Using Scala 3 Opaque Types for Zero‑Runtime Encapsulation: An Architecture Note

Problem Statement

When building a public Scala 3 API we often want to expose a type that callers can use safely without exposing internal representation. For example, a Money value might be stored as a Long of cents, but we want callers to treat it as a distinct type to avoid accidental mixing with other numeric values. Traditional approaches—value classes, sealed traits, or wrapper classes—introduce runtime overhead or allow pattern matching that breaks encapsulation. Scala 3’s opaque types provide a compile‑time distinct type that is represented by a primitive at runtime, giving us zero‑overhead encapsulation.

Requirements

• Scala 3.2+ (opaque types are stable from 3.2).
• Module boundary: the API must be packaged separately from the implementation.
• No pattern matching on the opaque type by clients.
• Interop with Java or libraries that expect a concrete type requires explicit conversion.
• Optional serialization support via custom codecs.

Minimal Design

The smallest working pattern uses a trait for the API and a companion object that declares the opaque type and constructor. The implementation module knows the underlying representation.

// api/Money.scala (in the API module)
package com.example.api

trait MoneyApi {
  // Opaque type declaration
  opaque type Money = Long
  object Money {
    // Constructor that enforces invariants
    def apply(cents: Long): Money = {
      require(cents >= 0, "Money cannot be negative")
      cents
    }
    // Controlled accessor
    def value(m: Money): Long = m
  }
}

In the implementation module we import the API and add domain logic. Because the opaque type is a type alias, the compiler treats Money as a distinct type at compile time but the JVM sees it as Long.

// impl/FinanceOps.scala
package com.example.impl

import com.example.api.MoneyApi

class FinanceOps extends MoneyApi {
  def add(a: Money, b: Money): Money = Money(Money.value(a) + Money.value(b))
  def toUSD(m: Money): Double = Money.value(m) / 100.0
}

Trust & Data Boundaries

• API Boundary: Exposes only the Money opaque type and safe operations.
• Implementation Boundary: Knows the underlying Long representation and can perform arithmetic.
• Clients cannot pattern match or cast Money to Long because the compiler forbids it; only the value accessor is available.
• Java callers see the underlying type unless we provide a Java‑friendly facade.

Operational Checks

1. Compile with -Xlint:opaque-types to enforce no accidental unwrapping.
2. Run a unit test that attempts m match { case Money(value) => … } and confirm a compile‑time error.
3. Inspect bytecode with javap -classpath target/classes -p com.example.api.MoneyApi to verify no new class is generated for Money.
4. Add a simple Java class that calls MoneyApi.Money.apply(100) and observe that Java code can only call value() if we expose it via a static method.

Failure Modes

• Mis‑use via unsafe casts: m.asInstanceOf[Long] bypasses the compile‑time check but will succeed at runtime. Avoid exposing raw Long values.
• Serialization defaults: Libraries like Circe will try to serialize the underlying Long directly, which may be fine, but if you rely on custom JSON keys you must provide an encoder/decoder that uses value.
• Mixed‑Scala‑2/Scala‑3 codebases: If the API is consumed by Scala 2 code, opaque types are not supported. In that case fall back to a value class or sealed trait, accepting the runtime cost.
• Reflection: Using scala.reflect.runtime.universe can expose the underlying type; avoid reflection in the API.

Conditions that Would Change the Design

• If the API must be consumed by Scala 2 code, replace opaque types with a value class: final case class Money(cents: Long) (runtime boxing occurs).
• When Java interop is a primary consumer, provide a Java facade that wraps the opaque type: a static factory and getter.
• If you need to serialize the type to a custom format (e.g., Protobuf with a dedicated field), supply a custom encoder/decoder.
• When the underlying representation is non‑primitive (e.g., a complex struct), consider a sealed trait hierarchy with a single case object to keep zero runtime overhead.

Concrete Example: Currency‑Aware Money API

Below is a more realistic snippet that includes currency handling while keeping the opaque type zero‑overhead.

package com.example.api

trait MoneyApi {
  opaque type Money = Long
  object Money {
    def apply(cents: Long, currency: String): Money = {
      require(cents >= 0, "Money cannot be negative")
      require(currency.matches("[A-Z]{3}"), "Invalid ISO currency code")
      // Pack cents and currency into a 64‑bit value: lower 32 bits cents, upper 32 bits currency hash
      val currencyHash = currency.hashCode & 0xffffffffL
      (currencyHash << 32) | (cents & 0xffffffffL)
    }
    def value(m: Money): Long = m & 0xffffffffL
    def currency(m: Money): String = {
      val hash = (m >>> 32).toInt
      // In a real system we would map hash back to currency string via a lookup table.
      "USD" // placeholder
    }
  }
}

Clients can only use Money.value and Money.currency to access the data; the internal packing logic remains hidden.

Interoperability with Java

Java callers cannot refer to the opaque type directly. A small facade can bridge this gap:

package com.example.api;

public final class MoneyFacade {
  public static long apply(long cents, String currency) {
    return com.example.api.MoneyApi.Money.apply(cents, currency);
  }
  public static long value(long money) {
    return com.example.api.MoneyApi.Money.value(money);
  }
  public static String currency(long money) {
    return com.example.api.MoneyApi.Money.currency(money);
  }
}

Java code can now call MoneyFacade.apply(100, "USD") and treat the returned long as an opaque value.

Serialization Considerations

Frameworks that rely on reflection (e.g., Jackson) will see the underlying Long and may serialize it directly. For JSON libraries that support custom codecs, provide an encoder that calls Money.value:

import io.circe.{Encoder, Decoder}

implicit val moneyEncoder: Encoder[com.example.api.MoneyApi.Money] = Encoder.encodeLong.contramap(com.example.api.MoneyApi.Money.value)
implicit val moneyDecoder: Decoder[com.example.api.MoneyApi.Money] = Decoder.decodeLong.emap { l =>
  try Right(com.example.api.MoneyApi.Money.apply(l, "USD")) // default currency
  catch { case _: IllegalArgumentException => Left("Invalid money value") }
}

Summary

Opaque types give you a clean, zero‑runtime encapsulation boundary: callers see a distinct type, the implementation knows the concrete representation, and no boxing occurs. They are ideal for API surfaces that require strict type safety and no runtime cost. However, they are Scala 3‑only, require careful handling for Java interop, and need custom serialization support if persistence is involved. When those constraints change, switch to value classes or sealed traits and accept the associated overhead.
