WireGuard vs OpenVPN on pfSense: A Decision Guide for Remote‑Access VPNs

Problem & Takeaway

When you need to expose your corporate network to remote users or sites, pfSense gives you two mature VPN options: WireGuard and OpenVPN. The choice hinges on client diversity, throughput demands, network traversal, and whether you’re running the free CE edition or the commercial Plus stack. The takeaway: use WireGuard for high‑bandwidth, key‑based tunnels on managed devices, and OpenVPN when you need per‑user authentication, MFA, or TCP‑443 fallback in hostile networks.

Decision Context

Typical constraints when picking a remote‑access VPN:

• Client OS diversity: Windows, macOS, Linux, iOS, Android.
• Throughput needs: video conferencing, large file sync, or low‑latency gaming.
• NAT traversal: clients behind carrier‑grade NAT or strict firewalls.
• Authentication model: per‑user accounts, MFA, or simple key‑based.
• pfSense edition: CE (free) vs Plus (commercial).

Supported Options

Feature	WireGuard	OpenVPN
Availability	CE: package; Plus: integrated	Built‑in, no extra package
Protocol type	UDP only, key‑based	TCP or UDP, certificate or user auth
Throughput / CPU	Very high, low overhead	Higher CPU, lower throughput
Client diversity	All major OSes, but requires manual key distribution	All major OSes, built‑in client export
NAT traversal	UDP, may struggle on strict firewalls	TCP 443 fallback, robust NAT support
User auth & MFA	No built‑in user model; key revocation is manual	Integrated with local, RADIUS, LDAP, MFA
Management	Peer list, allowed‑ips, simple config	Per‑client overrides, detailed logs
Security model	Ephemeral keys, minimal attack surface	Certificate chains, more complex

Trade‑Offs

WireGuard shines when you need speed and simplicity. Its tiny codebase reduces attack surface and its key‑only handshake eliminates the need for a full authentication stack. However, you lose per‑user identities and MFA, and you must manually revoke keys if a device is compromised.

OpenVPN offers richer policy control: you can enforce per‑user certificates, MFA, and granular firewall rules. Its ability to run over TCP 443 makes it reliable in restrictive networks, but the extra TLS handshake and per‑tunnel CPU cost can throttle throughput, especially on low‑power hardware.

In practice, a hybrid approach is common: WireGuard for internal site‑to‑site links and managed road‑warriors; OpenVPN for untrusted consumer devices that need MFA.

Concrete Implementation – WireGuard

Below is a minimal WireGuard setup on pfSense CE (requires the wireguard package). Replace placeholders with your real values.

# 1. Install the WireGuard package (only once per system)
# 2. Create the tunnel interface
Firewall > Interfaces > Assign > Click the + icon > select WireGuard
# 3. Configure the tunnel
Interfaces > OPT1 (WireGuard) > Edit
   Interface IP: 10.0.0.1/24
   Enable: checked
# 4. Add peers
VPN > WireGuard > Add Peer
   Public Key: <client_public_key>
   Allowed IPs: 10.0.0.2/32
   Endpoint Host: <client_ip>
   Endpoint Port: 51820
# 5. Firewall rule to allow traffic
Firewall > Rules > OPT1 (WireGuard) > Add
   Action: Pass
   Interface: WireGuard
   Source: any
   Destination: LAN subnet (e.g., 192.168.1.0/24)
   Description: "Allow VPN to LAN"
# 6. Apply changes

Key points:

• Allowed‑IPs doubles as routing and ACL; misconfiguring it can expose unintended subnets.
• pfSense CE uses the wireguard kernel module; ensure your version supports the feature you need.
• Revoke a device by disabling or deleting its peer entry.

Concrete Implementation – OpenVPN

OpenVPN is built into pfSense. The wizard and Client Export package simplify deployment.

# 1. OpenVPN server wizard
VPN > OpenVPN > Wizards > Server Wizard
   Server mode: Remote Access (SSL/TLS + User Auth)
   Protocol: UDP 1194 (or TCP 443 for NAT‑traversal)
   Server host: <public_ip_or_fqdn>
   Port: 1194
   Crypto settings: 2048‑bit RSA, AES‑256‑CBC
   User authentication: local (or RADIUS/LDAP)
# 2. Client Export package
System > Package Manager > Available Packages > Install Client Export
# 3. Export client profiles
VPN > Client Export > Select user > Export
   Choose .ovpn file or ZIP for mobile clients
# 4. Firewall rule (optional, if not auto‑created)
Firewall > Rules > OpenVPN > Add
   Action: Pass
   Source: any
   Destination: LAN subnet

OpenVPN automatically creates a dedicated interface (e.g., ovpns1) and applies the rule. The Client Export package bundles the necessary certificates and configuration into a single file for easy deployment to Windows, macOS, iOS, or Android.

Validation & Troubleshooting

After deployment, verify the tunnel works and performance meets expectations.

WireGuard Validation

# On the pfSense shell (or SSH) – check peer status
wg show
# Expected output: peer public key, latest handshake, transfer stats
# Test connectivity
ping -c 4 192.168.1.10   # LAN host behind the VPN
# Throughput test (on a client with iperf3 installed)
iperf3 -c 10.0.0.1 -t 30
# Review firewall logs for expected traffic
Status > System Logs > Firewall
# Look for rules matching the WireGuard interface and source/destination

OpenVPN Validation

# On the pfSense web GUI
Status > OpenVPN
# Verify server is running and clients are connected
# On a client, run
ping -c 4 192.168.1.10
iperf3 -c 10.0.0.1 -t 30
# Check logs
Status > System Logs > OpenVPN

Common pitfalls:

• WireGuard – Allowed‑IPs mis‑set to 0.0.0.0/0 will route all traffic through the tunnel, potentially exposing your public interface.
• OpenVPN – Using TCP on a lossy link can cause TCP‑over‑TCP “head‑of‑line” blocking; prefer UDP unless blocked.
• pfSense CE may have older kernel modules; verify wireguard is present by running kldstat | grep wireguard.

Practical Checklist

1. Identify your client base: managed devices vs consumer devices.
2. Measure baseline throughput on your hardware.
3. Decide on authentication: key‑only vs per‑user with MFA.
4. Choose WireGuard for high bandwidth, simple key distribution; choose OpenVPN if you need per‑user policies or TCP‑443 fallback.
5. Implement the chosen VPN, apply firewall rules, and export client configs.
6. Validate connectivity, throughput, and logs as shown above.
7. Document key revocation procedures (WireGuard) or user deactivation (OpenVPN).

Limitations & Future Work

pfSense’s WireGuard implementation is still evolving; future releases may add user‑level revocation or integration with RADIUS. OpenVPN’s performance can be improved with the tls-auth option or by tuning the MTU. Monitor pfSense release notes for changes that affect your chosen VPN.

Conclusion

Pick WireGuard when you need speed and simplicity on managed devices; pick OpenVPN when you require per‑user authentication, MFA, or robust traversal through restrictive networks. The concrete steps above give you a repeatable path to deploy and validate your choice on pfSense CE or Plus.
