Using Sourcetree’s Built‑in Git LFS Support for Large Binary Files

Problem: Large binaries bloat your Git history

When you add files such as videos, datasets, or compiled assets to a Git repository, each version creates a full copy in the object database. Over time the repository size grows, cloning becomes slow, and CI pipelines waste bandwidth.

Thesis: Sourcetree simplifies enabling Git LFS so that large files are stored as lightweight pointers while the actual content lives in a separate LFS store.

Enabling LFS in Sourcetree

Sourcetree detects a .gitattributes file and offers a one‑click wizard to track a file type with Git LFS. The steps below assume you have Sourcetree installed and a repository already cloned locally.

1. Open the repository in Sourcetree.
2. Locate the large file you want to track (e.g., a sample.mp4 that is >100 MB).
3. Right‑click the file in the file list and choose Track Large File.
4. In the wizard, confirm the file extension (or pattern) and click OK. Sourcetree will:
   • Add or update .gitattributes with a line like *.mp4 filter=lfs diff=lfs merge=lfs -text.
   • Create or update .lfsconfig with the remote LFS endpoint.
   • If Git LFS is not installed on your machine, Sourcetree will prompt to install it (requires admin rights on Windows/macOS or sudo on Linux).
5. After the wizard finishes, the file icon changes to show an LFS badge, indicating it is now a pointer object.

Worked Example: Tracking a 150 MB Video File

This example demonstrates the full lifecycle from tracking to push and verification. Replace placeholders with your own values.

1. Prepare the file

Place a video file named demo.mp4 (≈150 MB) in the root of your local repo.

2. Track the file via Sourcetree

Follow the steps in the previous section to track *.mp4. After completion, Sourcetree shows the file with an LFS icon.

3. Commit and push

In Sourcetree:

• Stage the .gitattributes change and the demo.mp4 pointer.
• Write a commit message such as "Add demo video via LFS" and click Commit.
• Click Push. Sourcetree will display a button Upload LFS Objects after the Git push; click it to transfer the actual video content to the remote LFS store.

4. Verify the result

You can confirm the workflow succeeded without needing to trust any output:

1. In Sourcetree, after the push, the file list should still show the LFS badge and no pending uploads.
2. Open a terminal (Git Bash, cmd, or shell) in the repository root and run:

   git lfs ls-files

   You should see demo.mp4 listed as an LFS object.
3. Visit the remote hosting service (e.g., GitHub, GitLab, Bitbucket) and inspect the file. The repository UI will show the file as stored in LFS, and the commit diff will display only the pointer line (something like version https://git-lfs.github.com/spec/v1).
4. Clone the repository to a different machine or directory and run:

   git lfs pull

   The actual video file should be downloaded automatically, confirming that the LFS transport works.

Trade‑offs and Limitations

While Git LFS solves the history‑bloat problem, it introduces considerations you should monitor:

• Network overhead: Each fetch or push may need to transfer the full binary size. In CI pipelines, enable LFS caching or shallow clones to reduce repeated downloads.
• Remote host requirements: The Git server must support LFS (most major services do). If you self‑host, ensure the LFS adapter is configured and has sufficient storage.
• Storage quotas: Providers often enforce limits on LFS bandwidth or storage. Check your plan’s usage dashboard regularly.
• Dependency on Git LFS binary: Sourcetree’s UI relies on the system’s git-lfs command. A missing or mismatched version leads to errors during push/pull. Keep the binary up to date via your package manager or the official installer.
• Pointer safety: If the LFS server becomes unavailable or the .lfsconfig is corrupted, the actual file data cannot be retrieved, leaving only useless pointers. Back up the LFS store or use a mirroring strategy if durability is critical.

Actionable Closing

For any repository that regularly handles assets larger than a few megabytes, enable Git LFS early:

1. Identify the file patterns (e.g., *.psd, *.zip, *.mp4) that qualify as large.
2. Use Sourcetree’s Track Large File wizard to create the appropriate .gitattributes entry.
3. Train team members to check the LFS badge before committing and to use the Upload LFS Objects button after pushing.
4. Set up a simple verification step in your CI pipeline: run git lfs ls-files and fail the step if any expected LFS object is missing.

By integrating these steps, you keep your Git history lean, reduce clone times, and still have the binary assets available when needed.
