Using REXX CALL to Run External Commands: Minimal Design, Security, and Failure Handling

Problem & Core Takeaway

When automating system tasks from REXX you often need to run external OS commands. The CALL statement offers a simple synchronous interface, but it also introduces security and reliability concerns. The key is to wrap CALL in a minimal design that enforces a command whitelist, captures output safely, checks exit status, and cleans up resources.

Requirements

• REXX interpreter that supports CALL (IBM REXX on IBM i, IBM REXX on Unix, or REXX on Windows).
• Operating‑system permissions to execute the target commands.
• Access to a temporary file system for output capture.
• Optional: REXX thread library if parallel execution is needed.

Minimal Design

1. Define a whitelist. Store allowed commands and optional argument patterns in a data structure.
2. Validate user input. Before invoking CALL, ensure the command and arguments match the whitelist.
3. Invoke CALL with OUTPUT capture. If the platform supports the OUTPUT parameter, use it to capture stdout directly; otherwise redirect to a temporary file.
4. Check STATUS or return value. Immediately after the call, examine STATUS (or the CALL return value) to detect errors.
5. Read and process output. If a temp file was used, read it into a string or array and delete the file.
6. Handle exceptions. Wrap the logic in a TRY/CATCH block to log failures and maintain a clean state.

Trust & Data Boundaries

Because CALL can execute any command, the trust boundary is the REXX process itself. All user‑supplied data that flows into CALL must be considered untrusted. The whitelist is the primary guard: it limits the command space and prevents injection of arbitrary shell syntax. For example:

/* REXX */
allowedCommands = "ls pwd echo"

/* Validate */
if pos(command, allowedCommands) = 0 then do
  /* Reject */
  say "Command not allowed: " command
  exit 1
end

When arguments are involved, use a regular expression or explicit comparison rather than concatenating raw user input into the command string.

Operational Checks

• Exit status. After CALL, STATUS holds the exit code. A non‑zero value indicates failure.
• Output file existence. If using a temp file, confirm the file was created and is readable.
• File size limits. For commands that can produce large output, check the file size and decide whether to stream or truncate.
• Permissions. Verify that the REXX process has the necessary file system permissions to write the temp file and execute the command.

Failure Modes & Mitigation

Failure	Cause	Mitigation
Command not found	Typo or missing path	Check STATUS and log the error; use absolute paths or a wrapper script.
Permission denied	Insufficient OS rights	Run REXX under a user with the needed privileges; use SYSTEM on IBM i for controlled privilege escalation.
Large output buffer overflow	Command emits > 64K of text	Redirect to a file; avoid capturing in a string.
Shell injection	Unvalidated user input	Whitelist and escape; avoid concatenating raw arguments.
Resource leak	Temp file not deleted	Use TRY/FINALLY to guarantee cleanup.

When to Change the Design

• High‑throughput automation. If you need to run thousands of commands per minute, consider spawning background processes or using the REXX thread library to avoid blocking the main interpreter.
• Cross‑platform scripts. When the same REXX code must run on Windows, Unix, and IBM i, abstract the command invocation behind a function that maps logical command names to platform‑specific shell syntax.
• Need for asynchronous output. If you must process output as it streams (e.g., tailing logs), replace the synchronous CALL with a background thread that reads from a pipe.
• Privileged operations. If commands require elevated rights, use IBM i’s SYSTEM command with the PRIVILEGE option instead of CALL to enforce security policies.
• Complex argument handling. For commands that need dynamic quoting or shell expansion, construct the command string carefully or delegate to a wrapper script that receives arguments safely.

Concrete Example

Below is a portable REXX snippet that demonstrates the minimal design on Unix and Windows. It runs echo, captures output, checks status, and cleans up.

/* REXX */
/* Parameters */
command = 'echo'
args    = 'Hello, World!'

/* Whitelist */
allowed = 'echo'
if command ~= allowed then do
  say 'Command not allowed: ' command
  exit 1
end

/* Temp file */
file = 'tmp_output_' || time() || '.txt'

/* Build invocation */
cmdLine = command || ' ' || args

/* Execute */
/* On platforms that support OUTPUT, use it; otherwise redirect */
if syscmd('which sh') then do
  /* Unix */
  call sh -c cmdLine > file
  status = STATUS
else
  /* Windows */
  call cmd /c cmdLine > file
  status = STATUS
end

/* Check status */
if status ~= 0 then do
  say 'Command failed with exit code' status
  /* Read error output if available */
  if fileexists(file) then readfile(file, output)
  else output = 'No output captured'
  say output
  exit status
end

/* Read output */
readfile(file, output)
/* Clean up */
if fileexists(file) then delete file

/* Helper functions */
readfile: procedure
  parse arg fname, buffer
  if fileexists(fname) then do
    buffer = ''
    do while linesin(fname) > 0
      buffer = buffer || linein(fname)
    end
  end
  return buffer
end

fileexists: function
  parse arg fname
  return fileexists(fname)
end

Note: Replace fileexists and linesin with the appropriate REXX system calls on your platform.

Verification Checklist

1. Run the script on a test machine; confirm that the output file contains "Hello, World!".
2. Change command to a non‑existent name; verify that STATUS is non‑zero and the error path is executed.
3. Execute the script on both Windows and Unix to confirm that the correct shell is invoked and path resolution works.
4. Intentionally introduce a large output command (e.g., generate 1M lines) and observe that the file size check prevents a buffer overflow.

Limitations

• Platform‑specific behavior: Windows uses cmd.exe, Unix uses /bin/sh. Path resolution and quoting rules differ.
• REXX line buffer limits may truncate output if not redirected to a file.
• Security relies on the whitelist; an attacker who can modify the whitelist script can bypass controls.
• Asynchronous or parallel execution requires additional complexity (threads, pipes).

Conclusion

By encapsulating CALL inside a whitelist‑protected function, capturing output safely, and checking STATUS, you can reliably use REXX to automate system tasks while mitigating common failure modes and security risks. Adapt the design to your platform and workload needs, and always verify the approach in a controlled test environment before deploying to production.
