Why Nim 2.0 Defaults to ORC: Deterministic Memory Without a Tracing GC

The problem: GC pauses don't fit every target

Tracing garbage collectors simplify application code but introduce unpredictable latency and require a runtime that isn't available on bare-metal, WebAssembly, or constrained embedded targets. Nim 1.4 introduced ARC (Automatic Reference Counting) and ORC (Optimized Reference Counting) as compile-time alternatives. Since Nim 2.0, --mm:orc is the default—a pragmatic engineering decision that trades a modest binary-size increase for deterministic destruction and no GC runtime.

How ARC and ORC differ from a tracing GC

ARC inserts retain/release calls at compile time based on ownership analysis, and defers destructors to scope exit. This gives you RAII semantics similar to C++ or Rust without a background collector. ORC adds a lightweight cycle collector that runs periodically or on demand, reclaiming reference cycles (doubly-linked lists, observer graphs) without requiring pervasive weak annotations. Both operate on thread-local heaps; cross-thread sharing requires explicit shared annotations and atomic reference counts.

Why the default matters for systems work

With --mm:arc or --mm:orc, Nim compiles to targets that have no OS runtime: --os:standalone for bare metal, --target:wasi for WebAssembly, or microcontroller toolchains. Objects have predictable lifetimes, so passing pointers to C/C++ libraries doesn't require pinning or GC-root registration—though you must ensure C code doesn't store Nim pointers beyond the Nim object's scope. The borrow-checker-like lent/owned annotations (still evolving) add compile-time safety for aliasing without runtime cost.

Worked example: a cyclic doubly-linked list under ORC

Create a minimal project to see ORC collect a cycle automatically:

# list.nim
import std/memory

type
  Node* = ref object
    value: int
    prev, next: Node

proc newNode(v: int): Node =
  new(Node, value: v)

proc link(a, b: Node) =
  a.next = b
  b.prev = a

when isMainModule:
  var head = newNode(1)
  var tail = newNode(2)
  link(head, tail)
  link(tail, head)  # creates a cycle
  # head and tail go out of scope here
  echo "Scope exited; ORC will collect the cycle on next collection"
  GC_collect()  # force collection for demo
  echo "Collection done"

Build and run with cycle-collector logging:

nim c --mm:orc --debug:gc list.nim
./list

You should see debug output indicating the cycle collector ran and freed the two nodes. With --mm:arc (no cycle collector) the same program would leak the cycle until process exit. With --mm:refc (legacy deferred-reference-counting GC) the tracing collector would eventually reclaim it, but at non-deterministic times.

Trade-offs you should weigh

• Binary size: --mm:arc binaries are typically 10–20% larger than --mm:refc equivalents because of inserted retain/release calls.
• Compile time: ownership analysis adds front-end work; large codebases see noticeably longer compiles.
• Cycle collector pauses: ORC's collection scales with reachable objects in cycles—usually sub-millisecond, but not hard real-time.
• Thread sharing complexity: shared objects use atomic refcounts; highly concurrent designs need careful architecture.
• Ecosystem friction: some Nimble packages still assume --mm:refc semantics; migration may require forks or upstream fixes.
• Leak debugging: a missing dealloc can be far from the leak site; --memAnalysis helps but isn't a full leak detector.

How to decide for your project

1. Start with the default --mm:orc for applications, CLIs, and services where deterministic latency and lower memory overhead matter.
2. Use --mm:arc for bare-metal, WASI, or kernels where even the cycle collector's runtime is unwanted.
3. Stick with --mm:refc or --mm:boehm only if you depend on libraries that haven't been ported or if you need the mature tracing GC for very large heaps with complex object graphs.
4. Verify: build your representative workload with each --mm option, measure binary size, RSS, and tail latency. Run koch tests with your chosen mode to catch stdlib regressions.

The Nim 2.0 default reflects a bet that most systems code benefits more from predictable destruction than from the throughput of a tracing collector. If your target lacks a runtime or your latency budget is tight, ORC is a practical, well-supported choice—just budget for the compile-time and binary-size costs.
