Zero‑Cost Fixed‑Size Buffers in Rust with Const Generics

The Problem: Runtime Overhead for Known Sizes

When writing drivers or tight loops you often need a buffer whose size is known at compile time – for example a 256‑byte receive ring for a UART. Using a plain [u8; N] array works, but if you want to expose the buffer through a generic API you either lose the size information (using Vec) or resort to unsafe transmutes. Both approaches add either runtime checks or the risk of undefined behaviour.

Thesis: Const Generics Give Compile‑Time Lengths

Rust’s const generics let you treat a usize value as a type parameter. The compiler monomorphizes the code for each concrete length, so the generated machine code contains no length checks or heap allocations – the abstraction is zero‑cost.

Worked Example: A UART‑Style Stack

use core::marker::PhantomData;

/// A simple LIFO stack backed by a fixed‑size array.
pub struct Stack {
    buf: [u8; N],
    len: usize,
}

impl Stack {
    /// Create an empty stack.
    pub const fn new() -> Self {
        Self { buf: [0; N], len: 0 }
    }

    /// Push a byte, returning an error if the stack is full.
    pub fn push(&mut self, byte: u8) -> Result<(), ()> {
        if self.len >= N {
            return Err(());
        }
        self.buf[self.len] = byte;
        self.len += 1;
        Ok(())
    }

    /// Pop a byte, returning None if the stack is empty.
    pub fn pop(&mut self) -> Option {
        if self.len == 0 {
            return None;
        }
        self.len -= 1;
        Some(self.buf[self.len])
    }
}

fn main() {
    let mut s = Stack::<32>::new();
    s.push(0xAA).unwrap();
    assert_eq!(s.pop(), Some(0xAA));
}

To verify that no runtime length checks appear, compile with cargo build --release and inspect the generated assembly:

$ objdump -d target/release/your_binary | grep -A2 -B2 "push\|pop"

You will see only straight‑line moves and increments; the comparison if self.len >= N becomes a compile‑time constant when N is known, so the branch is eliminated for constant‑propagation optimizations.

Trade‑offs and Limits

• Each distinct N creates a separate monomorphized copy of Stack, increasing compile time and binary size.
• Only values that the compiler can evaluate as const expressions may be used (literals, const fn results, or const { expr } blocks). Runtime values cannot become a const generic argument.
• Debugging const‑generic errors can be awkward because the error points to the definition site; you must inspect the call site to see which N triggered the problem.

Actionable Advice

1. Start by wrapping existing array‑based APIs in a thin const‑generic wrapper like the Stack above.
2. Benchmark compile‑time impact for the sizes you actually need (e.g., time cargo clean && time cargo build --release for N = 8, 32, 256).
3. Enable the wrapper only for lengths that are truly known at compile time; keep a fallback Vec-based version for dynamic cases.
4. If you hit const‑expression limits, consider moving the computation to a const fn on stable Rust (≥1.51) or use nightly features like generic_const_exprs for more complex formulas.
