When to Enable WebGPU Timestamp Queries for GPU Pass Measurement

Decision Overview

Enable WebGPU timestamp queries for production profiling only when the adapter reports the timestamp-query feature and you need GPU-side timing of a specific pass rather than a wall-clock estimate. If the feature is absent, fall back to CPU timing around queue.submit or to shader-based instrumentation.

Constraints

• Adapter must expose timestamp-query in adapter.features. Availability varies by browser and OS and may be behind flags.
• Each timestamp is 8 bytes. A resolve buffer must be sized for the number of queries and a separate staging buffer is required for MAP_READ.
• Readback requires a GPU to CPU copy and mapAsync. Mapping stalls the pipeline until the data is ready.
• Timestamp values are GPU timestamps in nanoseconds per the WebGPU spec. They measure execution on the GPU, not wall time, and are not comparable across adapters.

Option Comparison

Option	What It Measures	Instrumentation Cost	Availability	Typical Overhead
Timestamp Queries	GPU timestamp at start and end of a pass	Low: one writeTimestamp per range, query set and resolve buffers	Only with timestamp-query feature	Small GPU overhead for resolve; CPU stall only on readback
CPU Timing performance.now	Wall-clock time around queue.submit	None	Universal	Includes submission and scheduling latency; inaccurate for overlapping work
Instrumented Shader Counters	Custom counters written from shaders	Higher: extra instructions and register pressure	All adapters	Can change shader performance; needs resolve/readback

Trade-offs

• Timestamp queries give GPU-side duration with minimal shader impact. They require feature support, a query set, a resolve buffer and a staging buffer. Frequent readback adds synchronization cost.
• CPU timing is always available and adds no GPU work, but it conflates command submission, queue scheduling and execution.
• Shader counters are portable but alter shader resource usage and may affect the measurement.

Implementation Pattern

Run in browser JavaScript after a WebGPU device is obtained. No special permissions are required.

// 1. Feature check
if (!adapter.features.has('timestamp-query')) {
  // fallback path
  return;
}

// 2. Query set for start and end
const querySet = device.createQuerySet({
  type: 'timestamp',
  count: 2
});

// 3. Resolve buffer and staging buffer
const resolveBuffer = device.createBuffer({
  size: 2 * 8,
  usage: GPUBufferUsage.QUERY_RESOLVE | GPUBufferUsage.COPY_SRC
});

const readBuffer = device.createBuffer({
  size: 2 * 8,
  usage: GPUBufferUsage.COPY_DST | GPUBufferUsage.MAP_READ
});

// 4. Encode work
const encoder = device.createCommandEncoder();
const pass = encoder.beginRenderPass({ /* ... */ });

pass.writeTimestamp(querySet, 0);
// ... render commands ...
pass.writeTimestamp(querySet, 1);
pass.end();

// 5. Resolve and copy for readback
encoder.resolveQuerySet(querySet, 0, 2, resolveBuffer, 0);
encoder.copyBufferToBuffer(resolveBuffer, 0, readBuffer, 0, 2 * 8);

device.queue.submit([encoder.finish()]);

// 6. Read back
await readBuffer.mapAsync(GPUMapMode.READ);
const data = new BigUint64Array(readBuffer.getMappedRange());
readBuffer.unmap();

const startNs = data[0];
const endNs = data[1];
const gpuDurationNs = endNs - startNs;

Placeholders /* ... */ indicate your own render pass descriptor and commands.

Validation Steps

1. Confirm adapter.features.has('timestamp-query') before creating the query set. Creation will be rejected without the feature.
2. Create a minimal pass with two timestamps, resolve and copy, then map. Verify the returned values are non-zero and monotonic.
3. Increase workload size in a controlled way and check that measured GPU duration increases monotonically.
4. Test on target browsers and adapter types to confirm feature presence and consistent behavior.

Limitations and Practical Checks

• Avoid mapping the read buffer every frame in production. Batch reads or sample periodically to limit stalls.
• Query sets consume GPU memory. Create only the number needed for the profiling window.
• Timestamp values are per-adapter GPU timestamps. Do not compare absolute values across devices, only relative changes within the same run.
• Feature support is implementation-dependent. Check the browser documentation for flag requirements.
