs into a Single Gateway

Why Use Apollo Federation?

Apollo Federation lets you keep each micro‑service’s GraphQL schema isolated while still presenting a unified API to your clients. The gateway stitches the schemas together by resolving entity references across services.

Core Concepts

• @key – Declares the primary identifier for an entity that lives in a subgraph.
• @provides – Indicates that a field in one subgraph can supply data for a field in another.
• @requires – Declares that a field depends on data from another subgraph.
• @external – Marks a field as defined in another subgraph.

Step‑by‑Step Example

We’ll create two minimal subgraphs: user-service and post-service. They will share the User entity. The gateway will then expose a single endpoint to the client.

1. Setup the User Service (Subgraph A)

// user-service/package.json
{
  "name": "user-service",
  "version": "1.0.0",
  "dependencies": {
    "apollo-server": "^4.0.0",
    "graphql": "^16.0.0"
  }
}

// user-service/index.js
const { ApolloServer, gql } = require('apollo-server');

const typeDefs = gql`
  type User @key(fields: "id") {
    id: ID!
    name: String
  }

  extend type Query {
    user(id: ID!): User
  }
`;

const resolvers = {
  Query: {
    user: (_, { id }) => ({ id, name: `User ${id}` })
  },
  User: {
    __resolveReference: ({ id }) => ({ id, name: `User ${id}` })
  }
};

const server = new ApolloServer({ typeDefs, resolvers });
server.listen({ port: 4001 }).then(({ url }) => console.log(`User service ready at ${url}`));

2. Setup the Post Service (Subgraph B)

// post-service/package.json
{
  "name": "post-service",
  "version": "1.0.0",
  "dependencies": {
    "apollo-server": "^4.0.0",
    "graphql": "^16.0.0"
  }
}

// post-service/index.js
const { ApolloServer, gql } = require('apollo-server');

const typeDefs = gql`
  type Post @key(fields: "id") {
    id: ID!
    title: String
    author: User @provides(fields: "name")
  }

  extend type Query {
    post(id: ID!): Post
  }
`;

const resolvers = {
  Query: {
    post: (_, { id }) => ({ id, title: `Post ${id}` })
  },
  Post: {
    __resolveReference: ({ id }) => ({ id, title: `Post ${id}` })
  }
};

const server = new ApolloServer({ typeDefs, resolvers });
server.listen({ port: 4002 }).then(({ url }) => console.log(`Post service ready at ${url}`));

3. Create the Gateway

// gateway/package.json
{
  "name": "gateway",
  "version": "1.0.0",
  "dependencies": {
    "@apollo/gateway": "^2.0.0",
    "apollo-server": "^4.0.0",
    "graphql": "^16.0.0"
  }
}

// gateway/index.js
const { ApolloServer } = require('apollo-server');
const { ApolloGateway } = require('@apollo/gateway');

const gateway = new ApolloGateway({
  serviceList: [
    { name: 'user', url: 'http://localhost:4001/graphql' },
    { name: 'post', url: 'http://localhost:4002/graphql' }
  ]
});

const server = new ApolloServer({ gateway, subscriptions: false });
server.listen({ port: 4000 }).then(({ url }) => console.log(`Gateway ready at ${url}`));

4. Verify the Composition

Run each service and the gateway in separate terminals:

• npm run start in user-service (port 4001)
• npm run start in post-service (port 4002)
• npm run start in gateway (port 4000)

Open the Gateway’s GraphQL Playground at http://localhost:4000 and execute:

query {
  _entities(representations: [{ __typename: "User", id: "1" }]) {
    ... on User {
      id
      name
    }
  }
}

The response should include the name field resolved by the User subgraph. You can also query a Post that references a User:

query {
  _entities(representations: [{ __typename: "Post", id: "10" }]) {
    ... on Post {
      id
      title
      author {
        name
      }
    }
  }
}

Logs from each subgraph will show that the gateway routed the entity resolution to the appropriate service.

Common Pitfalls

• Version Mismatch – The gateway and subgraphs must use compatible Apollo Server and @apollo/gateway releases. Mixing 3.x subgraphs with a 4.x gateway can break schema composition.
• Missing @key – Every federated entity requires a @key. Forgetting it results in a schema error during gateway startup.
• Exposing Introspection – The gateway’s /graphql endpoint exposes the entire schema. In production, secure it behind authentication or disable introspection.
• Circular Dependencies – Two subgraphs that reference each other’s entities in a loop cause the gateway to hang. Avoid or break the cycle with @provides and @requires carefully.
• Unupdated Directives – Adding a field that depends on another subgraph’s field requires updating @requires or @provides accordingly.

Performance Considerations

• Each entity resolution may involve a round‑trip to the owning subgraph. Use the gateway’s built‑in DataLoader caching to batch multiple references into a single request.
• Enable debug: false in production to reduce logging overhead.
• Monitor the gateway’s executionTime and entityResolutionTime metrics to spot bottlenecks.

Practical Checklist

1. Define a unique @key for every federated type.
2. Keep subgraphs and the gateway on the same major Apollo Server version.
3. Test the gateway locally with graphql-playground before deploying.
4. Secure introspection in production.
5. Use __resolveReference resolvers that return the minimal fields required by other subgraphs.
6. Enable caching in the gateway to mitigate round‑trip latency.

Conclusion

Apollo Federation provides a clean, declarative way to compose independent GraphQL services. By following the example above, you can set up a gateway that stitches two subgraphs, verify the composite schema, and avoid common pitfalls. Remember to keep versions aligned, secure introspection, and monitor performance to maintain a healthy federated architecture.
